Models 110, 111 & 112
Calibration Information
4. Press the yellow
5. Repeat steps 1 through 4 until the display shows "End". This indicates that the calibration procedure
is complete. Press the yellow
Calibration Settings
The "Seconds to settle" column does not include calibrator settling time.
Step
Number
(switch position)
C-01
C-02
C-03
C-04
C-05
Step
Number
(switch position
C-01
C-02
C-03
C-04
C-05
C-06
(use Amps jack)
Display Messages
If the calibration procedure is not completed correctly, the Meter will not operate correctly. If calibration
is not completed correctly, the Meter alternates the messages "CaL" and "Err" on the display and you will
need to recalibrate the Meter. The meter is damaged and requires service if:
"CaL" and "Err" messages continue to appear after a proper recalibration.
"EEPr" and "Err" messages are alternating on the display.
"EEPr" message appears on the display.
14
button to proceed to the next step. The Meter records a new constant.
Hz
Hz
button to resume normal operation, or switch the Meter off.
Table 4. Calibration Settings for the Fluke 110
Function
Input value
B
6.000 V
- Hz
B
6.000 V
D
6.000 V
s
600 e
e
6.000 ke
Table 5. Calibration Settings for the Fluke 111 and 112
Function
Input value
B
6.000 V
- Hz
B
6.000 V
D
6.000 V
s
600 e
e
6.000 ke
I
6.000 A
Note
Frequency
(sine wave)
900.0 Hz
60 Hz
DC
N/A
N/A
Frequency
(sine wave)
900.0 Hz
60 Hz
DC
N/A
N/A
DC
Seconds
to Settle
4
2
1
1
1
Seconds
to Settle
4
2
1
1
1
1
