S
®
UPER
SuperServer 6026TT-HTF
SuperServer 6026TT-HTRF
SuperServer 6026TT-HIBXF
SuperServer 6026TT-HIBXRF
SuperServer 6026TT-HIBQF
SuperServer 6026TT-HIBQRF
USER'S MANUAL
Revision 1.0c

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SuperServer 6026TT-HTF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Supero SuperServer 6026TT-HTF

Summary of Contents for Supero SuperServer 6026TT-HTF

  • Page 1 ® UPER SuperServer 6026TT-HTF SuperServer 6026TT-HTRF SuperServer 6026TT-HIBXF SuperServer 6026TT-HIBXRF SuperServer 6026TT-HIBQF SuperServer 6026TT-HIBQRF USER’S MANUAL Revision 1.0c...
  • Page 2 The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.

  • Page 3: About This Manual

    Preface Preface About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SuperServer 6026TT-HT(R) F/HIBX(R)F/HIBQ(R)F. Installation and maintenance should be performed by experienced technicians only. The SuperServer SuperServer 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F is a 2U Twin (four serverboards/nodes in a 2U chassis) rackmount server based on the SC827H- (R)1400B server chassis and four Super X8DTT-HF/X8DTT-HIBXF/X8DTT-HIBQF serverboards.
  • Page 4 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Chapter 3: System Interface Refer to this chapter for details on the system interface, which includes the functions and information provided by the control panel on the chassis as well as other LEDs located throughout the system. Chapter 4: System Safety You should thoroughly familiarize yourself with this chapter for a general overview of safety precautions that should be followed when installing and servicing the...
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Table of Contents Chapter 1 Introduction Overview ......................1-1 Serverboard Features ..................1-2 Processors ...................... 1-2 Memory ......................1-2 Serial ATA ......................1-2 PCI Expansion Slots ..................1-2 Ethernet Ports ....................1-3 Onboard Controllers/Ports ................1-3 Graphics Controller ..................
  • Page 7 Table of Contents Removing the Protective Film ................. 2-4 Rack Mounting Instructions ................2-5 Separating the Sections of the Rack Rails ............. 2-5 Installing the Inner Rail Extensions ..............2-6 Outer Rack Rails ..................... 2-7 Checking the Serverboard Setup ..............2-9 Preparing to Power On .................
  • Page 8 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual X8DTT-F/X8DTT-IBXF/X8DTT-IBQF Quick Reference ........ 5-14 Connector Defi nitions ..................5-15 5-10 Jumper Settings .................... 5-20 5-11 Onboard Indicators ..................5-22 5-12 Installing Additional Drivers ................5-24 5-13 Confi guring Supero Doctor III ............... 5-25 Chapter 6 Advanced Chassis Setup Static-Sensitive Devices ..................
  • Page 9 Table of Contents Appendix A BIOS Error Beep Codes BIOS Error Beep Codes ................. A-1 Appendix B Installing Windows Installing Windows for a RAID System ............B-1 Installing Windows for a Non-RAID System ........... B-2 Appendix C System Specifi cations...
  • Page 10 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Notes...

  • Page 11: Chapter 1 Introduction

    Chapter 1: Introduction Chapter 1 Introduction Overview The SuperServer 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F is a "2U Twin " server com- prised of the SC827H-(R)1400B 2U chassis and four X8DTT-HF/X8DTT-HIBXF/ X8DTT-HIBQF serverboards. Please refer to our web site for information on oper- ating systems that have been certifi ed for use with the 6026TT (www.supermicro. com).

  • Page 12: Serverboard Features

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Serverboard Features At the heart of the SuperServer 6026TT are four X8DTT-HF/X8DTT-HIBXF/X8DTT- HIBQF dual processor serverboards, which are based on Intel's 5520 (North Bridge) + ICH10R (South Bridge) chipset. Below are the main features of the serverboards. Note that the features on each board are quadrupled for the server, which includes four nodes.

  • Page 13: Ethernet Ports

    Chapter 1: Introduction Ethernet Ports An Intel® network controller is integrated into each of the serverboards to support two Gigabit LAN ports (100/1000Base-T/1000BaseTX, RJ45 output). Onboard Controllers/Ports Onboard I/O backpanel ports on each serverboard include one COM port, a VGA port, two USB ports, a dedicated IPMI LAN port and two Gigabit LAN (NIC) ports.
  • Page 14 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual PROCESSOR#0 PROCESSOR#1 Intel 82574 MT25408 Connect-X IB QSFP PCI-E Gen2/DDR or QDR (For 36D Only) Intel 5520/5500 82574 36-D/24-D PCI-E x16 Slot AT25 DF321 ICH10R 4 SATA Hotswap Connector LPCIO W83527 BMC/VGA RMII VGA CONN RTL8201N PHY Dedicated LAN Figure 1-1.

  • Page 15: Server Chassis Features

    Chapter 1: Introduction Server Chassis Features The following is a general outline of the main features of the SC827H-(R)1400B 2U chassis. Details on the chassis can be found in Chapter 6. System Power When confi gured as a SuperServer 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F, the SC827H-(R)1400B includes a single 1400W power supply, which provides power to all four serverboards (nodes).

  • Page 16: Twin 2 : System Notes

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual 2U Twin : System Notes As a 2U Twin confi guration, the 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F is a unique server system. With four system boards incorporated into a single chassis acting as four separate nodes, there are several points you should keep in mind. Nodes Each of the four serverboards act as a separate node in the system.

  • Page 17: Contacting Supermicro

    Chapter 1: Introduction Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML 's-Hertogenbosch, The Netherlands Tel:...
  • Page 18 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Notes...

  • Page 19: Chapter 2 Server Installation

    Chapter 2: Server Installation Chapter 2 Server Installation Overview This chapter provides a quick setup checklist to get the 6026TT-HT(R)F/HIBX(R)F/ HIBQ(R)F up and running. Following these steps in the order given should enable you to have the system operational within a minimum amount of time. This quick setup assumes that your system has come to you with the processors and memory preinstalled.

  • Page 20: Choosing A Setup Location

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Choosing a Setup Location • Leave enough clearance in front of the rack to enable you to open the front door completely (~25 inches). • Leave approximately 30 inches of clearance in the back of the rack to allow for suffi...

  • Page 21: Rack Mounting Considerations

    Chapter 2: Server Installation • Allow the hot plug SATA drives and power supply modules to cool before touch- ing them. • Always keep the rack's front door and all panels and components on the servers closed when not servicing to maintain proper cooling. •...

  • Page 22: Removing The Protective Film

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Removing the Protective Film Before operating the 6026TT server for the fi rst time, it is important to remove the protective fi lm covering the top of the chassis, in order to allow for proper ventila- tion and cooling.

  • Page 23: Rack Mounting Instructions

    Chapter 2: Server Installation Rack Mounting Instructions This section provides information on installing the SC827 chassis into a rack unit with the quick-release rails provided. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly. You should also refer to the installation instructions that came with the rack unit you are using.

  • Page 24: Installing The Inner Rail Extensions

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Installing the Inner Rail Extensions The SC827 chassis includes a set of inner rails in two sections: inner rails and inner rail extensions. The inner rails are pre-attached to the chassis, and do not interfere with normal use of the chassis if you decide not to use a server rack. The inner rail extension is attached to the inner rail to mount the chassis in the rack.

  • Page 25: Outer Rack Rails

    Chapter 2: Server Installation Figure 2-4: Assembling the Outer Rails Outer Rack Rails Outer rails attach to the rack and hold the chassis in place. The outer rails for the SC827 chassis extend between 30 inches and 33 inches. Installing the Outer Rails to the Rack Secure the back end of the outer rail to the rack, using the screws provided.
  • Page 26 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Figure 2-5: Installing Into the Rack Installing the Chassis into a Rack Extend the outer rails as illustrated above. Align the inner rails of the chassis with the outer rails on the rack. Slide the inner rails into the outer rails, keeping the pressure even on both sides.

  • Page 27: Checking The Serverboard Setup

    Chapter 2: Server Installation Checking the Serverboard Setup After you install the system in the rack, you will need to access the inside of the nodes to make sure the serverboard is properly installed. Accessing the Inside of a Node (Figure 2-6) Before removing a node, unplug all the cables that connect to that node.

  • Page 28: Preparing To Power On

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Preparing to Power On Next, you should check to make sure the SATA drives and SATA backplane have been properly installed and all connections have been made. Checking the SATA drives The SATA disk drives are accessable from the front of the server and can be installed and removed from the front of the chassis without removing the top chassis cover.
  • Page 29 Chapter 2: Server Installation Figure 2-6. Removing a Node from the System 2-11...
  • Page 30 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Notes 2-12...

  • Page 31: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview There are LEDs on the control panels and on the SATA drive carriers to keep you constantly informed of the overall status of the system as well as the activity and health of specifi...

  • Page 32: Control Panel Leds

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Control Panel LEDs In addition to the LEDs built into the power and UID buttons, each of the four control panels located on the front of the SC827H-(R)1400B chassis has two LEDs that provide you with critical information related their own node. This section explains what each LED indicates when illuminated and any corrective action you may need to take.

  • Page 33: Chapter 4 System Safety

    Chapter 4: System Safety Chapter 4 System Safety Electrical Safety Precautions Basic electrical safety precautions should be followed to protect yourself from harm and the SuperServer 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F from damage: • Be aware of the locations of the power on/off switch on the chassis as well as the room's emergency power-off switch, disconnection switch or electrical outlet.

  • Page 34: General Safety Precautions

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual • This product may be connected to an IT power system. In all cases, make sure that the unit is also reliably connected to Earth (ground). • Serverboard Battery: CAUTION - There is a danger of explosion if the onboard battery is installed upside down, which will reverse its polarites (see Figure 4-1).

  • Page 35: Esd Precautions

    Chapter 4: System Safety • Remove any jewelry or metal objects from your body, which are excellent metal conductors that can create short circuits and harm you if they come into contact with printed circuit boards or areas where power is present. •...

  • Page 36: Operating Precautions

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Operating Precautions Care must be taken to assure that the chassis cover is in place when the 6026TT- HT(R)F/HIBX(R)F/HIBQ(R)F is operating to assure proper cooling. Out of warranty damage to the system can occur if this practice is not strictly followed. Figure 4-1.

  • Page 37: Chapter 5 Advanced Serverboard Setup

    Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to install the X8DTT-F/X8DTT-IBXF/X8DTT- IBQF serverboard into the SC827H-(R)1400B chassis, connect the data and power cables and install add-on cards. All serverboard jumpers and connections are also described.

  • Page 38: Unpacking

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Unpacking The serverboard is shipped in antistatic packaging to avoid electrostatic discharge. When unpacking the board, make sure the person handling it is static protected. Serverboard Installation This section explains the fi rst step of physically mounting the X8DTT-F/X8DTT-IBXF/ X8DTT-IBQF into the SC827H-(R)1400B chassis.

  • Page 39: Connecting Cables

    Chapter 5: Advanced Serverboard Setup Warning: To avoid damaging the motherboard and its components, do not apply any force greater than 8 lbs. per square inch when installing a screw into a mounting hole. Connecting Cables Now that the serverboards are installed, the next step is to connect the cables to the boards.

  • Page 40: I/O Ports

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Figure 5-1. Control Panel Header Pins Ground x (Key) x (Key) Power On LED 3.3V HDD LED Front UID Button NIC1 LED (Link) NIC1 LED (Activity) NIC2 LED (Link) NIC2 LED (Activity) OH/Fan Fail/Pwr Fail/UID LED UID LED Power Fail LED 3.3V...

  • Page 41: Processor And Heatsink Installation

    Chapter 5: Advanced Serverboard Setup Processor and Heatsink Installation When handling the processor package, avoid placing direct pressure on the label area of the fan. Notes: • Always connect the power cord last and always remove it before adding, re- moving or changing any hardware components.
  • Page 42 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual After removing the plastic cap, use your thumb and the index fi nger to hold the CPU at the north and south center edges. Align the CPU key (the semi-circle cutout) with the socket key (the notch below the gold color dot on the side of the socket).

  • Page 43: Installing A Cpu Heatsink

    Chapter 5: Advanced Serverboard Setup Installing a CPU Heatsink Remove power from the system and unplug the AC power cord from the power supply. Do not apply any thermal grease Screw #1 Screw #2 to the heatsink or the CPU die; the required amount has already been applied.

  • Page 44: Removing The Heatsink

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Removing the Heatsink Warning! We do not recommend that the CPU or the heatsink be removed. However, if you do need to uninstall the heatsink, please follow the instruc- tions below to prevent damage to the CPU or the CPU socket. Remove power from the system and unplug the AC power cord from the power supply.

  • Page 45: Installing Memory

    Chapter 5: Advanced Serverboard Setup Installing Memory CAUTION! Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Memory Support Each X8DTT-F/X8DTT-IBXF/X8DTT-IBQF has six 240-pin DIMM slots that can support up to 96 GB of registered ECC DDR3-1333/1066/800 SDRAM (for a total of 192 GB in the system) or up to 48 GB of unbuffered ECC/non-ECC DDR3- 1333/1066/800 SDRAM (for a total of 96 GB in the system).
  • Page 46 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual DIMM Population Table DIMM DIMMs DIMM Type (Reg.= Speeds (in MHz) Ranks per DIMM Slots per Populated Registered) (any combination; Channel per Channel SR=Single Rank, DR=Dual Rank, QR=Quad Rank) Reg. DDR3 ECC 800,1066,1333 SR, DR Reg. DDR3 ECC 800,1066, Reg.
  • Page 47 Chapter 5: Advanced Serverboard Setup 1.5V RDIMM Population with 5600 Processors Installed DIMM DIMMs DIMM Type (Reg.= Speeds (in MHz) Ranks per DIMM Slots per Populated Registered) (any combination; Channel per Channel SR=Single Rank, DR=Dual Rank, QR=Quad Rank) Reg. DDR3 ECC 800,1066,1333 SR or DR Reg.

  • Page 48: Adding Pci Cards

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Due to the memory allocation to system devices, the amount of memory that remains available for operational use will be reduced when 4 GB of RAM is used. The reduction in memory availability is disproportional. Refer to the table below. Possible System Memory Allocation &...

  • Page 49: Serverboard Details

    Chapter 5: Advanced Serverboard Setup Serverboard Details Figure 5-4. X8DTT Series Motherboard Layout COM1 USB0/1 InfiniBand JNMI1 Connector JWD1 LAN2 LAN1 IPMI_LAN JPG1 Nuvoton InfiniBand CTRL WPCM450 LAN CTRL JWOL1 JBT1 Intel ICH-10R Intel (South Bridge) 5520/5500 BIOS (North Bridge) JBAT1 Battery X8DTT Series...

  • Page 50: Superserver 6026Tt-Ht(R)F/Hibx(R)F/Hibq(R)F User's Manual

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual X8DTT-F/X8DTT-IBXF/X8DTT-IBQF Quick Reference Jumper Description Default Setting JBMC1 BMC Enable/Disable Pins 1-2 (Enabled) JBT1 CMOS Clear (See Section 5-10) JPEN1 Normal Power Enable Pins 1-2 (Enabled) JPG1 VGA Enable/Disable Pins 1-2 (Enabled) JPL1 LAN1/2 Enable/Disable Pins 1-2 (Enabled) J_UID_OW Red LED Overwrite Open (Overwrite)

  • Page 51: Connector Defi Nitions

    Chapter 5: Advanced Serverboard Setup Connector Defi nitions ATX Power 20-pin Connector Pin Defi nitions (ATX Power 1/2) Pin# Defi nition Pin # Defi nition ATX Power Connector PS On Ground The main ATX power supply connectors on 5VSB Ground the X8DTT-F/X8DTT-IBXF/X8DTT-IBQF are Ground Ground...
  • Page 52 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Power Fail LED PWR Fail LED Pin Defi nitions The Power Fail LED connection is located (JF1) on pins 5 and 6 of JF1. Refer to the table Pin# Defi nition on the right for pin defi nitions. 3.3V PWR Fail LED Overheat/Fan Fail/PWR Fail/UID LED...
  • Page 53 Chapter 5: Advanced Serverboard Setup HDD LED HDD LED Pin Defi nitions The HDD LED and UID switch connections (JF1) are located on pins 13 and 14 of JF1. Attach Pin# Defi nition a hard drive LED cable here to display disk UID Signal/3.3V activity.
  • Page 54 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Universal Serial Bus (USB) USB Ports Pin Defi nitions Two Universal Serial Bus ports are located (USB0/1/4) on the I/O panel. Two USB headers are Pin# Defi nition located on the serverboard and can be used to provide front side USB access (cables not included).
  • Page 55 Chapter 5: Advanced Serverboard Setup SMB (I C) Connector PWR SMB Pin Defi nitions System Management Bus (I C) Connector Pin# Defi nition (J18) monitors power supply, fan and system Clock temperatures. See the table on the right for Data pin defi...

  • Page 56: 5-10 Jumper Settings

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual 5-10 Jumper Settings Connector To modify the operation of the serverboard, Pins jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function Jumper of the connector. Pin 1 is identifi ed with a square solder pad on the printed circuit board.
  • Page 57 Chapter 5: Advanced Serverboard Setup LAN1/LAN2 Enable/Disable LAN1/2 Enable/Disable Jumper Settings Change the setting of jumper JPL1 to enable Jumper Setting Defi nition or disable the LAN1 and LAN2 ports. See the Pins 1-2 Enabled table on the right for jumper settings. The Pins 2-3 Disabled default setting is enabled.

  • Page 58: 5-11 Onboard Indicators

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual VGA Enable/Disable VGA Enable/Disable Jumper Settings (JPG1) JPG1 allows you to enable or disable the Jumper Setting Defi nition VGA port. The default position is on pins 1 Pins 1-2 Enabled and 2 to enable VGA. See the table on the Pins 2-3 Disabled right for jumper settings.
  • Page 59 Chapter 5: Advanced Serverboard Setup Onboard Power LED Onboard PWR LED Indicator Settings The LE1 LED is to indicate the system power LED Color Defi nition is on. Be sure to turn off the system and System Off (PWR cable unplug the power cord before removing or not connected) installing components.

  • Page 60: 5-12 Installing Additional Drivers

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual 5-12 Installing Additional Drivers After you've installed the Windows Operating System, a screen as shown below will appear. You are ready to install software programs and drivers that have not yet been installed. To install these software programs and drivers, click the icons to the right of these items.

  • Page 61: Confi Guring Supero Doctor Iii

    Chapter 5: Advanced Serverboard Setup 5-13 Confi guring Supero Doctor III The Supero Doctor III program is a web-based management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called the SD III Client. The Supero Doctor III program included on the CDROM that came with your motherboard allows you to monitor the environment and operations of your system.
  • Page 62 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Note: SD III Software Revision 1.0 can be downloaded from our Web site at: ftp:// ftp.supermicro.com/utility/Supero_Doctor_III/. You can also download SDIII User's Guide at:http://www.supermicro.com/manuals/other/SDIII_User_Guide.pdf. For Linux, we will still recommend that you use Supero Doctor II. 5-26...

  • Page 63: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform main- tenance on the SC827H-(R)1400B chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the step that follows.

  • Page 64: Control Panel

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Figure 6-1. Chassis Front View Node B Control Panel Node D Control Panel SATA Drives Node A Control Panel Node C Control Panel Figure 6-2. Chassis Rear View Dedicated IPMI LAN Port Dedicated IPMI LAN Port PCI-Express x16 Slot Power Supply** LAN Ports...

  • Page 65: Fan Confi Guration

    Chapter 6: Advanced Chassis Setup Fan Confi guration In the 2U Twin , each node (serverboard) controls the two fans that reside on its side of the chassis. This means that two nodes will share control for two fans. If the fan speed settings in BIOS are different for these two nodes, the BIOS setting with the higher fan speed will apply.

  • Page 66: Hard Drive Installation/Removal

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Hard Drive Installation/Removal Overview The hard drives are mounted in drive carriers to simplify their installation and removal from the chassis. These carriers also help promote proper airfl ow for the system. For this reason, even empty carriers without drives installed must remain in the chassis.
  • Page 67 Chapter 6: Advanced Chassis Setup Figure 6-3. Removing a Dummy Drive Tray Figure 6-4. Mounting a Hard Drive in a Carrier Hard Drive Drive Tray Installing/Removing Hot-swap Drives To remove a carrier, push the release button located beside the drive LEDs. Swing the handle fully out and use it to pull the unit straight out (see Figure 6-5).
  • Page 68 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Figure 6-5. Removing a Hard Drive Figure 6-6. Drives and Nodes: Logical Confi guration Note: see Figure 6-1 for the locations of the control panels that are associated with each node.

  • Page 69: Node Installation/Removal

    Chapter 6: Advanced Chassis Setup Node Installation/Removal As with any server system, power must be removed from the serverboard when upgrading or installing memory or processors. In the 2U Twin server, the server- boards (nodes) are capable of being hot-swapped from the chassis, allowing one to be powered down for servicing while the others continue operating.
  • Page 70 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Figure 6-7. Removing a System Node...

  • Page 71: Installing The Air Shrouds

    Chapter 6: Advanced Chassis Setup Installing the Air Shrouds Air Shrouds Air shrouds concentrate airfl ow to maximize fan effi ciency. The SC827 chassis air shroud does not require screws to set up. Four identical air shrouds are required, one in each serverboard drawer. Installing an Air Shroud Confi...

  • Page 72: Power Supply Failure: Redundant Power (Two Modules)

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Push the new power supply module into the power bay until you hear a click. Reconnect the AC power cord and depress the power button on the control panel to restart the system. Power Supply Failure: Redundant Power (Two Modules) The SuperServer 6026TT-BTRF/6026TT-BIBXRF/6026TT-BIBQRF has two1400 watt power supply modules to provide redundant power for the system.
  • Page 73 Chapter 6: Advanced Chassis Setup Figure 6-8. Removing the Power Supply Release Tab 6-11...
  • Page 74 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Notes 6-12...

  • Page 75: Chapter 7 Bios

    Chapter 7: BIOS Chapter 7 BIOS Introduction This chapter describes the AMI BIOS Setup Utility for the X8DTT-H/-HF/-HIBX/- HIBXF/-HIBQ/-HIBQF. The AMI ROM BIOS is stored in a Flash EEPROM and can be easily updated. This chapter describes the basic navigation of the AMI BIOS Setup Utility setup screens.

  • Page 76: Starting The Setup Utility

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Starting the Setup Utility Normally, the only visible Power-On Self-Test (POST) routine is the memory test. As the memory is being tested, press the <Delete> key to enter the main menu of the AMI BIOS Setup Utility. From the main menu, you can access the other setup screens.
  • Page 77 Chapter 7: BIOS Day MM/DD/YY format. The time is entered in HH:MM:SS format. (Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00.) Supermicro X8DTT/-F/-IBX/-IBXF/-IBQ/-IBQF BIOS Build Version This item displays the BIOS revision used in your system. BIOS Build Date This item displays the date when this BIOS was completed.

  • Page 78: Advanced Setup Confi Gurations

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Advanced Setup Confi gurations Use the arrow keys to select Boot Setup and hit <Enter> to access the submenu items: BOOT Features Quick Boot If Enabled, this option will skip certain tests during POST to reduce the time needed for system boot.

  • Page 79: Processor And Clock Options

    Chapter 7: BIOS Hit 'Del' Message Display This feature displays "Press DEL to run Setup" during POST. The options are Enabled and Disabled. Interrupt 19 Capture Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Enabled, the ROM BIOS of the host adaptors will "capture"...
  • Page 80 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual C1E Support Select Enabled to use the feature of Enhanced Halt State. C1E signifi cantly reduces the CPU's power consumption by reducing the CPU's clock cycle and voltage during a "Halt State." The options are Disabled and Enabled. Hardware Prefetcher (Available when supported by the CPU) If set to Enabled, the hardware pre fetcher will pre fetch streams of data and instruc- tions from the main memory to the L2 cache in the forward or backward manner to...

  • Page 81: Advanced Chipset Control

    Chapter 7: BIOS tion and heat dissipation. Please refer to Intel’s web site for detailed information. The options are Disable (Disable GV3) and Enable (Enable GV3). Intel® TurboMode Technology Select Enabled to use the Turbo Mode to boost system performance. The options are Enabled and Disabled.
  • Page 82 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual QPI L0s and L1 This enables the QPI power state to low power. L0s and L1 are automatically selected by the motherboard. The options are Disabled and Enabled. Memory Frequency This feature forces a DDR3 frequency slower than what the system has detected. The available options are Auto, Force DDR-800, Force DDR-1066, and Force DDR-1333.
  • Page 83 Chapter 7: BIOS Throttling - Closed Loop/Throttling - Open Loop Throttling improves reliability and reduces power in the processor by automatic voltage control during processor idle states. Available options are Disabled and Enabled. If Enabled, the following items will appear: Hysteresis Temperature Temperature Hysteresis is the temperature lag (in degrees Celsius) after the set DIMM temperature threshold is reached before Closed Loop Throttling...
  • Page 84 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual North Bridge Confi guration This feature allows the user to confi gure the settings for the Intel IOH chip. Crystal Beach/DMA (Direct Memory Access) This feature works with the Intel I/O AT (Acceleration Technology) to accelerate the performance of TOE devices.
  • Page 85 Chapter 7: BIOS USB 2.0 Controller Select Enabled to activate the onboard USB 2.0 controller. The options are Enabled and Disabled. USB 2.0 Controller Mode This setting allows you to select the USB 2.0 Controller mode. The options are Hi-Speed (480 Mbps) and Full Speed (12 Mbps). BIOS EHCI Hand-Off Select Enabled to enable BIOS Enhanced Host Controller Interface support to provide a workaround solution for an operating system that does not have EHCI...
  • Page 86 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Hot Plug (This feature is available when the option-Enabled is selected) Select Enable to enable the hot plug function for the SATA devices. The options are Enabled and Disabled. SATA#2 Confi guration Selecting Enhanced will set SATA#2 to native SATA mode. The options are Disabled, and Enhanced.
  • Page 87 Chapter 7: BIOS Select 0 to allow the AMI BIOS to use PIO mode 0. It has a data transfer rate of 3.3 MB/s. Select 1 to allow the AMI BIOS to use PIO mode 1. It has a data transfer rate of 5.2 MB/s.
  • Page 88 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Select UDMA5 to allow the BIOS to use Ultra DMA mode 5. It has a data transfer rate of 133 MB/s. Select UDMA6 to allow the BIOS to use Ultra DMA mode 6. It has a data transfer rate of 133 MB/s.
  • Page 89 Chapter 7: BIOS Load Onboard LAN1 Option ROM/Load Onboard LAN2 Option ROM Select Enabled to enable the onboard LAN1 or LAN2 Option ROM. This is to boot computer using a network interface. The options are Enabled and Disabled. Super IO Device Confi guration Serial Port1 Address/ Serial Port2 Address This option specifi...

  • Page 90: Hardware Health Monitor

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Terminal Type This feature allows the user to select the target terminal type for Console Redirec- tion. The options are ANSI, VT100, and VT-UTF8. VT-UTF8 Combo Key Support A terminal keyboard defi nition that provides a way to send commands from a remote console.
  • Page 91 Chapter 7: BIOS CPU Temperature/System Temperature This feature displays current temperature readings for the CPU and the System. The following items will be displayed for your reference only: CPU Temperature The CPU thermal technology that reports absolute temperatures (Celsius/Fahr- enheit) has been upgraded to a more advanced feature by Intel in its newer processors.
  • Page 92 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual User intervention: If the system buzzer and Overheat LED has activated, take action immediately by checking the system fans, chassis ventilation and room temperature to correct any problems. Notes: The system may shut down if it continues for a long period to prevent damage to the CPU.
  • Page 93 Chapter 7: BIOS APIC ACPI SCI IRQ When this item is set to Enabled, APIC ACPI SCI IRQ is supported by the system. The options are Enabled and Disabled. Headless Mode This feature is used to enable system to function without a keyboard, monitor or mouse attached The options are Enabled and Disabled.
  • Page 94 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual View BMC System Event Log This feature displays the BMC System Event Log (SEL). It shows the total num- ber of entries of BMC System Events. To view an event, select an Entry Number and pressing <Enter> to display the information as shown in the screen. •...
  • Page 95 Chapter 7: BIOS IP Address Source Select the source of this machine's IP address. If Static is selected, you will need to know and enter manually the IP address of this machine below. If DHCP is selected, the BIOS will search for a DHCP (Dynamic Host Confi guration Protocol) server in the network it is attached to, and request the next available IP address.
  • Page 96 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Subnet Mask This item displays the current subnet mask setting for your IPMI connection. Current Subnet Mask in BMC This item displays the current subnet mask used for your IPMI connection. Gateway Address Confi guration Enter the gateway address for this machine. This should be in decimal and in dotted quad form (i.e., 192.168.10.253).

  • Page 97: Security Settings

    Chapter 7: BIOS DMI Event Log View Event Log Use this option to view the System Event Log. Mark all events as read This option marks all events as read. The options are OK and Cancel. Clear event log This option clears the Event Log memory of all messages. The options are OK and Cancel.

  • Page 98: Boot Confi Guration

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Password Check This item allows you to check a password after it has been entered. The options are Setup and Always. Boot Sector Virus Protection When Enabled, the AMI BOIS displays a warning when any program (or virus) is- sues a Disk Format command or attempts to write to the boot sector of the hard disk drive.
  • Page 99 Chapter 7: BIOS Hard Disk Drives This feature allows the user to specify the boot sequence from all available hard disk drives. The settings are Disabled and a list of all hard disk drives that have been detected (i.e., 1st Drive, 2nd Drive, 3rd Drive, etc). •...

  • Page 100: Exit Options

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Exit Options Select the Exit tab from the AMI BIOS Setup Utility screen to enter the Exit BIOS Setup screen. Save Changes and Exit When you have completed the system confi guration changes, select this option to leave the BIOS Setup Utility and reboot the computer, so the new system con- fi...

  • Page 101: How To Recover The Amibios Image (-The Main Bios Block)

    Chapter 7: BIOS How to Recover the AMIBIOS Image (-the Main BIOS Block) An AMIBIOS fl ash chip consists of a boot sector block, and a main BIOS code block (a main BIOS image). The boot sector block contains critical BIOS code, including memory detection and recovery code to be used to fl...

  • Page 102: Boot Sector Recovery From A Serial Port ("Serial Flash")

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Boot Sector Recovery from a Serial Port ("Serial Flash") This process, also known as "Serial Flash," allows the user to use a serial port to load a BIOS image for Boot Sector recovery. This feature is usually used for embed- ded systems that rely on a serial port for remote access and debugging.
  • Page 103 Chapter 7: BIOS 4. Power on your system and click the <Connect> button in the Hyper Terminal. The terminal screen will display the following messages. 5. Following the instructions given on the screen to update the BIOS. These instructions are also shown below. a.
  • Page 104 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual 6. Once you've completed the instructions given, a screen will display to indicate that remote fl ashing is starting and the new BIOS fi le is being uploaded. 7. To use Hyper Terminal to transfer the XModem protocol by using the "Send File"...

  • Page 105: Appendix A Bios Error Beep Codes

    Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 106 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Notes...

  • Page 107: Appendix B Installing Windows

    Appendix B: Installing Windows Appendix B Installing Windows After all hardware components have been installed, you must fi rst confi gure Intel South Bridge RAID Settings before you install the Windows OS and other software drivers. To confi gure RAID settings, please refer to RAID Confi guration User Guides posted on our web site at www.supermicro.com/support/manuals.

  • Page 108: B-2 Installing Windows For A Non-Raid System

    SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual B-2 Installing Windows for a Non-RAID System Insert Microsoft's Windows XP/2003 Setup CD in the CD drive and the system will start booting up from CD. Continue with the OS installation. The Windows OS Setup screen will display. From the Windows XP/2003 Setup screen, press the <Enter>...

  • Page 109: Appendix C System Specifi Cations

    Appendix C: System Specifi cations Appendix C System Specifi cations Note: unless noted specifi cations apply to a complete system (four server- boards). Processors Eight Intel® 5500/5600 Series processors in LGA1366 sockets Note: Please refer to our website for details on supported processors. Chipset Intel 5520/ICH10R BIOS...
  • Page 110 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Serverboard 6026TT-HT(R)F: X8DTT-HF 6026TT-HIBX(R)F: X8DTT-HIBXF 6026TT-HIBQ(R)F: X8DTT-HIBQF Dimensions (all): 16.64" (L) x 6.80" (W) (422.66 mm x 172.72 mm) Chassis SC827H-(R)1400B (2U Rackmount) Dimensions: (WxHxD) 17.2 x 3.5 x 28.5 in. (437 x 89 x 724 mm) Weight Gross Weight: 85 lbs.
  • Page 111 Appendix C: System Specifi cations Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55022 Class A, EN 61000-3-2/- 3-3, CISPR 22 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe) California Best Management Practices Regulations for Perchlorate Materials:...
  • Page 112 SUPERSERVER 6026TT-HT(R)F/HIBX(R)F/HIBQ(R)F User's Manual Notes (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency com- munication devices or other critical systems whose failure to perform be reasonably expected to result in signifi...
