Summary of Contents for Buffalo HD-H0.6TGL

  • Page 1 User Manual TeraStation HD-HTGL/R5 www.buffalotech.com Rev 4.9...
  • Page 2 Congratulations on your new TeraStation! This user manual is intended to assist you in configuring it. If you run into difficulties or need additional help, feel free to contact our 24/7 Technical Support at (866) 75-610 (USA & Canada only). Technical Support in Europe is available between the hours of 9am - 6pm (GMT) Monday through Thursday and 9am-4:30 pm (GMT) Friday for this product. Customers in Europe can obtain Technical Support using the following information: Email: helpdesk@buffalo-technology.ie | Web: www.buffalo-technology.com This user manual uses images representative of TeraStation user interfaces and software. Because we’re constantly updating our product, the images and text in this manual may vary slightly from the images and text displayed by your TeraStation. These changes are minor and should not affect the ease of setup adversely. As time passes, future user interfaces, updated software, and later...

  • Page 3: Table Of Contents

    Table of Contents TeraStation Quick Setup ...........4 TeraNavigator Setup............8 Accessing TeraStation Data from a PC ......14 Accessing TeraStation Data from a Mac......17 TeraStation Diagram ............21 Advanced Settings ............24 Basic Settings ..............25 Network Settings ............. 26 Disk Management ............28 Adding Extra Hard Drives ..........34 Shared Folders ..............38 Groups ................

  • Page 4: Terastation Quick Setup

    TeraStation Quick Setup Begin setting up your TeraStation by plugging your power cable and Ethernet cable into the back of the TeraStation as shown.
  • Page 5 TeraStation Quick Setup Connect your cables Plug the power cord into a 120 volt wall socket. Plug the other end of the Ethernet cable into a hub, router, or switch in your network.
  • Page 6 TeraStation Quick Setup Make sure that the power switch on the rear of the TeraStation is in the ON position, with the “I” symbol pressed down. Press the power button on the front panel. The LEDs will swirl as your TeraStation boots up. After your TeraStation has completed booting up and the LEDs have ceased to swirl, check the LINK/ACT LED on the front of the TeraStation.
  • Page 7 Verify that the LINK/ACT LED on the front of TeraStation is lit (see page 6’s picture). If it’s lit, go to page 8 to continue setting up TeraStation. If the LINK/ACT LED is still not lit, try the suggestions below to verify that you’re not suffering from common setup problems. Having problems? Make sure that: • the TeraStation and the router, hub or switch are both powered on, • the Ethernet cable is securely plugged in at both ends, and • the Ethernet cable is not damaged. Verify this by trying a different Ethernet cable. If problems persist, contact our 24/7 technical support at (866) 75-610 (USA & Canada only). Technical Support in Europe is available between the hours of 9am - 6pm (GMT) Monday through Thursday and 9am-4:30 pm (GMT) Friday for this product. Customers in Europe can obtain Technical Support using the following information: Email: helpdesk@buffalo-technology.ie | Web: www.buffalo-technology.com...

  • Page 8: Teranavigator Setup

    TeraNavigator Setup Insert the TeraNavigator CD into your PC’s CD-ROM drive. Setup should automatically launch. If it does not, manually launch setup.exe by pressing the Start menu and selecting the Run... option. When the Run dialog opens, type d:\setup.exe (where d is the drive letter of your CD-ROM drive). Press OK to continue.
  • Page 9 TeraNavigator Setup TeraNavigator is now running. Please press the Install Client Utility icon, and then Start. When installation is finished, press Launch.
  • Page 10 TeraNavigator Setup The TeraStation Client Utility allows you to easily configure TeraStation’s network settings. The tabs show the names of available TeraStations. If you have more than one TeraStation on the network, click the tab of the one you want to select it. While a TeraStation’s tab is selected, its IP Address is visible and the View Shares button will take you directly to its network shares and folders. See page 66 for more information on TeraStation Client Utility. For now, make sure that the proper TeraStation’s tab is selected, click Setup, and choose Browser Management.
  • Page 11 TeraNavigator Setup This login prompt will appear. Enter admin for the user name. Until you change it, the password for the admin account will be password. Press the OK button when finished. User name: admin Password: password See page  to change your password. If you’ve forgotten your password, see page 60. If this login prompt does not appear, your DHCP server may not be functioning correctly. If DHCP is disabled, you may re-enable it, or verify that the TeraStation’s IP address (page 10) is in the same range as that of your PC. See page 66 and page 67 to manually configure your TeraStation’s IP address if necessary.
  • Page 12 TeraNavigator Setup You are now logged in to the TeraStation Management Utility. Bookmark this page in your browser so it can be easily accessed for future configuration changes. You can also get here by typing http://TERASTATION_NAME into a Web browser, where TERASTATION_NAME is the name of your TeraStation that you set on page 1. For detailed explanations of each menu and setting, please refer to the Advanced Settings section (starting on page ) of this manual. To continue setup, click on the Basic link on the left side.
  • Page 13 TeraNavigator Setup Here on the Basic page, begin by changing the name of your TeraStation in the TeraStation Hostname field. A friendly, easy-to-remember name is recommended. The name cannot contain any spaces or special characters. Alphanumeric characters, hyphens, and underscores are allowed. A short description of the TeraStation can be entered into the TeraStation Description field. You’ll then see this description in Network Neighborhood on Windows machines. Make sure that the date and time are correct in Date and Time Setup. To synchronize clock settings with your computer, press Use Local Time.
  • Page 14 TeraNavigator Setup Congratulations! You’ve completed basic setup. For more detail on the other settings available in your TeraStation, turn to Advanced Settings, beginning on page 1. To access TeraStation data: Press the Start menu, select the Run... option. When the Run dialog opens, type \\TeraStation_ Name (where ‘TeraStation_Name” is the TeraStation Hostname set on page 1). Press the OK button to continue.

  • Page 15: Accessing Terastation Data From A Pc

    Accessing TeraStation Data from a PC TeraStation’s root directory will appear. You will see all of the configured shares, including share, the preconfigured data folder. All users can read and write to all folders unless otherwise configured. To set up security and password protection, or add other shares to your TeraStation, please refer to pages 8 - 1 of this manual. To change your RAID configuration, see pages 8 - 1. To setup a printer see the Printers section beginning on page 7. Drive letters can also be mapped to shares on your TeraStation; see page 16 for more information. Note: If this page does not appear, or if you receive a popup window from your firewall saying that a NetBios Session has been blocked from your TeraStation’s IP address, you will need to add your TeraStation’s IP address to...
  • Page 16 Accessing TeraStation Data from a PC From the TeraStation’s Root Directory screen (see page 15), click the Tools pull down menu and select Map Network Drive; Map Network Drive will run. Select the drive letter you would like to map from the Drive: pull down menu. Enter \\TeraStation_Name\share_name in the Folder: field, where TeraStation_Name is the TeraStation Name set on page 1 and share_name is share (if you’re mapping to this preconfigured folder) or the name of another shared folder that you set up on page 8. You may browse for a shared folder by pressing the Browse button and searching through the Entire Network and then the Microsoft Windows Network.

  • Page 17: Accessing Terastation Data From A Mac

    Accessing TeraStation Data from a Mac If your Mac does not automatically detect your TeraStation’s Share folder and put it on your desktop, you will need to add the TeraStation to the Mac’s server list. Begin by clicking Go, and then choose Connect to Server. Enter your TeraStation’s IP address in the Server Address field and click Connect. If you don’t know your TeraStation’s IP address, see page 1.
  • Page 18 Accessing TeraStation Data from a Mac Select Guest and click on Connect. Note: If you have configured share permissions on your TeraStation, select Registered User and enter your Registered User credentials. Select the volume that you want to mount, such as share or share-mac, from the list of folders on the TeraStation. The share will open. A link to the shared folder will appear on your desktop.
  • Page 19 TeraStation client. See page 66 for more on the TeraStation client utility. If you have an all-Mac network with no Windows PCs available, you may have to get the TeraStation’s IP address from your router’s configuration utility. Many Buffalo routers list this information on the Client Monitor page, as shown to the right. Consult your router’s documentation for instructions on identifying the TeraStation’s IP address.
  • Page 20 TeraStation Expansion TeraStation has four USB 2.0 ports, two on the front panel and two on the rear. These ports can be used for adding external USB Hard Drives or a USB Printer. TeraStation will then share the USB devices, allowing everyone on the network to use them. Up to four external USB hard drives, or one printer and three hard drives, may be added to TeraStation. To connect a USB printer or hard drive to TeraStation, simply plug it into one of the four USB Ports. USB Hard Drive Information: You may plug in additional USB hard drives to any of the four USB ports on your TeraStation. See page  for setting up your USB hard drive under TeraStation. See page 8 for information on setting up shared folders on a USB Hard Drive. Page 7 will show you how to reformat the USB Hard Drive. Page 51 shows you how to set up TeraStation to backup to a USB Hard Drive. USB Printer Information: See page 7 to set up a USB Printer as a network printer on TeraStation.

  • Page 21: Terastation Diagram

    TeraStation Diagram 1. Power Button – Press and release the Power Button to turn the TeraStation on. Hold it down for 3 seconds to turn the TeraStation off. 2. USB Ports – USB ports on both front and rear panels of the TeraStation may be used to connect USB hard drives, a printer, or an additional TeraStation to your TeraStation.
  • Page 22 TeraStation Diagram 11. Diagnostic LED – The Diagnostic LED may 15. Power Switch – This is the TeraStation’s flash when the TeraStation encounters an error. master power switch. While it is on, the power In this event, please contact our 24/7 technical button on the front panel of the TeraStation may support at (866) 75-610 (USA & Canada be used to start and shut down the unit. When only; see page 71 for European tech support this switch is off, no power goes to the unit. If information). this switch is left off for an extended period of time, the TeraStation’s internal system clock Power – This LED glows a steady green may need to be reset.
  • Page 23 TeraStation Diagram 18. UPS interface – An Uninterruptable Power Supply can use this interface to safely shut down your TeraStation in the event of a power failure. This interface is non-LPS. DP-1, DP-1P, DP-2, or DP-2P cables may be used to connect to the UPS. 19. 10/100/100 Mbps Ethernet Port – Use this port to connect your TeraStation to a switch, a router, or another computer. The port is autosensing, so either a conventional Ethernet cable or a crossover Ethernet cable may be used.

  • Page 24: Advanced Settings

    Advanced Settings Browser Management Tool - Home Welcome to Advanced Settings! We’ll discuss the many adjustments you can make to your TeraStation. Begin by bringing up the Browser Management screen that you bookmarked on page 1. You are now at Home. Notice that Home is lit up in yellow in the screenshot to the left. You can return to this page at any time by clicking on Home from the menu at the left of your Browser Management screen. Here, you can see...
  • Page 25 Advanced Settings Basic You may modify your TeraStation’s hostname and description under Hostname Setup. Make sure that the date and time are correct in Date and Time Setup. To synchronize time settings with those in your computer, press Use Local Time. To have your system time automatically set by an NTP server, enable NTP Server and enter an IP address for the NTP server. Ensure that both the Display Language and the Windows Client Language are set to languages that you’re comfortable with.
  • Page 26 Advanced Settings Network (IP Address Properties) In most networks, TeraStation will get its IP address automatically from a DHCP server. You may disable DHCP here. If DHCP is disabled and an IP address is not set manually, it will default to 192.168.11.150. The TeraStation’s IP Address, Subnet Mask, Default Gateway Address, and DNS Server address may all be entered manually under IP Address Properties. Ethernet Frame Size may also be set manually on this page. Click Apply after making any changes.
  • Page 27 Advanced Settings Network (Workgroup/Domain) To make your TeraStation a member of a workgroup or domain, enter the appropriate information into the fields on this page and click Apply. If the TeraStation is to be part of a Windows Domain, the TeraStation should be added beforehand to the Domain Controller with a computer account in Server Manager.

  • Page 28: Disk Management

    Advanced Settings Disk Management (Drive Properties) This page shows the current properties of your hard drives and RAID Arrays. To change these settings, click on RAID Configuration at left.
  • Page 29 RAID Spanning - All four drives are striped into one large drive, giving the maximum capacity for your TeraStation. This size is the one listed on your TeraStation’s box and shows the total capacity of the TeraStation with no data used for redundancy. RAID Spanning is fast and efficient, but with no redundancy, if one hard drive fails, all data on the TeraStation is lost. RAID 1 (mirroring) - Hard drives (or spanned pairs of hard drives) are arranged in mirrored pairs. Each half of the pair reads and writes exactly the same data. This costs you half the total capacity of your TeraStation, but provides excellent redundancy. If a hard drive fails, the mirror continues to supply data, so you may work on normally. You may replace the damaged or defective drive at any time, and normal RAID 1 mirroring will then be automatically restored. RAID 5 (parity) - All drives in a RAID 5 array reserve part of their data space for parity information, allowing all data to be recovered if a single drive fails. The parity information takes up about one hard drive’s worth of space, so if you set up all four drives in the TeraStation as a RAID 5 array, your usable capacity will be about 3/4 of the total capacity of the TeraStation. RAID 5 is an excellent compromise between efficiency and security. If a single drive fails, no data is lost. After the damaged or defective drive is replaced, your TeraStation will automatically restore all data to the new drive and resume normal RAID 5 operation. This is how your TeraStation is set up out of the box. Buffalo Technology recommends RAID 5 for its excellent balance of efficiency and security.
  • Page 30 Advanced Settings Disk Management (RAID Configuration) This page shows your current RAID arrays. You may delete old arrays or create new ones by clicking on the underlined RAID Array # under RAID Array Configuration. You may also disable RAID Array Error Detection Response from this page. Normally, this is set to automatically shut down the RAID array when an error is detected.
  • Page 31 Advanced Settings Disk Management (RAID Configuration) A configured RAID array may be deleted by pushing the Delete RAID Array button. This will free up all hard drives listed under Disk Structure. To configure an unconfigured array, put checks next to the hard disks you want included in the array (under Disk Structure) and choose your RAID mode. Click Setup RAID Array when ready. It may take several minutes to complete setting up the RAID array. When it’s finished, a Disk Check will run.
  • Page 32 Advanced Settings Disk Management (Disk Check) When RAID Configuration is done, you’ll see this screen. To configure a new array, click on RAID Array # and go back to the bottom of page 1. To setup shares turn to page 8.
  • Page 33 Advanced Settings Disk Management (RAID Configuration) You’ll see this screen when your new RAID Array is completely configured. Click on Shared Folders and turn to page 8 to begin setting up shares on your TeraStation.
  • Page 34 Advanced Settings Disk Management (USB Settings) If you’ve plugged an external USB hard drive into one of the USB ports on your TeraStation, you may set it up from this page. Click on its name under USB Disk Setup to begin.
  • Page 35 Advanced Settings Disk Management (USB hard drive setup) From here you can see your USB hard drive’s setup information. If the hard drive’s information isn’t displayed properly, try restarting your USB hard drive and then restarting your TeraStation. Some USB hard drives must be reformatted from within TeraStation before they can be assigned shares. Press Format USB Disk, or choose Disk Format from the left-side menu, to begin reformatting your USB hard disk. Turn to page 7 for more information on reformatting disks. Turn to page 8 to set up shares on your USB hard drives.
  • Page 36 Advanced Settings Disk Management (Disk Check) To initiate a comprehensive disk check on a hard drive or array of drives, select the hard drive or array that you want to check from the Target Disk dropbox and click the Select Target button.
  • Page 37 Advanced Settings Disk Management (Disk Format) To format a hard drive or array, select it from the Target Disk dropbox. Choose the file system desired from the File System dropbox (internal drives can only be formatted with XFS). Note that FAT32 has a 4 gigabyte file size limit. If you choose FAT32 for your file system, you will not be able to store files larger than 4 gigabytes on the drive. Buffalo Technology recommends the XFS file system. Press Select Target Disk when done. Depending on the size of the target hard disk or array, a Disk Format may take several hours to complete.

  • Page 38: Shared Folders

    Advanced Settings Shared Folders To begin setting up shares on your TeraStation, select Shared Folders from the left side menu, and then click the Add button under Shared Folders Setup.
  • Page 39 Advanced Settings Add a new Shared Folder To add a new shared folder, enter a name for it in the Shared Folder Name box and choose which Disk Space it will reside in. You may also choose which operating systems the share will support by putting the appropriate checks next to Shared Folder OS Support, and whether the share supports the Recycle Bin by putting a dot next to Enable or Disable. Enter a Shared Folder Description and a Remote Backup Password if you desire.

  • Page 40: Groups

    Advanced Settings Shared Folders (Access restrictions) To use Access Restrictions for a share, put a dot next to Enable. Highlight groups or users in the All Groups/ Users column and use the left-pointing arrow buttons (located just to the left of each box) to move individual groups or users from the All Groups/Users column to the Read Only box (if you want to give them read access only) or all the way to the Writable box, if you want to give them full access to the share. Right-pointing arrows will move highlighted users or groups back to the right. Click Apply when you have your groups and users in the appropriate boxes.
  • Page 41 Advanced Settings Shared Folders (Anonymous FTP Setup) To allow Anonymous FTP, choose Enable for Anonymous FTP Server. Select a folder to share from the Anonymous User Public Shared Folder (only one folder may be shared by anonymous FTP) and choose whether you want the share to be Writable or Read Only. Click the Apply button to set up anonymous FTP. If FTP Server is disabled in the Basic window, this page will not be accessible. Anonymous FTP mode uses port 8021 (e.g. ftp://IP Address:801).
  • Page 42 Advanced Settings Group Management To Delete a group, put a check next to its name and click Delete. To add a group to your TeraStation, click Add. Add a name and a description to the Add New Group fields. Put checks next to each Member User that you want to be part of the group. Click Apply when your group is set up the way you want it.
  • Page 43 Advanced Settings User Management TeraStation is preconfigured with two users, admin and guest, out of the box. The guest account allows network users login access so that they can clear the print que. It has no password. The admin and guest user accounts cannot be deleted. To delete any other user, put a check next to their name and click Delete.
  • Page 44 Advanced Settings User Management (changing passwords) To change an account’s password, click on the name of the account under User Settings. Note: if a user name and password are used to log into user’s windows computer or domain, the same user name and password should be used when creating the user’s account on the TeraStation, or problems accessing shared folders may occur.
  • Page 45 Advanced Settings Troubleshooting Multiple Shares When adding multiple shares, you may see this error message. This is caused by having multiple shares to the same resource using different credentials. The error occurs when connecting to at least one secure, restricted share. Due to a constraint in Microsoft Windows, only one set of credentials can map drive letters for a network resurce such as the TeraStation. As such, only one username and password can be used while mapping a drive. If unsecure, unrestricted shares are mapped and then an attempt to map a secure, restricted share occurs, then this error will occur. To prevent this, you must create all mapped shares using the same login and password information. Please follow the steps on the next page to remedy this problem.
  • Page 46 Advanced Settings Mapping Multiple Shares When mapping any share, select the Connect using a different user name option. A login and password prompt will appear. Use the username and password required by any secure, restricted shares for all shares. All mapped shares must use the same username and password! If only unrestricted shares are being mapped, then it’s not necessary to set a username and password for shares. Multiple mapped drives to unrestricted shares can exist without a username or password as long as no restricted, secure shares are mapped.

  • Page 47: Printers

    Advanced Settings Print Server (Settings) A USB printer, plugged into a USB port on either the front or the rear of your TeraStation, may be used as a Windows Print Server and/or an Apple Print Server on your network by choosing Enable on this page as appropriate and then clicking Apply. TeraStation supports most PostScript printers. It doesn’t support bi-directional printers. Non-PostScript printers are not supported by Buffalo. You may be able to get enough information from a printer’s documentation to get it to work, but our technical support cannot help you with this.
  • Page 48 USB Settings Print Server - Printer Share Installation If TeraStation is set up to share your printer (page 7), you can easily add the printer to any Windows PC on your network. Follow these steps for each PC that you want to be able to access the printer. Access the TeraStation by pressing Start, selecting the Run... option, and entering \\TeraStation_Name (where TeraStation_ Name is the name you set on Page 1). Press the OK button when finished. Right click on the lp icon and select Connect.
  • Page 49 USB Settings Print Server - Printer Share Installation (continued) The Add Printer Wizard will launch. Select the proper driver for your printer. If your printer is not in the list, you’ll have to insert the CD that came with your printer into your PC’s CD-ROM drive and press the Have Disk button. Refer to your printer documentation for further information on installing your printer if necessary. Press OK to finish. If lp is the only printer installed on the PC, then it will automatically be set as the default printer. If it’s not the only printer, you may make it the default printer by clicking Printers and Faxes in Control Panel, right clicking on the lp printer icon and selecting the Set as Default Printer option from the File drop- down menu.
  • Page 50 Advanced Settings Print Server (Delete Print Queue) If a corrupt print job is sent to a printer, printing may suddenly fail. If your print jobs seem to be locked up, clearing the print queue may resolve the issue. To execute the Delete Print Queue program, press the Delete button. This will clear all current print jobs. Users will have to re-send any incomplete print jobs to the printer. If there are still problems printing to the printer, then check the printer manufacturer’s documentation for troubleshooting information. Also, verify that the USB cable is securely fastened to both the printer and the TeraStation. Finally, you may try turning the TeraStation off, turning the printer off, turning the printer back on, and then turning the TeraStation back on again. Note that if a multi-function (all-in-one) printer is attached to the TeraStation, usually only the printing and fax functions will work. Other features, such as scanning, probably will not function.

  • Page 51: Backups

    Advanced Settings Disk Backup To create a backup job, click on an underlined Job Number. The Edit Backup Job dialog will appear. If the Disk Sleep function is enabled, disable it (page 58) before creating a backup job.
  • Page 52 Advanced Settings Disk Backup (Edit Backup Job) A Backup Job can run regularly on a daily or weekly schedule, or immediately by appropriate choices in the Backup Job Schedule field. Date and Time for the backup may be entered, and Encryption and Compression enabled or disabled. Enable Overwrite Backup to have each scheduled backup write over the previous backup, or Differential Backups to backup only files changed since the previous backup.
  • Page 53 Advanced Settings Disk Backup (TeraStation List) Press Refresh to get a list of TeraStations on your network. Note: Disk Backups between two TeraStations use port 8873 for encrypted backups and port 873 for backups with no encryption.
  • Page 54 Advanced Settings Disk Backup (Add TeraStation) To add a TeraStation to your network, enter its numerical IP address in the Remote TeraStation IP Address field and click the Add to List button.

  • Page 55: Pcast

    Advanced Settings PCast Clicking on PCast on the left-side menu takes you to this page. Use this field to set a share on your TeraStation as the media folder for your LinkTheater. Choose Enable for PCast Media Server and choose the share where you keep your media files as the Media Folder.

  • Page 56: Maintenance Settings

    Advanced Settings Maintenance (Notification) If your TeraStation is remotely managed, you may choose to receive nightly status reports and be notified of any disk events by email. To set this up, enable Mail Notification and enter the IP address of your SMTP server* in the SMTP Server Address field. Select a Subject line for the emails (i.e. “TeraStation report”) and enter the email address of each person you want to receive notification emails into a Recipient Mail Address field. * SMTP server must be of open type. There’s no provision for entering a username or password.

  • Page 57: Ups Settings

    Advanced Settings Maintenance (UPS Settings) You may enable Synchronize with UPS and UPS Automatic Shutdown from this page. Consult your Uninterruptable Power Supply’s documentation for further information about setting up your UPS system. TeraStation’s UPS interface is serial. USB-type UPS interfaces are not currently supported. See the next page for more information on TeraStation’s UPS interface.
  • Page 58 Advanced Settings Maintenance (UPS Settings) This is TeraStation’s serial port pin assignment for serial UPS products.
  • Page 59 Advanced Settings Maintenance (Disk Sleep Function) If there are regular periods when your TeraStation is not in use, you may want to schedule disk sleeping. Enable Disk Sleep, select the time that you want to initiate sleep mode, and select the time that you want the TeraStation to “wake up” and resume normal operation. Click Apply. To avoid conflicts, do not use the Disk Sleep Function concurrently with Disk Backup.
  • Page 60 Advanced Settings Maintenance (Shutdown) From the Shutdown page, press Apply to shutdown TeraStation. This has the same function as holding down the power button on the front of TeraStation, but may be done remotely.
  • Page 61 Advanced Settings Maintenance (Initialization) The INIT button on the rear of your TeraStation normally returns the TeraStation to factory settings when held down for 15 seconds. This affects Admin Password, Ethernet Frame Size, and IP Address. If the Remain option has been selected on the screen below, then the Admin Password will not be reset when the INIT button is held down. Pressing Apply for Restore Defaults from Maintenance/Initialization resets Admin Password, Hostname, TeraStation Description, NTP Settings, Workgroup Settings, Access Restrictions, User Settings, Group Settings, Mail Notifications, UPS Settings, Disk Sleep, and Disk Backup. If you select the Remain option for Admin Password and then click Apply, the admin password will no longer be reset when the INIT button on the TeraStation is held down.
  • Page 62 Advanced Settings System Status (System Information) This page shows you the System Information for your TeraStation.
  • Page 63 Advanced Settings System Status (USB Details) This page shows you details on USB hard drives and printers plugged into your TeraStation.
  • Page 64 Advanced Settings System Status (Drive Properties) This page shows you the properties of all hard drives and RAID arrays in and attached to your TeraStation.
  • Page 65 Advanced Settings System Status (Network Information) This page shows you the System Information for your network connection.
  • Page 66 System Status User Access Status This page shows you the current status of all users on the system.

  • Page 67: Client Utility

    TeraStation Client Utility This is the TeraStation Client Utility. Installed on your PC, it allows you to access each of the TeraStations on your network. Click Refresh List to get tabs for each of your TeraStations. Each tab shows the Host Name, Workgroup, IP Address, and Subnet Mask of the associated TeraStation, as well as the version of firmware it’s running. With a TeraStation’s tab selected, you can click on the View Shares button to go directly to its root share.
  • Page 68 TeraStation Client Utility IP Address Setup Here, you may enter your IP address and Subnet Mask manually, or enable your TeraStation to acquire them automatically from a DHCP server. You’ll need the administrator password to use this screen. Press OK when you’re done.

  • Page 69: Troubleshooting

    Troubleshooting If TeraStation encounters a disk error, it will be reported in the TeraStation status on the top of any of the Web-Based configuration screens. Run a Disk Scan in the event of this error. If that still does not resolve the problem, a Format is recommended. Formatting the drive will delete all of the data on it, so back up any data you can before formatting (if possible). Finally, if none of the above solutions help, please contact Technical Support (see pages 70 and 71 for contact information). DIAG LED codes: One blink every second: RAID Array Configuration is running normally One blink every four seconds: RAID Error Four blinks every four seconds: Internal Fan Error Five blinks every four seconds: Flash ROM Error Six blinks every four seconds: Hard Drive Error Seven blinks every four seconds: RAM, LAN, or HDD Controller Error...
  • Page 70 When using Standard Mode - The failed drive will have a red light blinking in the STATUS/FULL position of the front display. To determine which drive has failed, restart the TeraStation and watch which Disk LED illuminates red. After replacing the failed drive, all data on that drive will be lost. Data on other dives should still be normally accessable. When using Spanning Mode - All drives will have a red light blinking in the STATUS/FULL position of the front display. Further troubleshooting will be required to determine which drive has failed in the array. Data recovery is not possible by replacing a drive. After replacing the failed drive, you will have to delete and recreate your RAID array to make the TeraStation usable again. All data on the array will be lost. If your TeraStation is still under warranty, contact tech support before replacing your hard drive. Replacing your hard drive yourself may void your warranty. If your warranty has expired, you may replace the hard drive with an exact replacement (available from Buffalo Technology), or with any IDE drive of at least the same capacity as the failed hard drive.
  • Page 71 Replacing a Hard Drive If a STATUS/FULL led is blinking, note the drive number before continuing. Use a clean, padded work area to dissassemble your TeraStation. You’ll need a #2 phillips screwdriver. You will be removing and replacing a total of 22 screws to replace a hard drive, so keep each screw that you remove carefully in a safe place. Be careful not to drop the TeraStation, or cut yourself on sharp interior metal parts. Buffalo Technology is not responsible for any damage that you do to yourself or your TeraStation while changing out a hard drive! Be careful. Remove all cables and place the unit on its top, exposing the four rubber feet. Remove the rubber feet. Each foot is held in place by one screw. M3 Screw 6mm...
  • Page 72 Replacing a Hard Drive Remove the 3 screws from the rear panel as shown. M3 Screw 4mm Remove the cover by sliding it towards the rear of the TeraStation. Remove the front panel by removing the 4 screws on the sides of the TeraStation that hold it in place. M2.5 Screw 2.5mm...
  • Page 73 Replacing a Hard Drive Unplug and detach the LED cable at the point indicated. Remove the three screws from the side panel. M3 Screw 4mm Remove the indicated screw from the base panel. M3 Screw 6mm...
  • Page 74 Replacing a Hard Drive The side panel can be opened towards the front of the TeraStation. Unplug the power and hard drive cables from the motherboard. Remove the three screws as indicated from the hard drive chassis. M3 Screw 4mm...
  • Page 75 Replacing a Hard Drive Place the TeraStation on its base and slide out the hard drive chassis. Remove the power plugs from all four hard drives.
  • Page 76 Replacing a Hard Drive Remove the 4 screws from the sides of the failed hard drive. Note that the hard drive chassis is marked with numbers corresponding to the drive numbers on the front display. 4mm HD screw (note that the threads are coarser than the M3 screws; please do not get them mixed up!) Remove the failed hard drive from the chassis. Install the replacement hard drive.
  • Page 77 Replacing a Hard Drive Reassembly is the reverse of dissassembly. Reconnect cables and power to your TeraStation. Login to the TeraStation’s Web-based configuration tool. Click the error link on the first page of the management interface. Follow the steps shown in the manager to rebuild the RAID Array. The TeraStation should now be back in the state it was prior to the hard drive failure. If you were using RAID 5 or RAID 1, your data should be restored.

  • Page 78: Technical Specifications

    Technical Specifications LAN Standards: IEEE 802.3u 100BASE-TX; IEEE 802.3 10BASE-T Transmission Types: 1000Mbps/100Mbps/10Mbps; 100BASE-TX 4B/5B, MLT-3;10BASE-T Manchester Coding Access Media: CSMA/CD Media Interface: RJ-45 USB Standard: USB 2.0 Hi-Speed (HS) Full-Speed (FS) Low-Speed (LS) USB Connector: USB A Connector (4) Data Transmission Speed: Max: 480 Mbps (HS Mode) Max: 12 Mbps (FS Mode) UPS: UPS Compatible (Serial port connection) Power Consumption: 17W Maximum Dimensions: 6.6” x 8.7” x 9.5” (168 x 221 x 241 mm.) Weight: 15.8 lb. (7.2 kg.) Operating Environment: 32° - 95° F; 20-80% non-condensing...
  • Page 79 Technical Support (US and Canada) Buffalo Technology offers toll-free technical support 24 hours a day, 7 days a week for this product. Customers in the United States and Canada can obtain technical support using the following information: Web: www.buffalotech.com E-mail: info@buffalotech.com Telephone: (866)-75-610 (USA & Canada only; see page 68 for European tech support) FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. GPL Statement This product uses GPL/LGPL software. Please see the GNU LICENSE document on the LinkNavigator CD-ROM for more information concerning the terms of the license. To obtain a copy of our open source software, please send a message to GPL@buffalotech.com to inquire about obtaining a...

  • Page 80: Technical Support

    Technical Support (Europe) Buffalo Technology (Europe), Inc. 176 Buckingham Avenue, Slough, Berkshire, SL1 4RD United Kingdom GENERAL INQUIRIES Email: sales@buffalo-technology.com TECHNICAL SUPPORT Technical Support in Europe is available between the hours of 9am-6pm (GMT) Monday to Thursday and 9am-4:30pm (GMT) Friday for this product. Customers in Europe can obtain Technical Support using the following information: E-mail: helpdesk@buffalo-technology.ie | Web: www.buffalo-technology.com...
