1:1 HDD/SSD Duplicator with Image
Library Backup & Restore
SATDUP11IMG
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 08/25/2014
*actual product may vary from photos
Advertisement
Table of Contents
Related Manuals for StarTech.com SATDUP11IMG
Summary of Contents for StarTech.com SATDUP11IMG
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 08/25/2014...
-
Page 2: Fcc Compliance Statement
StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby... -
Page 3: Table Of Contents
Table of Contents Product Diagram ..................1 Front View ..............................1 Rear View ..............................1 Introduction ....................2 Packaging Contents ..........................2 Hardware Installation ................2 User Menu Table of Contents ...............5 User Menu Table of Contents ...............6 Hardware Operation ................6 1. Copy ................................6 2. -
Page 4: Product Diagram
Product Diagram Front View SATA HDD Source Port Display Screen Navigation Buttons Ok Button Esc Button SATA HDD Target Port Rear View Power Switch Power Adapter Port Instruction Manual... -
Page 5: Introduction
(such as the computer case) for several seconds. 1. Ensure the power switch is set in the off position. Using the included Universal Power Adapter, connect the Power Adapter Port on the back of the SATDUP11IMG to an available power outlet. Instruction Manual... - Page 6 2. Connect your Source drive to the SATA SSD/HDD Source Port on the SATDUP11IMG. Note: The Source Drive can be a drive you intend to make an exact copy of, or an Image drive containing several hard drive images. a) If the source drive is a SATA HDD/SSD, use the included Short SATA cable or the included Long SATA cable if the drive is installed into a PC chassis.
- Page 7 4. For added drive protection and heat insolation, place the source drive and target drive on top of each, of the included SSD/HDD Pads. 5. Set the Power Switch to the on position. The SATDUP11IMG is now ready to use. Instruction Manual...
-
Page 8: User Menu Table Of Contents
User Menu Table of Contents 1.1 HDD > Image 1. Copy 1.2 Image > HDD 1.3 HDD > HDD 2.1 HDD > Image 2. Compare 2.2 Image > HDD 2.3 HDD > HDD 3.1 HDD > Image 3.2 Image > HDD 3. -
Page 9: User Menu Table Of Contents
User Menu Table of Contents 6.1.1 System and Files 6.1.2 ALL Partitions 6.1 Copy Area 6.1.3 Whole HDD 6.1.4 Percentage 6.2 Skip Error 6. Setup 6.3 Language 6.4.1 Unknown Format 6.4 Advanced Setup 6.4.2 Stop Motor Time 6.5 Restore Defaults Hardware Operation 1. - Page 10 2. Using the UP/DOWN Navigation buttons and the Display Screen, locate 1.HDD -> Image, on the [Copy] sub menu, and press the OK button. 3. The SATDUP11IMG will analyze the source drive and ensure the target drive is ready, by verifying size and format.
- Page 11 5. Once the drives have been analyzed (and if necessary, formatted the SATDUP11IMG will begin to copy your SSD/HDD image to the Image Drive. 6. The image will be completely copied when the % indicator on the Display Screen reaches 100%. The image drive now contains the drive image (and if working with a non-formatted drive, an image drive has also been created.)
- Page 12 1. The SATDUP11IMG will analyze the source Image Library Drive and ensure the target drive is ready, by verifying size and format. Using the UP/DOWN Navigation buttons and the Display Screen, select the drive image you would like to copy over to the target drive and press the OK button.
- Page 13 2. Using the UP/DOWN Navigation buttons and the Display Screen, locate 3. HDD-> HDD, on the [Copy] sub menu, and press the OK button. 3. The SATDUP11IMG will analyze the source drive and ensure the target drive is ready, by verifying drive size, and begin the duplication process.
-
Page 14: Compare
4. The drive duplication will be complete when the % indicator on the Display Screen indicates the duplication has reached 100%. The target drive is now a duplicate of the source drive. 2. Compare The Compare function can be used after your duplication is finished, to confirm the data on the target HDD is identical to the source HDD. -
Page 15: Image Manager
4.2 / 4.3 / 4.4 / 4.5] for details. Note: Ensure your Image drive is connected to the target port on the SATDUP11IMG for the below operations. 4.1 Show HDD Info Displays Disk information from the physical hard drive being used as your image drive. -
Page 16: Utility
4.4 Format HDD #2 Enables you to delete the data on the target drive and prepare it to be a new Image Library Drive. Follow the below steps to format and create your Image Library Drive. WARNING! All data stored on the drive connected to the target port will be deleted. - Page 17 5.1.3 Serial Number The Serial Number function displays the serial number of the connected HDD [Disc Info.] Serial N0.: WD-WXB1A91M3998 1. Serial Number 5.1.4 Device Power Cycle The Device Power Cycle function displays the number of times the HDD has been turned on and off.
- Page 18 5.1.7 Off-Line Scan Uncorrectable The Off-Line Scan Uncorrectable Sector Count function displays the volume of sectors that are uncorrectable when scanned off-line. The higher the uncorrectable sector volume is, the more seriously the HDD is damaged. [Disc Info.] [Off-Line Scan uncorrecta] 8.
- Page 19 BIOS update. Follow the steps below for details. 5.3.1 Update Bios If an update to the device firmware is available on the StarTech.com product page, this option can be used to update the device. The steps below outline the steps for executing a system update.
-
Page 20: Setup
6. Setup From the Setup function you can access different advanced configurations. See the list below outlining the details of each option. Refer to functions [6.1 – 6.5] for details. 6.1 Copy Area The Copy Area function enables you to adjust the mode in which the hard drives are copied. - Page 21 6.1.2 All Partitions This mode will copy all of the partitions bit for bit including the free space. It can support all of the formats 6.1.3 Whole HDD This mode will copy the entire HDD, regardless of the content, format, partition, or free space, and it will take much more time to duplicate the source HDD completely.
- Page 22 6.2 Skip Error The Skip Error function allows you to define a number of acceptable sector errors during the duplication process in the event that the hard drive has bad sectors on it. 6.3 Language The Language function allows you to set is to set the language the menu is displayed 6.4 Advanced Setup From Advanced Setup you can adjust HDD Wait Time, and lock the keys, see details below.
-
Page 23: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 24 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
