Installation using Wall Mount Bracket
DWC-PTZ10x [Mini SPEED DOME CAMERA]
www.Digital-Watchdog.com
1. Pass the cables from the camera unit through the wall
mount bracket.
Then connect Video, communication, and power cables.
2. Install wall mount bracket on the wall using the four screws.
3. Attach the main unit to the wall mount bracket with the four
screws.
4. Carry out the settings and adjustments for the camera.
5. Secure the dome cover by tightening with the screws.
INSTALLATION
2
