Spectralink IP-DECT Server 6500 Installation and Configuration Guide
In the New username field, type a new username.
3
In the New password field, type a password.
4
In the New password again, type the password again.
5
Click Allow remote logging if it should be possible to perform remote logging (Useful in case
6
of problem solving).
Select Force Secure HTTP (TLS) if you prefer this option. The setting is optional
7
Click Save.
8

Checking Indicators

Verify that the Spectralink IP-DECT Server 6500/media resource LED indicator is continuously
•
on, indicating that the Spectralink IP-DECT Server 6500/media resource is functional.
Note
The LED will not be green until the base stations have been configured.

Deployment of a Multi-Cell Solution

This section contains deployment information specific to the Spectralink IP-DECT Server 6500.
For general deployment information, refer to the Deployment Guide.
Sync over Air
As a user moves from one base station radio coverage area to another, the call must be handed
over to the next radio unit. To create handover between radio units it is necessary to establish
synchronization chains. If the synchronization between radio units is lost, then handover is not
possible and ongoing calls will be terminated.
Note
Each base station must be placed within the radio coverage area of at least one other base
station or repeater (radio units).
Synchronization Chains Considerations
Certain rules must be taken into consideration when establishing synchronazation chains:
14215700 Version 3.0
April, 2014 49
