ENFORCER MVE-AH030Q Manual

Hdmi extender over single cat5e/6
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MVE-AH030Q
HDMI
Extender over Single Cat5e/6
®
Manual
Up to
1080p
Resolution
Up to 196' (60m)
• Extend HDMI over a single Cat5e/6 cable.
• Supports resolutions from 480i to 1080p with zero signal loss.
• Transmits up to 196' (60m) at 1080p over a Cat6 cable.
• Plug and play operation — comes as a complete set.
• Bi-directional IR for remote control extension.
• Multiple EDID management settings.
• ARC/Digital Audio Out for integration with existing sound systems.
• HDMI loop output for local HDMI output.
• Two (2) 5VDC power supplies included.
Note: Model numbers that end with "Q" or that have a round green "Q" sticker signify RoHS-compliant products.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MVE-AH030Q and is the answer not in the manual?

Questions and answers

Related Manuals for ENFORCER MVE-AH030Q

Summary of Contents for ENFORCER MVE-AH030Q

  • Page 1 MVE-AH030Q HDMI Extender over Single Cat5e/6 ® Manual Up to 1080p Resolution Up to 196’ (60m) • Extend HDMI over a single Cat5e/6 cable. • Supports resolutions from 480i to 1080p with zero signal loss. • Transmits up to 196’ (60m) at 1080p over a Cat6 cable.

  • Page 2: Table Of Contents

    Warranty ............................8 Introduction: The ENFORCER HDMI Extender over Single Cat5e/6 extends the range of traditional HDMI cabling methods by using an active transmitter and receiver to send video and audio over a single Cat5e/6. HDMI formats as large as 1080p can be transmitted up to 196ft (60m) between the two units with zero signal loss by using integrated circuits in the receiver and transmitter.

  • Page 3: Specifications

    ® ENFORCER HDMI Extender over Single Cat5e/6 Specifications: Input Video signal 3.3V Input DDC signal 5Vp-p (TTL) Maximum single link range 1080p Deep color 24bit Video formats supported High-speed HDMI, HDCP 1.2 Audio formats supported LPCM, Dolby-AC3, DTS7.1, DSD Output video...

  • Page 4: Overview

    ® ENFORCER HDMI Extender over Single Cat5e/6 Overview: Transmitter: Cat5e/6 HDMI Loop Output Output Power LED IR Tx Port Link LED IR Rx Port HDMI Input 5VDC Input EDID Switch ARC Option Receiver: Switch 5VDC Input Digital Audio IR Rx Port...

  • Page 5: Bi-Directional Ir

    The MVE-AH030Q supports bi-directional IR pass-through signals. This allows for remote operation of either the source device from the display location, or the display device from the source location. The MVE-AH030Q bi-directional IR Transmitter unit and IR Receiver unit support signals from 20~60 kHz.

  • Page 6: Digital Audio Out

    This HDMI output can be used for local displays that are in the same location as the HDMI source. Installation: 1. Determine the location where the MVE-AH030Q units will be wired as well as how much Cat5e/6 cable will be necessary.

  • Page 7: Sample Application

    ® ENFORCER HDMI Extender over Single Cat5e/6 Sample Application: Cable Legend: Local Display HDMI Power Cat5e/6 Digital Audio HDMI Loop Output Transmitter HDMI Input 5VDC IR Tx Source Cat6 Up to 196ft (60m) A/V Receiver 5VDC Digital Audio Out Receiver...

  • Page 8: Troubleshooting

    ® ENFORCER HDMI Extender over Single Cat5e/6 Troubleshooting: • Use T568-B wiring standard • Make sure the extender is powered on both sides. • Make sure the source and the display are powered. HDMI device does not function • Test the Cat5e/6 cable between the receiver and correctly transmitter and make sure it is functional.
