Available RAID Modes

Mode
Normal
RAID0
RAID1
JBOD

RAID 1 Rebuild

When operating in RAID1 mode, if one of the hard drives fails or is removed, the duplicator dock
will enter a failed state and a buzzer will sound once per second.
Use the <UP> and <DOWN> arrows to display information on either Drive1 (Source) or Drive2
(Destination).
Reconnect a hard drive to the appropriate Source of Destination side and the duplicator dock
will automatically prompt for a rebuild.
The progress of the rebuild will be displayed, including the transfer speed, percentage complete
and a countdown timer to completion.
Instruction Manual
Function
Two independent disks
Striped drives for maximum data transfer rates. Com-
bined capacity will be double the smallest drive. No
redundancy/backup.
Mirroring a single drive to create two exact copies.
Concatenate two drives to create a single large disk.
