Crestron DM-RMC-SCALER-C
DigitalMedia 8G+™ Receiver & Room
Controller with Scaler
Operations & Installation Guide

Advertisement

Table of Contents
loading

Related Manuals for Crestron DM-RMC-SCALER-C

Summary of Contents for Crestron DM-RMC-SCALER-C

  • Page 1 Crestron DM-RMC-SCALER-C DigitalMedia 8G+™ Receiver & Room Controller with Scaler Operations & Installation Guide...

  • Page 2: Regulatory Compliance

    Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. This device includes an aggregation of separate independent works that are each generally copyrighted by Crestron Electronics, Inc., with all rights reserved. One of those independent works, Linux Bridge Project, is copyrighted under the GNU GENERAL PUBLIC LICENSE, Version2, reproduced in “GNU General Public License”...

  • Page 3: Table Of Contents

    Crestron DM-RMC-SCALER-C DigitalMedia 8G+™ Receiver Contents DigitalMedia 8G+™ Receiver & Room Controller with Scaler: DM-RMC-SCALER-C Introduction ..........................1 Features and Functions ....................1 Applications......................... 5 Specifications ......................6 Physical Description....................10 Setup ............................15 Network Wiring......................15 Identity Code ......................15 Supplied Hardware ....................

  • Page 5: Digitalmedia 8G+™ Receiver & Room Controller With Scaler: Dm-Rmc-Scaler-C

    100% HDCP compliant (Continued on following page) 1. For DM 8G+ wiring up to 330 feet (100 meters) between devices, use Crestron DM-CBL-8G DigitalMedia 8G™ cable, Crestron DM-CBL DigitalMedia cable, Crestron DM-CBL-D DigitalMedia D cable, or generic CAT5e (or better) UTP or STP. Shielded cable and connectors are recommended to safeguard against unpredictable environmental electrical noise which may impact performance at resolutions above 1080p.
  • Page 6 1. Video wall processing requires a separate DM-RMC-SCALER-C for each individual display. 2. For DM 8G+ wiring up to 330 feet (100 meters) between devices, use Crestron DM-CBL-8G DigitalMedia 8G cable, Crestron DM-CBL DigitalMedia cable, Crestron DM-CBL-D DigitalMedia D cable, or generic CAT5e (or better) UTP or STP.
  • Page 7 16 individual displays. Configurations of 2x2, 3x2, 3x3, 4x3, or 4x4 are supported, and all that is required is a separate DM-RMC-SCALER-C for each display, and a DM switcher with sufficient DM 8G+ outputs.
  • Page 8 CEC (Consumer Electronics Control) signal embedded in HDMI. Through its connection to the control system, the DM-RMC-SCALER-C provides a gateway for controlling the display device through the HDMI connection, potentially eliminating the need for any dedicated control wires or IR probes.

  • Page 9: Applications

    Applications The diagram below shows a DM-RMC-SCALER-C in a standalone application. In this type of application, the DM-RMC-SCALER-C is used with a DM 8G+ transmitter such as the DM-TX-201-C and is not used with a DM switcher. DM-RMC-SCALER-C in a Standalone Application DigitalMedia 8G+™...

  • Page 10: Specifications

    DigitalMedia 8G+™ Receiver Crestron DM-RMC-SCALER-C Specifications Specifications for the DM-RMC-SCALER-C are listed in the following table. DM-RMC-SCALER-C Specifications SPECIFICATION DETAILS Video Scaler HD video scaler, motion-adaptive deinterlacer, interlacer, intelligent frame rate conversion, Deep Color support, 3D-to-2D conversion , content-adaptive noise reduction, widescreen format...
  • Page 11 , Dolby Digital EX, Dolby ® Digital Plus, Dolby TrueHD, DTS DTS-ES, DTS 96/24, DTS-HD High Res, DTS-HD Master Audio™, up to 8ch PCM (Continued on following page) DigitalMedia 8G+™ Receiver: DM-RMC-SCALER-C • 7 Operations & Installation Guide – DOC. 7231A...
  • Page 12 Width 7.61 in (194 mm) Depth 1.46 in (38 mm) Weight 1.9 lb (0.9 kg) Included Accessory Universal 24 Volt DC Power Pack (Continued on following page) 8 • DigitalMedia 8G+™ Receiver: DM-RMC-SCALER-C Operations & Installation Guide – DOC. 7231A...
  • Page 13 6. With or without reduced blanking. 7. With reduced blanking only. 8. The latest software versions can be obtained from the Crestron Web site. Refer to the NOTE following these footnotes. 9. Crestron 2-Series control systems include the AV2 and PRO2. Consult the latest Crestron Product Catalog for a complete list of 2-Series control systems.

  • Page 14: Physical Description

    Physical Description This section provides information on the connections, controls and indicators available on your DM-RMC-SCALER-C. DM-RMC-SCALER-C Physical Views (Front Panel View) DM-RMC-SCALER-C Physical View (Bottom Panel View) 10 • DigitalMedia 8G+™ Receiver: DM-RMC-SCALER-C Operations & Installation Guide – DOC. 7231A...
  • Page 15 Crestron DM-RMC-SCALER-C DigitalMedia 8G+™ Receiver DM-RMC-SCALER-C Overall Dimensions (Front and Side Panel Views) 1.46 in 7.61 in (38 mm) (194 mm) 7.46 in 1.39 in 1.05 in (190 mm) (36 mm) (27 mm) 7.62 in 7.55 in (194 mm) (192 mm) DM-RMC-SCALER-C Connectors, Controls &...
  • Page 16 DigitalMedia 8G+™ Receiver Crestron DM-RMC-SCALER-C DM-RMC-SCALER-C Connectors, Controls & Indicators (Top Panel View) DM-RMC-SCALER-C Connectors, Controls & Indicators (Bottom Panel View) DM-RMC-SCALER-C Connectors, Controls & Indicators (Rear Panel View) 12 • DigitalMedia 8G+™ Receiver: DM-RMC-SCALER-C Operations & Installation Guide – DOC. 7231A...
  • Page 17 (1) 4-pin 3.5 mm detachable terminal block comprising two IR/Serial ports: IR output up to 1.1 MHz; 1-way serial TTL/RS-232 (0-5 Volts) up to 19200 baud (Continued on following page) DigitalMedia 8G+™ Receiver: DM-RMC-SCALER-C • 13 Operations & Installation Guide – DOC. 7231A...
  • Page 18 Blue Brown 6. For DM 8G+ wiring up to 330 feet (100 meters) between devices, use Crestron DM-CBL-8G DigitalMedia 8G cable, Crestron DM-CBL DigitalMedia cable, Crestron DM-CBL-D DigitalMedia D cable, or generic CAT5e (or better) UTP or STP. Shielded cable and connectors are recommended to safeguard against unpredictable environmental electrical noise which may impact performance at resolutions above 1080p.

  • Page 19: Setup

    6052), which is available from the Crestron Web site (www.crestron.com/manuals). For information specifically related to Ethernet connectivity using DigitalMedia devices, refer to the latest version of the Crestron IP Considerations Guide for the IT Professional (Doc. 4579), which is also available from the Crestron Web site (www.crestron.com/dmresources).

  • Page 20: Supplied Hardware

    1. Using the four included 6-32 x 3/4” (2009211) slot head screws, attach the included mounting bracket to the electrical box. 2. Ground the DM-RMC-SCALER-C and attach the proper cable to the rear of the unit (refer to “Hardware Hookup” on page 18 for information).

  • Page 21: Hardware Hookup

    Hardware Hookup Make the necessary connections as called out in the following illustrations. Refer to “Network Wiring” on page 15. Apply power after all connections have been made. Hardware Connections for the DM-RMC-SCALER-C (Top Panel View) LAN: 24 V 10BASE-T/ 0.75A MAX:...
  • Page 22 UTP or STP. Shielded cable and connectors are recommended to safeguard against unpredictable environmental electrical noise which may impact performance at resolutions above 1080p. Refer to the latest version of the Crestron DigitalMedia Infrastructure Guide (Doc. 4556) for complete wiring guidelines and to the Crestron DigitalMedia Design Guide (Doc.

  • Page 23: Programming Software

    Have a question or comment about Crestron software? Answers to frequently asked questions (FAQs) can be viewed in the Online Help section of the Crestron Web site. To post a question or view questions you have submitted to Crestron’s True Blue Support, log in at www.crestron.com/support.
  • Page 24 C2ENET-2 Device, Slot 8 (Using Output Card in a DM Switcher) C2ENET-2 Device, Slot 8 (Using Ethernet Slot on Control System) 2. If additional DM-RMC-SCALER-C devices are to be added, repeat step 1 for each device. Each DM-RMC-SCALER-C device is assigned a different IP ID.
  • Page 25 Crestron DM-RMC-SCALER-C DigitalMedia 8G+™ Receiver Program Manager Program Manager is the view where programmers “program” a Crestron control system by assigning signals to symbols. The symbol can be viewed by double-clicking the icon or dragging it into Detail View. Each signal in the symbol is described in the SIMPL Windows help file (F1).

  • Page 26: Uploading And Upgrading

    1. Establish communication between the PC and the DM switcher as described in the latest version of the DigitalMedia Switchers Operations Guide (Doc. 6755). 2. Use the Device Discovery Tool in Crestron Toolbox to find the IP address of the DM-RMC-SCALER-C. The tool is available in Toolbox version 1.15.143 or later.
  • Page 27 DM 8G+ To establish USB communication between the PC and the DM switcher: 1. Use the Address Book in Crestron Toolbox to create an entry using the expected communication protocol (USB). When multiple USB devices are connected, identify the DM switcher by entering “DM-MD8X8”, “DM-MD16X16”, or “DM-MD32X32”...

  • Page 28: Firmware

    For details on upgrading, refer to the Crestron Toolbox help file. Check the Crestron Web site to find the latest firmware. (New users may be required to register to obtain access to certain areas of the site, including the FTP site.) To upgrade DM-RMC-SCALER-C firmware: 1.

  • Page 29: Ip Configuration

    IP Configuration If the DM-RMC-SCALER-C is used in a standalone configuration (i.e., not connected to a DM switcher), use Crestron Toolbox to create the IP table entry of the DM-RMC-SCALER-C. NOTE: If the DM-RMC-SCALER-C is connected to a DM switcher, the IP table entry of the DM-RMC-SCALER-C is created automatically.

  • Page 30: Problem Solving

    Improper grounding. Check that all ground functionality due connections have been made to electrostatic properly. discharge. NOTE: For more advanced diagnostics, use the DMTool in Crestron Toolbox. 26 • DigitalMedia 8G+™ Receiver: DM-RMC-SCALER-C Operations & Installation Guide – DOC. 7231A...

  • Page 31: Reference Documents

    Crestron Web site (www.crestron.com) for a listing of Crestron worldwide offices. You can also log onto the online help section of the Crestron Web site (www.crestron.com/onlinehelp) to ask questions about Crestron products. First- time users will need to establish a user account to fully benefit from all available features.

  • Page 32: Return And Warranty Policies

    Purchasers should inquire of the dealer regarding the nature and extent of the dealer's warranty, if any. CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended or if it has been subjected to misuse, accidental damage, modification or improper installation procedures.

  • Page 33: Gnu General Public License

    You may charge a fee for the physical act of transferring a copy and you may at your option offer warranty protection in exchange for a fee. DigitalMedia 8G+™ Receiver: DM-RMC-SCALER-C • 29 Operations & Installation Guide – DOC. 7231A...
  • Page 34 Program (or any work based on the Program), you indicate your acceptance of this License to do so and all its terms and conditions for copying, distributing or modifying the Program or works based on it. 30 • DigitalMedia 8G+™ Receiver: DM-RMC-SCALER-C Operations & Installation Guide – DOC. 7231A...
  • Page 35 THIRD PARTIES OR A FAILURE OF THE PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. DigitalMedia 8G+™ Receiver: DM-RMC-SCALER-C • 31 Operations & Installation Guide – DOC. 7231A...
  • Page 36 Crestron Electronics, Inc. Operations & Installation Guide – DOC. 7231A 15 Volvo Drive Rockleigh, NJ 07647 (2031645) Tel: 888.CRESTRON 08.11 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
