Crestron DM-RMC-SCALER-C
DigitalMedia 8G+™ Receiver & Room
Controller with Scaler
Operations & Installation Guide

Advertisement

Table of Contents
loading

Related Manuals for Crestron DM-RMC-SCALER-C

Summary of Contents for Crestron DM-RMC-SCALER-C

  • Page 1 Crestron DM-RMC-SCALER-C DigitalMedia 8G+™ Receiver & Room Controller with Scaler Operations & Installation Guide...

  • Page 2: Regulatory Compliance

    HDMI Licensing LLC in the United States and/or other countries. Other trademarks, registered trademarks, and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others.

  • Page 3: Table Of Contents

    Further Inquiries ......................24 Future Updates ......................24 Return and Warranty Policies ....................25 Merchandise Returns / Repair Service ..............25 Crestron Limited Warranty ..................25 GNU General Public License ....................26 Operations & Installation Guide – DOC. 7231B Contents • i...

  • Page 5: Digitalmedia 8G+ Receiver & Room Controller With Scaler: Dm-Rmc-Scaler-C

    Provides intelligent frame rate conversion (Continued on following page) 1. For DM 8G+ or HDBaseT wiring, use Crestron DM-CBL-8G DigitalMedia 8G™ cable, Crestron DM-CBL DigitalMedia cable, Crestron DM-CBL-D DigitalMedia D cable, or third-party CAT5e (or better) UTP or STP. Maximum wire length for DM 8G+ is 330 feet (100 meters) between devices.
  • Page 6 Dolby TrueHD and DTS-HD Master Audio as well as uncompressed linear PCM. All signals are transported over one 8-conductor twisted pair cable, supporting distances up to 330 feet (100 meters) using Crestron DM 8G cable or CAT5e. HDBaseT Certified Crestron DigitalMedia 8G+ technology is designed using HDBaseT Alliance specifications, ensuring interoperability with third-party HDBaseT products.
  • Page 7 DM switcher. Or, a single DM-RMC-SCALER-C can be fed straight from a DM 8G+ or HDBaseT transmitter, affording a simple solution for extending a computer or AV signal to a single display.
  • Page 8 Configurations of 2 x 2, 3 x 2, 3 x 3, 4 x 3, or 4 x 4 are supported, and all that is required is a separate DM-RMC-SCALER-C for each display and a DM switcher with sufficient DM 8G+ outputs.

  • Page 9: Applications

    Applications The diagram below shows a DM-RMC-SCALER-C in a standalone application. In this type of application, the DM-RMC-SCALER-C is used with a DM 8G+ transmitter such as the DM-TX-201-C and is not used with a DM switcher. DM-RMC-SCALER-C in a Standalone Application Operations &...

  • Page 10: Specifications

    DigitalMedia 8G+ Receiver Crestron DM-RMC-SCALER-C Specifications Specifications for the DM-RMC-SCALER-C are listed in the following table. DM-RMC-SCALER-C Specifications SPECIFICATION DETAILS Video Scaler HD video scaler, motion-adaptive deinterlacer, interlacer, intelligent frame rate conversion, Deep Color support, 3D-to-2D conversion, content-adaptive noise reduction, widescreen format...
  • Page 11 , Dolby Digital EX, Dolby ® Digital Plus, Dolby TrueHD, DTS DTS-ES, DTS 96/24, DTS-HD High Res, DTS-HD Master Audio, up to 8ch PCM (Continued on following page) Operations & Installation Guide – DOC. 7231B DigitalMedia 8G+ Receiver: DM-RMC-SCALER-C • 7...
  • Page 12 Width 7.61 in (194 mm) Depth 1.46 in (38 mm) Weight 1.9 lb (0.9 kg) Included Accessory Universal 24 Volt DC Power Pack (Continued on following page) 8 • DigitalMedia 8G+ Receiver: DM-RMC-SCALER-C Operations & Installation Guide – DOC. 7231B...
  • Page 13 3D. 3. Video wall processing requires a separate DM-RMC-SCALER-C for each individual display. 4. For DM 8G+ or HDBaseT wiring, use Crestron DM-CBL-8G DigitalMedia 8G cable, Crestron DM-CBL DigitalMedia cable, Crestron DM-CBL-D DigitalMedia D cable, or third-party CAT5e (or better) UTP or STP.

  • Page 14: Physical Description

    Crestron DM-RMC-SCALER-C Physical Description This section provides information on the connections, controls, and indicators available on the DM-RMC-SCALER-C. DM-RMC-SCALER-C Physical View (Front Panel) DM-RMC-SCALER-C Physical View (Bottom Panel) 10 • DigitalMedia 8G+ Receiver: DM-RMC-SCALER-C Operations & Installation Guide – DOC. 7231B...
  • Page 15 Crestron DM-RMC-SCALER-C DigitalMedia 8G+ Receiver DM-RMC-SCALER-C Overall Dimensions (Front and Side Panels) 1.46 in 7.61 in (38 mm) (194 mm) 7.46 in 1.39 in 1.05 in (190 mm) (36 mm) (27 mm) 7.62 in 7.55 in (194 mm) (192 mm) DM-RMC-SCALER-C Connectors, Controls, and Indicators (Front Panel) Operations &...
  • Page 16 DigitalMedia 8G+ Receiver Crestron DM-RMC-SCALER-C DM-RMC-SCALER-C Connectors, Controls, and Indicators (Top Panel) DM-RMC-SCALER-C Connectors, Controls, and Indicators (Bottom Panel) DM-RMC-SCALER-C Connectors, Controls, and Indicators (Rear Panel) 12 • DigitalMedia 8G+ Receiver: DM-RMC-SCALER-C Operations & Installation Guide – DOC. 7231B...
  • Page 17 (1) 4-pin 3.5 mm detachable terminal block comprising two IR/Serial ports: IR output up to 1.1 MHz; 1-way serial TTL/RS-232 (0-5 volts) up to 19200 baud (Continued on following page) Operations & Installation Guide – DOC. 7231B DigitalMedia 8G+ Receiver: DM-RMC-SCALER-C • 13...
  • Page 18 Blue Brown 5. For DM 8G+ or HDBaseT wiring, use Crestron DM-CBL-8G DigitalMedia 8G cable, Crestron DM-CBL DigitalMedia cable, Crestron DM-CBL-D DigitalMedia D cable, or third-party CAT5e (or better) UTP or STP. Maximum wire length for DM 8G+ is 330 feet (100 meters) between devices.

  • Page 19: Setup

    When setting the IP ID, consider the following: • The IP ID of each unit must match an IP ID specified in the Crestron Studio or SIMPL Windows program. • Each device using IP to communicate with a control system must have a unique IP ID.

  • Page 20: Supplied Hardware

    Using the four included 6-32 x 3/4” (2009211) slot head screws, attach the included mounting bracket to the electrical box. Ground the DM-RMC-SCALER-C and attach the proper cable to the rear of the unit (refer to “Hardware Hookup” on page 17 for information).

  • Page 21: Hardware Hookup

    Hardware Hookup Make the necessary connections as called out in the following illustrations. Refer to “Network Wiring” on page 15. Apply power after all connections have been made. Hardware Connections for the DM-RMC-SCALER-C (Top Panel View) LAN: 24 V 10BASE-T/ 0.75A MAX:...
  • Page 22 NOTE: Ensure that the unit is properly grounded by connecting the chassis ground lug to an earth ground (building steel). NOTE: For DM 8G+ or HDBaseT wiring, use Crestron DM-CBL-8G DigitalMedia 8G cable, Crestron DM-CBL DigitalMedia cable, Crestron DM-CBL-D DigitalMedia D cable, or third-party CAT5e (or better) UTP or STP Maximum wire length for DM 8G+ is 330 feet (100 meters) between devices.

  • Page 23: Uploading And Upgrading

    In addition, the IP table of the device can be configured. NOTE: Crestron software and any files on the website are for authorized Crestron dealers and Crestron Service Providers (CSPs) only. New users must register to obtain access to certain areas of the site (including the FTP site).
  • Page 24 To establish USB communication between the PC and the DM-RMC-SCALER-C via a DM switcher: Use the Address Book in Crestron Toolbox to create an entry using the expected communication protocol (USB). When multiple USB devices are connected, identify the DM switcher by entering “DM-MD8X8”, “DM-MD16X16”, or “DM-MD32X32”...

  • Page 25: Firmware

    For details on upgrading, refer to the Crestron Toolbox help file. Check the Crestron website to find the latest firmware. (New users must register to obtain access to certain areas of the site, including the FTP site.)

  • Page 26: Ip Configuration

    Crestron Toolbox to create the IP table entry of the DM-RMC-SCALER-C. NOTE: If the DM-RMC-SCALER-C is connected to a DM switcher, the IP table entry of the DM-RMC-SCALER-C is created automatically. Use the Device Discovery Tool to find the IP address of the DM-RMC-SCALER-C.

  • Page 27: Problem Solving

    Device is improperly Check that all ground functionality due grounded. connections have been made to electrostatic properly. discharge. NOTE: For more advanced diagnostics, use the DMTool in Crestron Toolbox. Operations & Installation Guide – DOC. 7231B DigitalMedia 8G+ Receiver: DM-RMC-SCALER-C • 23...

  • Page 28: Reference Documents

    Crestron worldwide offices at www.crestron.com/offices. To post a question about Crestron products, log onto Crestron’s Online Help at www.crestron.com/onlinehelp. First-time users must establish a user account to fully benefit from all available features.

  • Page 29: Return And Warranty Policies

    (property or economic damages inclusive) arising from the sale or use of this equipment. Crestron is not liable for any claim made by a third party or made by the purchaser for a third party.

  • Page 30: Gnu General Public License

    You may charge a fee for the physical act of transferring a copy and you may at your option offer warranty protection in exchange for a fee. 26 • DigitalMedia 8G+ Receiver: DM-RMC-SCALER-C Operations & Installation Guide – DOC. 7231B...
  • Page 31 Program (or any work based on the Program), you indicate your acceptance of this License to do so and all its terms and conditions for copying, distributing or modifying the Program or works based on it. Operations & Installation Guide – DOC. 7231B DigitalMedia 8G+ Receiver: DM-RMC-SCALER-C • 27...
  • Page 32 THIRD PARTIES OR A FAILURE OF THE PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. 28 • DigitalMedia 8G+ Receiver: DM-RMC-SCALER-C Operations & Installation Guide – DOC. 7231B...
  • Page 33 Crestron DM-RMC-SCALER-C DigitalMedia 8G+ Receiver This page is intentionally left blank. Operations & Installation Guide – DOC. 7231B DigitalMedia 8G+ Receiver: DM-RMC-SCALER-C • 29...
  • Page 34 DigitalMedia 8G+ Receiver Crestron DM-RMC-SCALER-C This page is intentionally left blank. 30 • DigitalMedia 8G+ Receiver: DM-RMC-SCALER-C Operations & Installation Guide – DOC. 7231B...
  • Page 35 Crestron DM-RMC-SCALER-C DigitalMedia 8G+ Receiver This page is intentionally left blank. Operations & Installation Guide – DOC. 7231B DigitalMedia 8G+ Receiver: DM-RMC-SCALER-C • 31...
  • Page 36 Crestron Electronics, Inc. Operations & Installation Guide – DOC. 7231B (2031645) 15 Volvo Drive Rockleigh, NJ 07647 Tel: 888.CRESTRON 04.14 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
