POSIFLEX LM-6601 User Manual

LM-6601
nd
12.1" 2 LCD Monitor
User's Manual
I. FEATURES
• 12.1" LCD monitor with tilt adjust for 2
POS system
• Spill proof and easy maintenance structure allowing easy cleaning
• High quality TFT LCD panel with scaling up function for full screen
display
• Resolution: 1024 x 768
• Color depth: 262,144 colors
• Super VGA interface
• Powered through interface cable

FCC NOTICE

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions manual, may cause interference to radio communications. It has been tested and found to comply with limits
for a Class A digital device pursuant to subpart J of Part 15 of FCC Rules, which are designed to provide reasonable protection
against interference when operated in a commercial environment. Operation of this equipment in a residential area is likely to cause
interference in which case the user at his own expense will be required to take whatever measures to correct the interference.
WARRANTY LIMITS
Warranty will terminate automatically when the machine is opened by any person other than the authorized
technicians. The user should consult his/her dealer for the problem happened. Warranty voids if the user does not follow the
instructions in application of this merchandise. The manufacturer is by no means responsible for any damage or hazard caused by
improper application.

ABOUT THIS MANUAL

This manual assists the user to utilize the LCD Monitor LM-6601. Thos series provides adjustable robust
construction for 12.1" LCD display with maximum resolution of 1024 x 768 pixels and 262,144 colors. It is powered by the host FT
series system through the interface cable.
The manufacturer of the LM-6601 series heartily apologizes to the user for reserving the right to change or to modify
this manual without notice due to the rapid and constant progress and improvement on science and technology. The user may
always obtain the most up to date information through any of our web sites: http://www.posiflex.com, http://www.posiflex.com.tw,
http://www.posiflexusa.com.
TRADE MARKS AND SERVICE MARKS
POSIFLEX is a registered trademark of Posiflex Technologies, Inc..
Other brand and product names are trademarks and registered trademarks and service marks of their respective owners.
P/N: 19050903010
Rev. Original
© Copyright Posiflex Technologies, Inc. 2008
nd
display attached to FT series
Part 1
