StarTech.com SATDUP13 Quick Install Manual

Quick Install Guide
1 to 3 Standalone Hard Drive Duplicator and Eraser
SATDUP13
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
NOTE: Please visit www.startech.com/downloads for the full
set of operating instructions.
Front
1. Display Screen
2. Navigation buttons
3. OK button
4. Esc button
5. SATA HDD source port
6. SATA HDD destination ports
1
Back
1. Power Switch
2. Power Adapter Port
3. Daisy Chain ports
1

Packaging Contents

• 1X – 1 to 3 HDD Duplicator/Eraser
• 4X – SATA Cables
• 1X – Power Adapter
• 3X – Power Cords (NA, UK, EU)
• 1X – Instruction Manual
For the most up-to-date information, please visit: www.startech.com
WARNING! Hard drives and storage enclosures require careful
handling, especially when being transported. If you are not careful
with your hard disk, lost data may result. Always handle your hard
drive and storage device with caution. Be sure that you are properly
grounded by wearing an anti-static strap when handling computer
components or discharge yourself of any static electricity build-up
by touching a large grounded metal surface (such as the computer
case) for several seconds.

Hardware Installation

1. Ensure the power switch is set in the off position. Connect the
included power adapter from an available AC power outlet to the
Power Adapter Port on the back of the SATDUP13.
2. Using an included SATA Cable, attach the HDD you would like to
duplicate to the source port (first port on the left, see below)
3. Using an included SATA Cable, connect up to 3 HDDs you would
like to have over written, or erased to the destination ports. (3
ports from right to left , see below)
WARNING! Any Data remaining on the destination drives will be
over written.
Note: If using less than 3 HDDs, drives should be connected from
left to right leaving port(s) closest to the right unoccupied.
4. Press the power switch to the "On" position, the SATDUP13 is now
ready to use.

Hardware Operation

Hard Drive Duplication

1. Using the Navigation buttons, locate "HDD Duplicator 1. Copy"
and press OK. Default copy mode is "System and Files"
Manual Revision: 07/23/2013
