MuxLab VideoEase 500300 Specifications

Overview

The CATV Distribution Hub allows terrestrial broadband
RF video to be distributed to multiple RF receivers via
Cat5 unshielded twisted pair cable and is available in an
8-port or 16-port configuration.
standard CATV channels, digital cable and broadband
Internet.
The CATV Hub also features built-in gain amplification,
port buffering and works in conjunction with MuxLab's
passive CATV Balun II (500302) and other RF video
equipment for a complete RF cabling solution.
Applications
Residential, apartment, condominiums, hotels, offices,
schools, hospitals, trading floors.

Specifications

Environment
Devices
Transmission
3dB Bandwidth
Video Channels Supported
Signal Gain – Forward path (S
Signal Gain – Reverse path (S
Return Loss
Common Mode Rejection Ratio
Mounting
Dimensions
Weight
Maximum Distance - Cat 5 UTP
LED Indicators
Cable – UTP
Cable – "F"
Connectors
RJ45 Pin Configuration
Compatible MuxLab Baluns
Power Requirement
Power Supply
Temperature
Enclosure
Regulatory
Warranty

Order Information

MuxLab inc. © 2007-2008 Rev B
The product supports
Broadband CATV, VHF, FM, broadband Internet, digital cable.
Set-top tuners, RF splitters, RF amplifiers, modulators, combiners, re-processors,
cable modems
Transparent to the user
5MHz to 900 MHz
CATV 2-142, VHF channels 2-13, FM broadcast band. 5-42Hz return path for
Internet.
8P (500300/500301)
) 55-450 MHz: Tilt of .6 dB to 15.3 dB
21
450-900 MHz: 14.1 dB < S
5-42 MHz: -1.7 dB < S
)
12
>7 dB from 5 to 42MHz
> 10 dB from 55 to 900 MHz
> 30 dB from 5 to 900 MHz
Desktop
9.3" x 3.9" x 1.6" (23.5 x 9.9 x 4 cm)
28.07 oz (817 gms)
Dependant on channel frequency, input power and receiver sensitivity.
Power: One (1) green LED.
24 gauge or lower solid copper twisted pair wire impedance: 100 ohms at 1 MHz
Maximum capacitance: 20 pf/foot. Attenuation: 6.6 dB/1000 ft at 1 MHz
Impedance: 75 ohms at 1 MHz (RG6)
RF Input: "F" connector
RF Outputs: Eight (8) or sixteen (16) RJ45S depending on model
RJ45 Pins 7& 8
500006 (550MHz), 500302 (900 MHz)
12VDC @ 400 mA
Desktop 110-240V switching power supply.
Input: 100-240V, ~0.5A Max, 50-60Hz
Output: +12V, 1.25A. Output Power: 15W Max. Detachable AC power cord
Operating: 0° to 40°C. Storage:-10° to 70°C. Humidity: up to 95% non-condensing
Black anodized aluminium
FCC, CE, RoHS
2 years
500300 CATV Distribution Hub, 8 Ports, 110V
500301 CATV Distribution Hub, 8 Ports, 220-240V
500303 CATV Distribution Hub, 16 Ports, 110V
500304 CATV Distribution Hub, 16 Ports, 220-240V
VideoEase CATV Distribution Hub
500300, 500301, 500303, 500304
Benefits
Centralised cabling for greater control
Cost savings - eliminate costly coaxial cable
Quicker moves, adds and changes
Neater wiring
Features
900 MHz bandwidth
Supports CATV, Internet, digital cable
Built-in RF amplifier
Bi-directional transmission
Works with other standard RF video equipment
55-450 MHz: Tilt of -2.0 dB to 13.0 dB
< 15.9 dB 450-900 MHz: 9.6 dB < S
21
< 4.3 dB 5-42 MHz: -6.7 dB < S
12
>7 dB from 5 to 42MHz
> 10 dB from 55 to 900 MHz
> 30 dB from 5 to 493 MHz
> 20 dB from 493 to 547 MHz
> 30 dB from 547 to 900 MHz
1U Rack-mount
19" x 3.9" x 1.75" (48.3 x 9.9 x 4.4 cm)
41 oz (1.2 kgs)
VideoEase CATV Distribution Hub
16P (500303/500304)
< 13.1 dB
21
< .4 dB
12
