- Page 1 1:1 HDD/SSD Duplicator with Image Library Backup & Restore Actual product may vary from photos User Manual SKU#:SATDUP11IMG For the latest information and specifications visit www.startech.com/SATDUP11IMG Manual Revision: 02/25/2020...
-
Page 2: Compliance Statements
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual... -
Page 3: Safety Statements
を行い、 電気障害やつまづきの危険性など、 安全上のリスクを回避するよう にしてください。 Misure di sicurezza • I terminiali dei fili elettrici non devono essere realizzate con il prodotto e/o le linee elettriche sotto tensione. • I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati e stesi in modo da evitare pericoli di inciampo, rischi di scosse elettriche o pericoli per la sicurezza. Säkerhetsåtgärder • M ontering av kabelavslutningar får inte göras när produkten och/eller elledningarna är strömförda. • K ablar (inklusive elkablar och laddningskablar) ska dras och placeras på så sätt att risk för snubblingsolyckor och andra olyckor kan undvikas. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 4: Table Of Contents
Requirements ............................. 6 Hardware Installation ................7 Operation ....................9 Copy Function ............................9 Compare ............................... 10 Copy & Compare............................11 Image Manager ............................11 Utility ................................13 Setup................................15 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 5: Product Diagram
Front View Source HDD Status LEDs SATA HDD Source Port Up Navigation Button Down Navigation Button OK Button Esc Button SATA HDD Target Port Target HDD Status LEDs To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 6: Rear View
Rear View Power Switch Power Adapter Port To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 7: Product Information
Power Cords (NA, UK, EU) x 3 • HDD Pads x 2 • User Manual x 1 • Requirements Source Drive x 1 • Target Drive x 1 • To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 8: Hardware Installation
SATA Port on an Enclosure or Docking Station. Note: The Source Drive can be a drive you intend to make an exact copy of, or an Image drive containing several hard drive images. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 9 Source Drive. Then place the Target Drive on the HDD Pad on top of the Source Drive. Move the Power Switch on the Duplicator to the On position. The Duplicator is now ready to use. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 10: Operation
Image - HDD: The Image to HDD enables you to restore an • HDD Image from an Image Library Drive. HDD - HDD: The HDD to HDD enables you to copy one • hard drive exactly to another. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 11: Compare
Source HDD. Note: Please be sure to select the sub-menu option that cor- responds with the Copy Selection (i.e. IMG->HDD, HDD -> IMG, or HDD -> HDD). To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 12: Copy & Compare
Enables you to rename images on your image drive, follow the below steps to rename a specific image on your drive. From the Function Table (on screen), select Image Manager >> Rename Image. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 13 Warning! All data stored on the drive connected to the target port will be deleted. From the Function Table (on screen), select Image Manager >> 4.Format HDD. Press the OK button to confirm your format. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 14: Utility
The Device Power Cycle function displays the number of times the HDD has been turned on and off. Power-on Hours The Power-on Hours function displays the total number of hours the HDD has been powered-on. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 15 Update System From the Update System menu you can perform a BIOS update or create an update hard drive to perform a BIOS update. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 16: Setup
BIOS and press the OK button. The update will take place, and the on screen display will alert you upon completion. Setup From the Setup function you can access different advanced configurations. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 17 The Skip Error function allows you to define a number of acceptable sector errors during the duplication process in the event that the hard drive has bad sectors on it. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 18 This function is used to set the time of motor stopping after finishing function executing. Restore Default: The Restore Default function sets the • duplication setting back to the original configuration. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 19 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 20 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 21 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 22 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 23 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 24 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 25 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 26 Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
- Page 27 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
