C o n t r o l o P t i o n S
User settings on Source four leD Studio HD fixtures allow multiple
operational modes and settings for either console operation via DmX
protocol or stand-alone operation. the expanded lCD display provides
easy navigation to all possible settings and options. Some of the
setting options are:
• multiple DmX choices for multiple operational modes
• multiple dimming curve options
• Preset color temeratures and sequences for stand-alone (no
console required) operation
• White point selection – i.e. 3200K, 5600K, etc
• loss of data behavior options – instant off, hold last look for
two minutes, etc
• output modes – three output options that offer the user a
choice between maximum output and maximum consistency
See the user manual for a complete explanation of all of the control
settings and options for the Source four leD.

Quick Setups

to assist in managing the numerous control and fixture behavior choices, five
combinations of operational settings are available to quickly get started. these
settings are specifically created for different applications and are easily accessible at
the fixture display. each setting can then be modified as required to take advantage
of all of the possible control features.
Setting
Profile Description
title
General Direct factory Default:
for general purpose
use including interior
architectural applications
Stage HSi theatrical lighting:
Plus 7 Duplicates the color and
enabled dimming behavior of
tungsten stage lighting
fixtures
Xt arch HSi exterior architectural lighting:
Provides a high degree of
color consistency in high
ambient temperature
envionments
High rGB event lighting:
impact enables quickest response,
simple rGB control and
strobe channel for maximum
effect usage
Studio Studio Studio factory Default:
enables three parameter
control of white light
(intensity, white point, and
tint) via DmX from console
or from fixture display – no
console required
*See user manual for complete list of features for each Quick Setup
Source Four LED
C o n t r o l o P t i o n S
DMX input channel profiles
typical features*
• Standard dimming curve
• Regulated output for
color consistency
• Incandescent dimming
curve
• Regulated output for
color consistency
• 3200K white point setting
• Standard dimming curve
• Protected output
• 3200 white point setting
additional profile options
• Quick dimming curve
• Boost mode for
maximum intensity
• 5600K white point setting
• Linear dimming curve
• Regulated output mode
for color consistency
4 of 5
Source Four LED Series
DmX DmX Channel
Profile Channels assignments
Studio 6 1 – intensity
(Ch. 4 2 – Color Point
not used) (CCt)
3 – tint
4 – n/a
5 – Strobe
6 – fan Control
Direct 10 1 – red
2 – redorange
3 – mint
4 – Blue
5 – indigo
6 – n/a
7 – n/a
8 – intensity
9 – Strobe
10 – fan Control
HSi 6 1 – Hue (coarse)
2 – Hue (fine)
3 – Saturation
4 – intensity
5 – Strobe
6 – fan Control
HSiC 7 1 – Hue (coarse)
2 – Hue (fine)
3 – Saturation
4 – intensity
5 – Strobe
6 – fan Control
7 – Color Point
(CCt)
rGB 6 1 – red
(Ch. 4 2 – Green
not used) 3 – Blue
4 – n/a
5 – Strobe
6 – fan Control
Plus 7 Seven additional color control channels are available in
rGB, HSi, and HSiC input profile settings. for example
HSi with 'Plus 7' enabled becomes a 15-channel
profile:
1 – Hue (coarse)
2 – Hue (fine)
3 – Saturation
4 – intensity
5 – Strobe
6 – fan Control
7 – n/a
8 – Plus7
Control on/off
9 – red
10 – redorange
11 – mint
12 – Blue
13 – indigo
Strobe Variable strobe control: 0% is no strobe. the fixture
output will strobe more rapidly as the strobe channel
value approaches 100%.
Studio HD
™
notes
Controls fixture as a white light
unit. if no DmX, i.e. console
input, is present, fixture can
be adjusted for these three
parameters on the U/i at the back
of the unit.
Direct control of each individual
color with a separate master
intensity channel. Color
calibration of leDs is not active
in this mode. this profile will
produce additive color cross-
fades.
High resolution hue (two-
channels), saturation, and
intensity control. HSi mode will
produce color cross-fades around
the color space.
High-resolution hue, saturation
and intensity control as above,
with the addition of a color
point channel to adjust the color
temperature of the fixture in
both white light and color. Color
cross-fade performance is the
same as HSi.
effectively addresses all seven
colors via three channels of
control. rGB profile will produce
additive color cross-fades.
the desired color and intensity
is achieved by using the HSi or
rGB channels
Placing channel seven at a value
over 51% gives the fixture a
15-channel profile.
Channels 9-15 represent the
native colors of the fixture and
allow the operator to adjust
individual color channels to fine
tune the color output.
