MVE-AH020Q

HDMI Extender Over Single Cat5e/6

Manual

Up to

1080p

Resolution

Up to 164' (50m)

Extend HDMI over a single inexpensive Cat5e/6 cable.

Supports resolution from 480i to 1080p with zero signal loss.

Transmits up to 164' (50m) at 1080p over a Cat6 cable.

Plug and play operation—comes as a complete set.

NOTE: Model numbers that end with ―Q‖ or products that have a round green ―Q‖ sticker signify RoHS compliance.

Table of Contents

Need help?

Do you have a question about the MVE-AH020Q and is the answer not in the manual?

Page 1 MVE-AH020Q HDMI Extender Over Single Cat5e/6 Manual Up to 1080p Resolution Up to 164’ (50m) Extend HDMI over a single inexpensive Cat5e/6 cable. Supports resolution from 480i to 1080p with zero signal loss. Transmits up to 164’ (50m) at 1080p over a Cat6 cable.
Page 2: Specifications
Zero Signal Loss – Integrated circuits in the transmitter and receiver clean, buffer, and amplify the HDMI signal to prevent signal loss and ensure a clear signal regardless. DVI Support – The MVE-AH020Q can be used with an HDMI to DVI adapter to support multiple components of a home theater system.
Page 3 Two (2) HDMI cables are required. Installation: 1. Determine the location where the MVE-AH020Q units will be wired as well as how much Cat5e/6 cable will be necessary. 2. Connect the transmitter to the HDMI output of the source device.
Page 4: Troubleshooting
ENFORCER HDMI Extender over Single Cat5e/6 Troubleshooting HDMI device does not function correctly Make sure the extender is powered on both sides. Make sure the source and display are powered. Test the Cat5e/6 cable between the receiver and transmitter and make sure it is functional.
