Reference
Information
This section reference information for the SW HDMI LC switchers. Topics that are covered
include:
z z
z z
z z

Specifications

NOTE: *Appropriate HDMI to DVI-D cables or adapters are required for DVI signal input/output.
Video
Maximum data rate .................. 6.75 Gbps (2.25 Gbps per color)
Maximum pixel clock ................ 225 MHz
Resolution ................................ Up to 1080p @ 60 Hz or 720p/1080i @ 120 Hz, 12-bit color
Formats .................................... RGB, YCbCr, and xvYCC digital video
Standards ................................. DVI 1.0, HDMI 1.3, HDCP, CEA-861E
Video input
Number/signal type................... 2 or 4 single link HDMI (or DVI-D*)
Connectors ............................... 2 or 4 female HDMI type A
Input equalization ..................... +6 dB or +18 dB, selectable for each input
Video output
Number/signal type................... 1 single link HDMI (or DVI-D*)
Connectors ............................... 1 female HDMI type A
Control/remote — switcher
Serial control port ..................... (1) RS-232, 3.5 mm captive screw connector, 5 pole (shared with auto-
Baud rate and protocol ............. 9600 baud, 8 data bits, 1 stop bit, no parity
Serial control pin configurations 1 = Tx, 2 = Rx, 3 = GND
Contact closure ........................ (1) 3.5 mm captive screw connector, 5 pole (shared with RS-232)
Contact closure pin configurations
IR controller module ................. IR 102 remote control (optional)
Program control ........................ Extron Simple Instruction Set
Specifications
Part Numbers
Mounting the SW HDMI LC
input switching control)
Pins 4 and 5 shorted together turn auto-input switch mode on.
30' maximum, 40 degrees off axis
(SIS )
™ ™
SW HDMI LC • Reference Information 22
