Portable 1:5 USB Flash Drive
Duplicator and Eraser
USBDUP15
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 07/23/2014
*actual product may vary from photos
Advertisement
Table of Contents
Related Manuals for StarTech.com 8STUSBDUP15
Summary of Contents for StarTech.com 8STUSBDUP15
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 07/23/2014...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Product Diagram ..................1 Top View ............................... 1 Back View ..............................1 Introduction ....................2 Packaging Contents ..........................2 System Requirements ..........................2 Hardware Setup ..................3 User Menu Table of Contents ........................ 4 Hardware Operation ..........................5 1.2 Asynchronous Copy .......................... 6 2. -
Page 4: Product Diagram
Product Diagram Top View 1. Source USB drive port 2. Destination USB drive ports 3. LCD Display 4. Forward button 5. Backward button 6. OK button 7. Escape button Back View 1. Power Adapter Port 2. Power Switch Instruction Manual... -
Page 5: Introduction
Introduction Packaging Contents • 1x 1:5 USB Flash Drive Duplicator (USBDUP15) • 1x Universal Power Adapter (NA/UK/EU) • 1x Instruction manual System Requirements • 1x Source USB drive • 1 to 5x Destination USB drive(s) • (Optional) USB multimedia card reader (1 x each drive): To use an SD/ SDHC/ Micro SD/ MMC/ Mini SD/ CF card as Source or Destination drive. -
Page 6: Hardware Setup
Hardware Setup Note: a) Before you begin ensure the power switch on the USBDUP15 is set to the off position. b) The source or destination drives can be replaced with any SD/ SDHC/ Micro SD/ MMC/ Mini SD/ CF media card, using USB multimedia card reader (sold separately), or Hard Drive(HDD) / Solid State Drive (SSD) through a Hard Drive docking station or USB enclosure (sold separately). -
Page 7: User Menu Table Of Contents
User Menu Table of Contents Instruction Manual... -
Page 8: Hardware Operation
Hardware Operation 1. Copy There are two types of copy modes, Asynchronous Copy and Synchronous Copy. The system will check the content size of the source before executing the ‘copy’ function. If the source content size is less than the system’s buffer memory, it will automatically start an Asynchronous copy. -
Page 9: Asynchronous Copy
3. When the copy has completed, the LCD display will show the total time it took to copy, the number of passes, and if there were any failures. NOTE: a) When the copy is in progress, the green LED will flash for each Flash drive that is connected. -
Page 10: Compare
2. Once the copy has completed, the green LED will stop blinking. The destination Flash drive can be removed and a new Flash drive inserted, then the copy will automatically start again. The LCD display will show the accumulated quantity of the successful/failed duplications and the drive that is still copying. -
Page 11: Capacity Check
4. Capacity Check Check the exact capacity of the connected Flash drive in the destination slots. 1. Plug the Flash drive into the slot and press OK on Capacity Check. The system will quickly report the exact capacity of the connected Flash drive by reporting either a green or red LED. -
Page 12: Utility
5.2 System Information This function will show information about the system, including model number and software version. 6. Utility 6.1 Do Format Insert a Flash drive device into one of the destination slots and press OK to begin formatting. 1. This function will automatically detect the capacity of the Flash drive and format accordingly. -
Page 13: Measure Speed
6.2 Measure Speed Measure the read and write speeds of the Flash drive. 1. Plug the Flash drive into one of the slots and select function “6.2 Measure Speed”, then press OK. 2. Use the up and down arrows to see the Flash drive’s exact read and write speeds for each port. -
Page 14: Setup
6.3.4 Setup Error Limit Set the tolerance range when checking for errors on the Flash drive. Use the up and down arrows to set the percentage. 6.4 Quick Erase Erase the Flash drive’s data content. Use the up and down arrows to check each port’s status. - Page 15 7.2.2 Whole Media Set the system to copy the entire Flash drive’s content, including empty space and file format. 7.3 Button Beep Turn audio feedback ON/OFF. ON by default. 7.4 Asyn Hold time Set the time to cancel an Asynchronous copy when you’ve temporarily finished copying and all of the Flash drive devices have been removed, but the copy job has not been manually cancelled.
- Page 16 7.10 Working Mode There are 5 duplication speeds: • Slowest Mode • Slower Mode • Normal Mode (default setting) • Faster Mode • Fastest Mode Change the duplication speed. Normal speed is recommended for most Flash drive types. If there is a high failure rate when duplicating, try lowering the speed. 7.11 Set HDD Mode Choose ‘Active Mode’...
-
Page 17: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 18 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
