DM-RMC-SCALER-C
DigitalMedia 8G+
> DigitalMedia 8G+
receiver, high-definition scaler, and
display controller
> DM 8G+
input supports up to 330 ft (100 m) cable length
> Connects to a DM
switcher or transmitter over one CAT5e
®
or Crestron
DM 8G
cable
®
®
> HDBaseT
Certified — Enables direct connection to a
®
third-party HDBaseT source
> Provides one HDMI
or DVI display output
®
> Accepts any video source from standard NTSC 480i or
PAL 576i, to HD 1080p60 w/Deep Color
> Also accepts any computer source from VGA to UXGA/WUXGA
> Scales the source to match the native resolution of virtually any
popular video display or computer monitor
> Provides intelligent frame rate conversion
> Allows motion-adaptive de-interlacing or interlacing
> Allows adjustable overscan or underscan up to 7.5%
> Provides automatic 3D to 2D signal conversion
> Automatically passes 3D video without scaling to 3D
capable displays
[2]
> Includes content-adaptive noise reduction
> 100% HDCP compliant
> Scalable zoom feature enables 2x2, 3x2, 3x3, 4x3, or 4x4 video
wall capability
[6]
> Handles Dolby
TrueHD, DTS-HD Master Audio
®
uncompressed 7.1 linear PCM audio
> Provides 10/100 Ethernet and USB HID mouse/keyboard ports
> Compatible with Crestron USB Extenders to enable expanded
USB device support
[5]
> Enables device control via CEC, IR, RS-232, and Ethernet
> Allows quick, easy setup and diagnostics
> Low-profile design mounts to a 2-gang US, UK, or European
wall box
> Universal power pack included
The DM-RMC-SCALER-C provides an advanced one-box interface
solution for a single display device as part of a complete Crestron
DigitalMedia
system. It functions as a DM 8G+
and control interface, providing a single HDMI
USB HID, RS-232, and IR control ports. In addition to DM 8G+, it is also
compatible with HDBaseT
specifications, allowing it to be connected
®
directly to any HDBaseT compliant source. Built-in scaling enables the
connected display to handle virtually any video signal up to HD 1080p and
WUXGA resolutions. Its compact, low-profile design allows the
DM-RMC-SCALER-C to be installed discreetly behind a flat panel display
or above a ceiling mounted projector. It connects to the head end or source
location using a single CAT5e or Crestron DM 8G
DigitalMedia 8G+
As the leader in HDMI and control system technologies, Crestron
developed DigitalMedia (DM
) to deliver the first complete HD AV
®
distribution system to take HDMI to a higher level. DigitalMedia allows
virtually any mix of HDMI and other AV sources to be distributed throughout
|
crestron.com
800.237.2041
Receiver & Room Controller w/Scaler
[1]
[3]
[2]
, and
®
receiver, video scaler,
®
output along with Ethernet,
cable.
®
[1]
[1]
a home, office, school, or virtually any other facility.
DigitalMedia 8G+ is the latest generation of DM, providing a true one-wire
transport for moving high-definition video, audio, and Ethernet over low-
cost twisted-pair cable without any compression or repeaters.
Engineered for ultra high-bandwidth and ultimate scalability, DM 8G+
handles uncompressed video beyond high-definition with support for
HDCP, Deep Color, and 3D. Audio capabilities include support for high-
bitrate 7.1 audio formats like Dolby
as well as uncompressed linear PCM. All signals are transported over one
8-conductor twisted-pair cable, supporting distances up to 330 feet
(100 m) using Crestron DM 8G Cable or CAT5e.
HDBaseT
Certified
®
Crestron DigitalMedia 8G+ technology is designed using HDBaseT Alliance
specifications, ensuring interoperability with third-party HDBaseT products.
Via its DM 8G+ input, the DM-RMC-SCALER-C can be connected directly to
any HDBaseT compliant source without requiring a DM transmitter.
HDBaseT connectivity through the DM-RMC-SCALER-C converges
uncompressed full HD digital video, audio, Ethernet, and control signals
through a single CAT5e or CAT6 cable over distances up to 330 ft (100m).
Multimedia Display Interface
A single HDMI digital AV output port is provided on the
DM-RMC-SCALER-C, supporting HD 1080p video and WUXGA computer
signals with HDCP, Deep Color, 3D
— all through one connection. The HDMI output can also handle DVI
signals using an appropriate adapter or interface cable
A single cable connects the DM-RMC-SCALER-C to a DM switcher or
transmitter, or to an HDBaseT source, transporting video, audio, control,
and networking signals all through one simple RJ45 connection.
DM-RMC-SCALER-Cs may be installed to handle each display in a multi-
room distribution system, all fed from a central DM-MD series switcher.
Or, a single DM-RMC-SCALER-C can be fed straight from a DM 8G+
or HDBaseT transmitter, affording a simple solution for extending a
computer or AV signal to a single display.
®
TrueHD and DTS-HD Master Audio
[1]
[2]
, and multi-channel HD lossless audio
.
[3]
[1]
Multiple
