HOT CAPPUCCINO & COFFEE DISPENSER
Cecilware sells value...Worldwide
th
45-05 20
Avenue, Long Island City, NY 11105
•
718-932-1414
FAX 718-932-7860
SERIES
GB1K
OCS-3
OPERATION MANUAL
Specifications
Installation &
Operating instructions
Adjustments
Care & Maintenance
Components Illustration
Parts Identification
Wiring Diagram
NC66A 12W96
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cecilware GB1K
Summary of Contents for Cecilware GB1K
- Page 1 HOT CAPPUCCINO & COFFEE DISPENSER SERIES GB1K OCS-3 OPERATION MANUAL Specifications Installation & Operating instructions Adjustments Care & Maintenance Components Illustration Parts Identification Wiring Diagram Cecilware sells value…Worldwide 45-05 20 Avenue, Long Island City, NY 11105 • 718-932-1414 FAX 718-932-7860 NC66A 12W96...
- Page 2 Electrical Specifications Kilo Number of Receptacle Nema Model No. Volts Phase Amps Circuit Breaker Watts Heaters GB1K, 120V 5-15R GB1K 120/240 50/60 L14-20R** GB1K 50/60 L6-20R* 120V, 1.8 KW, 15A, Nema 5-15R standard on all models; 3.0 KW, 120/240V units available ** 120/240V, 3 pole, 4 wire grounding type Twist-Plug Receptacle.
-
Page 3: Installation Requirements
INSTALLATION REQUIREMENTS: This equipment is to be installed to comply with the applicable federal, state, or local plumbing codes having jurisdiction. In addition: 1. A quick disconnect water connection or enough extra coiled tubing (at least the depth of the unit) so that the machine can be moved for cleaning underneath. -
Page 5: Part Numbers
TERMINAL BLOCK 120V OR 240V B117A OR B116A BALLAST CE221 RELAY, (NORMALLY OPEN) OR TIMER (OPTIONAL ) 1 20V B129A OR 58017 GB1K FRAME WELDMENT ASS'Y RC85Q POWER SWITCH (120V) OR (120/240 V) L069A OR L299A RINSE SWITCH L446A LEGS (SET OF 4) -
Page 6: Recommended Daily Cleaning
MAINTENANCE INSTRUCTIONS (See Illustration A): LIT DISPLAY LAMP AND STARTER REPLACEMENT 1. To replace the lamp, first remove the upper inside door panel. Turn the lamp and pull it out of the lamp holder, then place the new lamp into the lamp holder and turn it until it snaps into position. 2. -
Page 7: Quick Start-Up Procedure
QUICK START-UP PROCEDURE Flush inlet water line thoroughly before connecting. If pipe sealant is necessary, Teflon tape is commended. Connect water line to the 1/4" flare fitting located at rear of the unit. A shutoff valve in the water supply line is advisable. Turn on water.
