SocketModem Cell Pin-Out
The SocketModem Cell cellular
modem interfaces easily with existing
products through a standard serial
communication channel. The serial DTE
channel is capable of transfer speeds
to 921.6K bps (depending on model)
and can be interfaced directly to a
UART or microcontroller. The complete
on-board RF transceiver interfaces with
an antenna for direct connection to
wireless SMS, circuit switched dial up, or
packet data networks. It also includes an
onboard LED to display network status.
(Voice Model)
Ordering Information
HSPA+ Models
Product
Description
MTSMC-H5
HSPA+ Embedded Modem (Serial Interface)
MTSMC-H5-U
HSPA+ Embedded Modem (USB Interface)
EV-DO Models
Product
Description
For Verizon Networks
MTSMC-EV3-N3
EV-DO Rev A Embedded Modem (Serial Interface)
MTSMC-EV3-U-N3
EV-DO Rev A Embedded Modem (USB Interface)
GPRS Models
Product
Description
MTSMC-G2
850/1900 MHz GSM/GPRS Modem
MTSMC-G2-ED
900/1800 MHz GSM/GPRS Modem
MTSMC-G2-V
850/1900 MHz GSM/GPRS Modem w/Voice
MTSMC-G2-V-ED
900/1800 MHz GSM/GPRS Modem w/Voice
MTSMC-G3-EU
850/900/1800/1900 MHz GSM/GPRS Modem
CDMA Models
Product
Description
For Sprint Networks
MTSMC-C2-N2
CDMA2000 1xRTT Modem (Serial Interface)
For Verizon Networks
MTSMC-C2-N3
CDMA2000 1xRTT Modem (Serial Interface)
For Aeris Networks
MTSMC-C2-N16
CDMA2000 1xRTT Modem (Serial Interface)
Developer's Kit
The Developer's Kit allows you to
plug in the communications device
and use it for testing, programming
and evaluation. The kit includes one
development board with RS-232
DB-25 connector, universal power
supply, antenna and RS-232 cable.
Services & Warranty
Services & Warranty
Multi-Tech's comprehensive Support
Multi-Tech's comprehensive Support
Services programs offer a full array of
Services programs offer a full array of
options to suit your specific needs.
options to suit your specific needs.
These services are aimed at protecting
These services are aimed at protecting
your investment, extending the life of
your investment, extending the life of
your solution or product, and reducing
your solution or product, and reducing
total cost of ownership. Our seasoned
total cost of ownership. Our seasoned
technical experts, with an average
technical experts, with an average
tenure of more than 10 years, can
tenure of more than 10 years, can
walk you through smooth installations,
walk you through smooth installations,
troubleshoot issues and help you with
troubleshoot issues and help you with
configurations. Products include a 2-year
configurations. Products include a 2-year
warranty.
warranty.
Installation Support
Installation Support
Multi-Tech's Installation Support Service
Multi-Tech's Installation Support Service
delivers priority service with the ability
delivers priority service with the ability
to work one-on-one with an experienced
to work one-on-one with an experienced
Multi-Tech technical support engineer,
Multi-Tech technical support engineer,
to guide you through the installation
to guide you through the installation
process for our products.
process for our products.
Technical Support Services
Technical Support Services
At Multi-Tech, we're committed to
At Multi-Tech, we're committed to
providing you personalized attention
providing you personalized attention
and quality service while providing you a
and quality service while providing you a
quick response to your product support
quick response to your product support
needs. We have several options of
needs. We have several options of
support for you to choose from.
support for you to choose from.
For additional information on Support
For additional information on Support
Region
Services as well as other service
Services as well as other service
Global
offerings, please contact your Multi-Tech
offerings, please contact your Multi-Tech
Global
representative or visit
representative or visit
www.multitech.com/support.go.
www.multitech.com/support.go.
Region
US
US
Region
World Headquarters
World Headquarters
Global
Multi-Tech Systems, Inc.
Multi-Tech Systems, Inc.
Global
2205 Woodale Drive
2205 Woodale Drive
Global
Mounds View, MN 55112 U.S.A.
Mounds View, MN 55112 U.S.A.
Global
Tel: 763-785-3500
Tel: 763-785-3500
Euro/GB
Toll-Free: 800-328-9717
Toll-Free: 800-328-9717
Email: sales@multitech.com
Email: sales@multitech.com
www.multitech.com
www.multitech.com
Region
EMEA Headquarters
EMEA Headquarters
US
Multi-Tech Systems (EMEA)
Multi-Tech Systems (EMEA)
Unit 1, Thames Court
Unit 1, Thames Court
2 Richfield Avenue
2 Richfield Avenue
US
Reading, Berkshire RG1 8EQ
Reading, Berkshire RG1 8EQ
United Kingdom
United Kingdom
US
Tel: +(44) 118 959 7774
Tel: +(44) 118 959 7774
Email: sales@multitech.co.uk
Email: sales@multitech.co.uk
