Infinity V3367WTIR
User Manual Version #2:
Camera with ICON Menu
11192010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Infinity V3367WTIR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Digital Watchdog Infinity V3367WTIR

Summary of Contents for Digital Watchdog Infinity V3367WTIR

  • Page 1 Infinity V3367WTIR User Manual Version #2: Camera with ICON Menu 11192010...

  • Page 2: Fcc Compliance

    PRECAUTIONS  Do not open or modify.  Do not open the case except during maintenance and installation, for it may be dangerous and can cause damages.  Do not put objects into the unit.  Keep metal objects and flammable substances from entering the camera. It can cause fire, short-circuits, or other damages. ...
  • Page 3 FEATURES 1/3” Sony Super HAD II CCD High Resolution 560 TV Lines 3.3 ~ 12mm Varifocal Auto Iris Lens 100ft Range IR with Intelligent Camera Sync True Day & Night / TDN5 (Electro Magnetic Mechanism) Star-Light (Super Low Light Technology) Max-DR (Electronic Wide Dynamic Range) Enables the camera to capture perfect images in both bright and dark environments simultaneously.
  • Page 4 DIMENSIONS (mm) & POWER REQUIREMENT POWER REQUIREMENT: 12VDC @1A 24VAC @ .500mA Power Wire Maximum Distance COAXIAL CABLE TYPE MAXIMUM DISTANCE Wire Gauge 12VDC 24VAC 24 AWG 80ft 323ft RG59/ U 750feet 22 AWG 128ft 513ft 20 AWG 203ft 815ft RG6/U 1,000feet 18 AWG...

  • Page 5: Installation

    INSTALLATION Included with DW Vandal Dome Camera: Mounting Template User Manual Security L-Key Single Sided Hex Key Double Sided Hex Key Secondary BNC Cable for Field Monitor Four (4) Screws and Four (4) Dry Wall Anchors 3 Axis Gimbal Guide Camera Installation Use the mounting template to mount the camera.
  • Page 6 CONNECTION DC12V / AC24V Video Output BNC Cable Main Monitor Spot Monitor Cable Field Test Monitor...
  • Page 7 CAMERA SETTINGS & ON-SCREEN DISPLAY 1. Adjusting Level Volume (VR) If the entire image is too dark or bright or the backlight compensation is not correct even after the lens is set to “DC, ” you need to adjust the level volume.

  • Page 8: Day & Night

    EXPOSURE LENS DC (0~100) / MANUAL / VIDEO. (DC Lens is recommended.) SHUTTER 1/160 /1/100 / FLC / 1/250 ~ 10000 / SENS-UP x2 ~ x250 OFF / ON BLC (Back Light Compensation) HIGH / MIDDLE / LOW / OFF AGC (Auto Gain Control) MAX-DR OFF / ON (0 ~ 20) (Electronic Wide Dynamic Range)
  • Page 9 FUNCTION MIRROR OFF / MIRROR / V-FLIP / ROTATE SHARPNESS 0 ~ 31 GAMMA 0.05 ~ 1.00 / USER FREEZE OFF / ON NEGATIVE OFF/ ON OFF / LOW / MIDDLE / HIGH 3D-DNR 3D-DNR (3D Digital Noise Reduction) D-ZOOM OFF / ON (x1.0 ~ x32 PTZ) OFF / ON SLC (Side Light Compensation)
  • Page 10 PRIVACY MASK 1 OFF / ON MASK 2 OFF / ON MASK 3 OFF / ON MASK 4 OFF / ON MASK 5 OFF / ON MASK 6 OFF / ON EXIT JUMP EXIT / SAVE&EXIT / FACTORY SET SETUP CAMERA ID 0 ~ 255 TITLE...

  • Page 11: Save And Exit

    SYNC SYNC INTERNAL / AUTO V-PHASE 0 ~ 199 EXIT JUMP EXIT / SAVE & EXIT / FACTORY SET EXIT EXIT Exit the menu SAVE&EXIT Exit the menu and save the setting FACTORY SET Reset the menu setting to factory default...

  • Page 12: Specifications

    Camera TYPE Color / BW V3367WTIR SPECIFICATIONS: Mount Surface Image Device Super HAD II CCD Size 1/3" Pixels-Total 811(H) x 508 (V) Pixels-Effective 768(H) x 494 (V) Scanning System 525 line, 2:1Interlace Horizontal Frequency Internal Mode 15,734Hz Vertical Frequency Internal Mode 59.94Hz Min.
