Crestron DM NVX Series Quick Start Manual

DM-NVX-350C, DM-NVX-351C, and DM-NVX-352C
DM NVX® 4K60 4:4:4 HDR Network AV Encoder/Decoder Cards
The Crestron® DM-NVX-350C, DM-NVX-351C, and
network AV encoder/decoder cards transport ultra high-definition 4K60
4:4:4 HDR video over standard Gigabit Ethernet.

In the Box

1 DM-NVX-350C, DM-NVX-351C, or DM-NVX-352C
Network AV Encoder/Decoder Card
Additional Item
1 Connector, 5-Pin (2003577)

Install the Card

The DM-NVX-350C, DM-NVX-351C, and DM-NVX-352C are designed to
occupy the DMF-CI-8 chassis.
CAUTIONS: To prevent bodily injury when mounting or servicing the
unit in a rack, observe the following guidelines:
DM NVX® cards are susceptible to damage from electrostatic
l
discharge (ESD). Observe standard ESD precautions when
handling the cards. Wear an ESD wrist strap that is connected to
ground, and place the cards on grounded surfaces only.
To prevent damage to a card that is connected to cables,
l
disconnect all cables from the card before installing the card into a
card slot or removing the card.
DM-NVX-352C
NOTES:
l
l
To install a card into the DMF-CI-8:
1. Using a #2 Phillips screwdriver (not included) or your fingers, remove
the filler plate of an unused slot by loosening the two captive panel
screws.
2. Carefully insert the card into the card guides of the selected slot, and
then push the card inward until it engages the chassis backplane.
In a new installation of the DMF-CI-8, it is recommended that the
cards be installed before power is applied to the chassis. In an
existing installation of the DMF-CI-8, the cards can be added or
replaced without the need to shut down the chassis—the cards are
hot swappable.
When installing the cards into a partially populated DMF-CI-8,
install the cards into slots 5–8 before using slots 1–4. Doing so
ensures better cooling and lower power consumption. In addition,
always cover empty slots using the filler plates included with the
chassis.
