Adjusting the EZ-TRAK refrigerator shelf
(cont.)
To replace the shelf track:
1.
Guide the track hooks into the shelf support slots on
the back wall.
NOTE: Make sure that both sets of track hooks are in
the slots and that the slots are parallel with each other.
2.
Push the track back and down securely into the shelf
supports.
To reinstall the shelf:
1.
Hold the shelf at the front and tip the front at a 45°
angle to the track.
2.
Insert both of the rear shelf slides into the upper chan-
nel of the track.
3.
Lower the front into place.
NOTE: Make sure that both of the rear shelf slides are
securely in the track before letting go of the shelf. The
EZ-TRAK shelf may be difficult to install if the track is
placed too close to the refrigerator ceiling. If this occurs
reposition the track on lower rungs until the shelf can be
tilted enough to easily slide into the track.
R
EMOVING THE CRISPER AND
CRISPER COVER
The crisper and its cover are designed for easy removal and
cleaning.
To remove the crisper:
1.
Slide crisper straight out to the stop.
2.
Lift the front.
3.
Slide crisper out the rest of the way.
Replace the crisper in the reverse order.
To remove the cover:
1.
Hold the glass insert firmly while pushing up from the
bottom.
2.
Slide the glass insert out.
3.
Lift cover frame up and out.
NOTE: Before reinstalling the cover, make sure the U-shaped
reinforcement bar is reinstalled.
To replace the cover:
1.
Fit back of cover frame into notch supports on back wall
of the refrigerator.
2.
Lower front of the frame into place.
3.
Slide back of glass insert into place and lower front.
16
(on some models)
