Specifications - Digital Watchdog DWC-PTZ12x Specifications

700TVL
3.8~45.6mm
High Resolution
Auto Focus Lens
Summary
The PTZ12X is a powerful Mini-PTZ that produces clear and precise 700TVL
images during the day and 750TVL images during the night. It offers image
enhancing features like Wide Dynamic Range, Star-Light Low Light
Technology, and 3D Digital Noise Reduction. The Digital Watchdog 12X
PTZ camera will lead the market in performance, size, flexibility, reliability,
and cost.
Features
1/4" Sony Super HAD (Double Scan) CCD II
•
750 TV Lines [B&W], 700 TV Lines [Color]
•
3.8~45.6mm Autofocus Lens
•
12X Optical Zoom, 32X Digital Zoom
•
Auto Day and Night with IR Cut Filter
•
WDR (Wide Dynamic Range)
•
3D-DNR (3D Digital Noise Reduction)
•
Star-Light (Super Low Light Technology)
•
DSS (Digital Slow Shutter)
•
Programmable Privacy Zones (8) & Motion Detection
•
Pan 0~360 o Endless; 360 o Per Second Pan Speed
•
Vector Drive Technology (Pan/Tilt in Shortest Path)
•
128 Preset Positions with Alphanumeric Labels
•
4 Patterns, 8 Scans, and 8 Groups
•
RS-485 Communication
•
IP66 Certified (Weatherproof)
•
Heater and Fan Built-in
•
Sunshield Cover (Optional)
•
Accessories (Optional)
DWC-P12WM DWC-P12CM
Indoor Wall Mount Indoor Ceiling Mount
DWC-P39CNM DWC-P39POLM
Corner Mount Pole Mount
Pan Tilt Zoom Dome PTZ12X
DWC-P12WMS DWC-P12CMS
Sunshield Wall Mount Sunshield Ceiling Mount
Dimensions (unit : mm)
115(4.5")
66.5
(2.61")
60.8
(2.4")
¾"NPT
35.0
(1.37")
165(6.5")

Specifications

VIDEO
Image Sensor
Effective Pixels
Horizontal Resolution
Minimum Illumination
S/N Ratio
Video Output
LENS
Focal Length
Focus
Zoom
OPERATIONAL
Digital Slow Shutter
3D Digital Noise Reduction
Wide Dynamic Range
Day and Night
Auto Gain Control
White Balance
Motion Detection
Privacy Zones
Highlight Compensation
PAN / TILT
Range
Speed
Presets
Scans
Patterns
Groups
Schedules
GENERAL
Sensor In / Out
Operating Temperature
Approvals
Power Requirement
Power Consumption
Housing Material
Bubble Dome Material
Dimensions
Weight
¾"NPT
46(1.8")
1/4" Sony Super HAD (Double Scan) CCD II
1028 (H) x 508 (V), 520K
750 TV Lines [B&W], 700 TV Lines [Color]
Color: 0.5 Lux, 0.001 Lux [DSS ON]
B&W: 0.2 Lux, 0.0004 Lux [DSS OFF]
50dB (AGC off)
CVBS: 1.0Vp-p / 75 Ω
F1.6 (W) ~ F2.7(T)
f = 3.8mm (W) ~ 45.6mm (T)
Auto / Semi-Auto / Manual
12X Optical, 32X Digital
x2 ~ x512 / 1/60 ~ 1/100000
OFF / ON
OFF / ON
AUTO / DAY / NIGHT
AUTO / MANUAL / MAX GAIN LIMIT
ATW / AWC / MANUAL / INDOOR / OUTDOOR / OUT. AUTO
Available
OFF / ON (8 Programmable Zones)
OFF / ON
Pan: 360 o Endless
Tilt: 180 o (Auto-Flip On), 90 o (Auto-Flip Off)
360 o /sec for Presets; 1~180 o /sec for Scans;
0.05~360 o /sec for Manual Adjustments
128 with Alphanumeric Labels
8
4 (1000 Commands/Pattern)
8 (20 Actions/Group)
7
2 In / 1 Out
-10oC ~ 50oC (14oF ~ 122oF)
FCC, CE, RoHS,
IP66 (Protects against dust and high pressure water.)
Dual (12VDC & 24VAC)
12VDC: 12W, 1A , Fan ON: 1.63A, Fan+Heater ON: 2.5A
24VAC: 12W, 500mA, Fan ON: 1A, Fan+Heater ON: 1.5A
Aluminum Die-casting
Polycarbonate
165 x 162.3 mm (6.5 x 6.39 in)
6.61 lbs , 3kg
