C
h
a
p
t
e
r
C
h
a
p
t
e
r
Package Checklist
PES1A/PESV1A PoE Ethernet to RS-232 Converters are shipped with the
following items included:
The PES1A or PESV1A module
A printed version of this user manual
A printed version of the PES1A/PESV1A Quick Start Guide
CD-ROM disc with
o
B&B discovery software
o
RealPort drivers for Windows 98/ME/2000/XP/NT 4.0
this manual in pdf format
o
a Quick Start guide in pdf format
o
Power Over Ethernet
to RS-232 Converter
Model PES1A
Figure 2.
Top View of the PES1A Converter
Figure 3.
Top View of the PESV1A Converter
Manual Documentation Number: PES1A/PESV1A-4905m
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Hardware Overview
2
:
H
a
r
d
w
a
r
e
O
v
e
r
2
:
H
a
r
d
w
a
r
e
O
v
e
r
Hardware Overview
Indicators, Switches and Connectors
v
i
e
w
v
i
e
w
Link Integrity LED (Yellow)
When the yellow LED located on the Ethernet jack is illuminated it indicates
that a connection (link integrity) has been established between the converter
and a node on the network.
Network Activity LED
When the green LED located on the Ethernet jack is flashing it indicates
data is being sent across the network.
Reset Switch
The Reset switch is a recessed switch located on the RJ-45 end of the PES1A
and on the side of the PESV1A. The Reset switch provides two functions:
Press and release within 10 seconds
Press and hold for more than 10 seconds
Voltage Output Selector Switch (PESV1A only)
A three-position slide switch located on the side of the PESV1A allows you
to select the voltage output (available on the two position terminal block).
The three voltages available are:
•
•
•
5
6
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Figure 4.
LED Indicators on the PES1A
Reloads factory default values
while powering up
5 VDC
9 VDC
12 VDC
Manual Documentation Number: PES1A/PESV1A-4905m
Resets the PES1A/PESV1A
