All antennas need to have a minimum flammability rating.
Safety requirements depend on your final product.
Unless otherwise noted, antennas certified by MultiTech are not approved for outdoor use. Do not extend
these antennas outside of any building.

Diversity and Power Draw

There are no significant power draw differences.

GPS Antenna Specifications

Manufacturer:
Description:
Model Number:
Multi-Tech Part Number:

MultiTech Ordering Information

Model
ANGPS-1MM
ANGPS-10MM
ANGPS-50MM

Antenna Specifications

Category
Frequency Range
Impedance
VSWR
Gain
LNA Current Consumption
Noise Figure
Polarization
Input voltage

OEM Integration

FCC & IC Information to Consumers
The user manual for the consumer must contain the statements required by the following FCC and IC regulations:
47 C.F.R. 15.19(a)(3), 15.21, 15.105 and RSS-Gen Issue 3, Dec 2010; 7.1.2 and 7.1.3
®
SocketModem Cell LTE MTSMC-Lxx Device Guide
Trimble
GPS Antenna with low noise amplifier
66800-52
45009665L
Quantity
1
10
50
Description
1575.24 MHz
50 Ohms
2.0:1 max
10-30 dBi
40 mA max
< 2dB
RHCP
3.0V M M 0.2V
ANTENNAS
25
