Specifications
Packet Data Features
GPRS Class 10, PBCCH support
Coding Schemes: CS1 to CS4
Embedded TCP/IP stack
Circuit Switched Data/Fax Features
Asynchronous, transparent & non-transparent up to
14.4K bps, MNP2 & V.42bis
SMS Features
Text & PDU, Point-to-Point, cell broadcast
Internet Protocols Supported
DNS Resolve, FTP client, IP, IPCP, LCP, PPP (dial-out),
TCP socket, UDP socket, CHAP, PAP
Antenna Connector
RF Antenna: 50 ohm SMA (Female connector)
SIM Connector
Standard 3V SIM receptacle
Interface Connectors
RS-232 Model: DE-15
USB Model: USB Type B
Ethernet Model: RJ-45, 10BaseT/100BaseTX, 802.3
Power Connectors
RS-232 & Ethernet Models: 2.5mm miniature screw
USB Model: Bus Powered
Voice Connectors
RS-232 Model: Optional Y-cable
USB & Ethernet Models: RJ-9 4-pos modjack
Power Requirements
5V to 32VDC
Physical Description
RS-232 & USB Models:
4.3" L x 2.4" W x 0.94" H; 4.2 oz.
(11 cm x 6.1 cm x 2.4 cm; 119g)
Ethernet Model:
2.8" L x 6.4" W x 1.2" H; 11.5 oz.
(7.1 cm x 16.3 cm x 3.0 cm; 326g)
World Headquarters
Tel: (763) 785-3500
(800) 328-9717
www.multitech.com
9/08 86002084
Copyright © 2008 by Multi-Tech Systems, Inc. All rights reserved.
EMEA Headquarters
Multi-Tech Systems (EMEA)
United Kingdom
Tel: +(44) 118-959 7774
Operating Environment
-30° to +70° C
Certifications:
CE Mark, R&TTE
EMC: FCC Part 2, 15, 22, 24, EN 55022, & EN 55024
Safety: cUL, UL 60950, EN 60950
Network: PTCRB
Ordering Information
Product
Description
MTCBA-G*
†
GSM/GPRS Class 10 Modem
Ordering Codes
-F4
850/900/1800/1900 MHz GPRS Modem
-U
USB Interface
-ED
900/1800 MHz Default
-EN
Ethernet Interface
-NAM
Includes US Style Power Cord
-EU
Includes Euro Style Power Cord
-GB/IE
Includes UK Style Power Cord
* Use ordering codes for specific build options. Check with your local carrier
to see which frequency bands are required. Go to www.multitech.com for
detailed product model numbers.
All build options support 850/900/1800/1900 MHz cellular connectivity.
†
Standard builds default to 850/1900 MHz while the builds that include a -ED in
the ordering code default for 900/1800 MHz.
Made in Mounds View, MN, U.S.A.
Features and specifications are subject to change without notice.
Trademarks / Registered Trademarks: MultiModem, Multi-Tech, and the
Multi-Tech logo: Multi-Tech Systems, Inc. / All other products and technologies
are the trademarks or registered trademarks of their respective holders.
Multi-Tech Systems (EMEA)
France
Tel: +(33) 1 49 19 22 06
Region
Global
