Tech Specs - Blizzard Lighting The Puck 3NX Manual

Tech Specs!

Weight & Dimensions
Length
Width
Height
Weight
Power
Operating Voltage
Fuse
Power Consumption
Light Source
LED
Optical
Beam Angle
Luminous Intensity
Thermal
Max. Operating Temp.
Control
Protocol
DMX Channels
Input
Output
Other Operating Modes
Coolness Factor
Leventy Billion Percent
Warranty
The Puck 3NX Manual Rev. B
8.50 inches (215 mm)
3.75 inches (95.25 mm)
8.25 inches (210 mm)
4.2 lbs (1.9 kg)
90-230VAC, 50-60 Hertz
2A 250V
35W
9x 3-watt TRI-Color LED's 60K hrs.
25 degrees
29 degree fi eld
7,160 Lux @ 1m (Full White)
Red 1,550 Lux @ 1m
Green 2,250 Lux @ 1m
Blue 2,930 Lux @ 1m
104 degrees F (40 degrees C) ambient
USITT DMX-512
3 or 6 (User Selectable)
3-pin XLR Male
3-pin XLR Female
Standalone, Master/Slave, Sound Active,
Color Preset, Standalone color mixing
2-year limited warranty, does not cover mal-
function caused by damage to LED's.
Page 15
Copyright (c) 2011-2012 Blizzard Lighting, LLC
