Introduction The StarTech.com UNIDUPDOCK functions as both a convenient hard drive copying/imaging solution and an external USB to SATA/IDE HDD docking station for 2.5” (up to 500Gb) or 3.5” hard drives (up to 2 TB). Packaging Contents • 1 x UNIDUPDOCK duplicator dock • 1 x USB cable... -
Page 5: Product View
Product View Built-in LCD screen Configuration buttons LP4 molex connector USB connector 40-pin IDE connector ON/OFF switch Power connector 7+15 SATA connector Configuration Buttons Button Function Navigate Up Navigate Down Enter Cancel RESET Reset duplicator dock (soft) MUTE Mute buzzer sounds Instruction Manual... -
Page 6: Installation
Installation WARNING: Hard drives require careful handling, especially when being transported. If you are not careful with your hard disk, lost data may result. Always handle your hard drive and storage device with caution. Hardware Installation 1. Plug the universal power adapter into a wall power outlet and into the DC In connector on the duplicator dock. - Page 7 7. Follow the same procedure for either a SATA or IDE hard drive for the Destination side of the duplicator dock. NOTE: SATA and IDE hard drives can be mixed, so one side can be SATA while the other is IDE. 8.
-
Page 8: Driver Installation
Driver Installation No driver installation is required for any supported operating system, as this hard drive dock is natively supported, so the drivers are already installed. How to Use Menu Options Copy HDD • Perform a 1:1 sector clone from the Source disk to the Destination disk. Each disk sector on the Source disk will be copied, regardless if it contains data or not. - Page 9 Compare HDD • Compares the sectors on the Source disk to the Destination disk. Used to ensure that the Copy operation was successful. Pre-scan • Scans the Source disk for bad sectors/blocks and reports the errors. Rescan Bus • Rescans the hard drive connectors on the duplicator dock to detect new/swapped drives. Source Size • Displays the total storage capacity of the Source disk.
-
Page 10: Advanced Menu Options
Advanced Menu Options The Advanced Menu can be access from the main menu by pressing and holding the <ESC> button for several seconds. Rescan Bus Delay • Sets the time interval delay before starting “Rescan Bus” from the main menu. Read Error Skip • Ignore any read errors (sector or block) detected during the copying process. -
Page 11: Duplicator (Copy) Mode
Duplicator (Copy) Mode Use the <UP> and <DOWN> arrows on the duplicator dock to select the Copy HDD mode and press the ENT button to activate. The LCD screen will display transfer rates, progress percentage, amount of data copied and a countdown timer. NOTE: As the duplicator dock creates a 1:1 copy, the Destination disk must be of equal or greater capacity than the Source disk. -
Page 12: Available Raid Modes
Available RAID Modes Mode Function Normal Two independent disks Striped drives for maximum data transfer rates. Com- RAID0 bined capacity will be double the smallest drive. No redundancy/backup. RAID1 Mirroring a single drive to create two exact copies. JBOD Concatenate two drives to create a single large disk. RAID 1 Rebuild When operating in RAID1 mode, if one of the hard drives fails or is removed, the duplicator dock will enter a failed state and a buzzer will sound once per second. -
Page 13: Specifications
Specifications Bus Interface USB 2.0 Chipset ID ACARD ARC286 2 x 7+15 SATA connector 2 x 40-pin IDE male Connectors 2 x LP4 molex male 1 x USB type B 1 x DIN power connector LEDs 4 x Disk Power/Activity 0, 1, JBOD (concatenation), single RAID Modes disks... -
Page 14: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 15 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
