Configuration Connections - B&B Electronics PESV1A Manual

Switch or Hub
PC
PC
* Must be w ithin 100 ft of the PES1A/PESV1A
Figure 7. Connection using Midspan Power Source

Configuration Connections

Your PES1A/PESV1A converter typically is configured over the network
connection using standard browser software. It also could be connected
directly to a PC network adapter. To do so an Ethernet crossover cable is
required. Also, a midspan power source is required to provide power to the
PES1A/PESV1A.
M idspan PoE
Power Source*
PC
PC
* Must be w ithin 100 ft of the PES1A/PESV1A
Figure 8. Direct Configuration Connection
Manual Documentation Number: PES1A/PESV1A-4905m
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Hardware Overview
M idspan PoE
Power Source*
Serial Cable
Serial Device
PES1A
or
PESV1A
Serial Cable
Serial Device
PES1A
or
PESV1A
Hardware Overview
9 10
