Fill in the following fields:
Field
Address
User Name
Password
Click Refresh to update the list of cameras associated with the server, and then select the
camera whose video you want to capture into the Buffalo Surveillance Server.
Click OK to close the dialog box.
In the Video Type field, select the format in which the extracted video should be stored.
MJPEG stores video in the same format in which it was stored in Milestone, and takes
the same amount of space.
H.264 is a loss-less format that takes 30% to 70% less storage space.
In the Recording Computer field, select from the drop-down list a computer that captures a
video feed from your camera.
Select the Active check box if you want to make the camera available for capturing video if a
policy references it, or leave it inactive.
Click OK to close the Add New Camera dialog box.
Record and Capture Video Feeds
The host name or IP address of the image server from
which you want to extract video.
The user name can be either a Basic User or a Windows
Domain User. When Basic User, user is just the user
name. If a Windows Domain User, then the user name
format is "<user>@<domain>" where user is the user and
domain is the Windows domain the user is valid within.
Your Basic User password for the Milestone database.
Results
73
