Vandal Dome Camera
X12 Zoom V1312XW
User Manual
ABOUT MANUAL
Before installing and using the camera, please read this manual carefully.
Be sure to keep it handy for future reference.
10112011
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Digital Watchdog V1312XW
Summary of Contents for Digital Watchdog V1312XW
-
Page 1: User Manual
Vandal Dome Camera X12 Zoom V1312XW User Manual 5436 W Crenshaw St. Tampa, FL 33634 Tel: 866-446-3595 / 813-888-9555 Fax: 813-888-9262 www.Digital-Watchdog.com technicalsupport@dwcc.tv Technical Support Hours: Monday-Friday 8:30am to 8:00pm Eastern Time ABOUT MANUAL Before installing and using the camera, please read this manual carefully. -
Page 2: Table Of Contents
PRECAUTIONS Table of Contents Do not open or modify. Introduction Camera Features ■ Do not open the case except during maintenance and installation, ■ Parts and Descriptions for it may be dangerous and can cause damages. Do not put objects into the unit. ■... -
Page 3: Parts And Descriptions
FEATURES * PART & DESCRIPTIONS * 1/4" Sony Ex-View HAD Double Scan CCD ■ Lens 560 TV Lines ■ 3.6~44.3mm Varifocal Auto Iris Lens ■ Video Output Connector - BNC 12X Digital Zoom ■ Power input Connctor Electronic Day and Night with Color Removal Circuit 12VDC/24VAC Dual Voltage ■... -
Page 4: Dimensions
DIMENSIONS IN MILLIMETERS * INSTALLATION * Parts Included with DW Camera 1. USER MANUAL 5. L-WRENCH 2. MOUNTING TEMPLATE 6. TOOL - 0.89MM 3. FOUR(4) SCREW AND FOUR(4) DRy WALL ANCHORS 7. TOOL - 1.5/2.0MM 4. 2ND VIDEO JACK Required Tools (Not Included) PHILLIPS HEAD SCREWDRIVER UNITS : (MM) TOP VIEW... - Page 5 Instructions to Mount the Camera Junction Box Adapter Installation Instructions 1. Pull wires through and make connections. 2. Adjust the camera (pan, tilt, zoom). 1. Check to see all parts are 2. Use the drywall anchors 3. Insert wires through Refer to page 13.
-
Page 6: Wall Mount
Junction Box Adapter Installation Instructions Pendant Installation Instructions 1. Check to see all parts are 2. Insert the wires from the 3. Attach the camera to the 1. Check to see all parts are 2. Attach the top shield to 3. -
Page 7: Corner Mount
CONNECTING TO MONITORS * Corner Mount Installation Instructions Follow the diagram below to make proper connections to the CRT Monitor or the Monitor. 12VDC / 24VDC CCTV Monitor 1. Check to see all parts are in the box. 2. Attach the two compression fittings to the corner bracket. -
Page 8: Adjusting The 3 Axis Gimbal
ADJUSTING THE 3-AXIS GIMBAL * CONTROL BOARD * The Gimbal Mechanism yields Maximum Rotation And Placement As Shown Below. CONTROL BOARD FUNCTIONS 1. Joystick Controller - Functional control of O.S.D. (On Screen Display) 2. CON1 - Second Video Output Connector 3. - Page 9 MODULE OSD MENU AND GLOSSARY * MAIN MENU Description INTELLIGENCE Description Setting Options CAMERA SET Camera related functions and data. MOTION Motion detection function OFF / TRACKING / DETECTION INTELLIGENCE Motion detection, and more. ADVANCED Advanced Motion detection function OFF / FIXED,MOVED PRIVACy ZONE Privacy related settings MASK AREA...
-
Page 10: Warranty Information
WARRANTY INFORMATION * TROUBSHOOTING Before sending your camera for repair, check the following or contact our technical specialist. Digital Watchdog (referred to as “the Warrantor”) No VIDEO warrants the Camera Series against defects in Check the coaxial cable and make sure it is connected securely. -
Page 11: Specifications
LIMITS AND EXCLUSIONS * SPECIFICATIONS * There are no express warranties except as listed above. The Warrantor will not be liable for incidental or consequential ITEMS SUB-ITEMS X12_ZOOM_N damages (including, without limitation, damage to recording media) Device SONy 1/4” ExView-HAD PS CCD(ICX-448) resulting from the use of these products, or arising out of any breach Total 811 x 508... - Page 12 MEMO Off/On (Area Setting) Off/On (Max.Level Setting) ALC(Auto Level Control) Auto(DC)/Manual (Level Control) Line Lock Off/On (Phase Control) Camera ID Off/On (Max. 54ea/2Line) ATW1/ATW2/AWC/MANUAL White Balance (ATW1 : 2,500 ~ 9,500°K, ATW2 : 2,000 ~ 10,000°K) Off/On (Adaptive 3D+2D) Off/On PRESET Off/On (256ea Off/On (x128/NTSC, x160/PAL)
