CYBEX VR Owner's Manual page 5

Tools Required
• External snap ring pliers
• Hammer
• Medium weight automotive engine oil
Installing Weight Stacks
! WARNING: Use extreme caution when installing the weight stacks, failure to do so
could result in injury.
NOTE: Two people will be required to perform this procedure.
NOTE: Read and understand all instructions thoroughly before installing weight stacks.
1. Place machine in desired location.
2. Remove all banding and shipping supports.
3. Using an external snap ring pliers, remove the upper snap ring from one of the guide rods
and carefully lower the guide rod. See Figure 1.
Figure 1
4. Remove lower snap ring from the guide rod. Repeat steps 3 and 4 to remove both snap
rings from other guide rod.
5. Lean guide rods in the direction that will provide the most room for installing weight plates
(direction may vary, depending upon machine).
6. Slide top weight up and out of machine and carefully set it aside.
7. Wipe guide rods clean over entire length. Lubricate with light coating of medium weight
automotive engine oil.
8. Carefully install weight plates one at a time.
Cybex VR Owner's Manual
4 - Assembly
Assembly
Page 4-1
