Define Array Definition Menu will next appear that allows drive assignments to the
disk array.
Define Array Definition Menu
Selecting an Array # from the Define Array Menu brings up the Define Array
Definition Menu screen. Under the Definition section, highlight the Array # and
use the [Space] key to cycle through three array types: Performance (RAID 0
FastBuild (tm) Utility 1.xx (c) 1995-99 Promise Technology, Inc.
Array No RAID Mode
Array 1 Stripe
Stripe Block: 64 KB
Channel:ID
1 : Master
1 : Slave
2 : Master
[ ] Up [ ] Down
Striping), Fault Tolerance (RAID 1 Mirroring, RAID 0+1 Striping/Mirroring (for 4
drives ), or Capacity (Spanning). See Auto Setup or Chapter 5 about RAID levels.
Drive Assignments Options
Under the [ Drive Assignments ] section, highlight a drive and with the [Space] bar
key change the Assignable option to "Y" to add the drive to the disk array. Press
<Ctrl-Y> to save the disk array information. Depending on the array type selected,
the following scenarios will take place:
1) If choosing a Striping, Spanning, or Mirroring/Striping array, the initial Define
Array Menu screen will appear with the arrays defined. From there you may
ESC to exit and return to the Main Menu of FastBuild.
2) If you selected a Mirroring array for two drives, there is an additional window
that appears as described in order to create the array. To do this you will use
either two brand new drives, or one drive that contains existing data that you
wish to mirror.
TM
FastBuild Configuration Setup
[ Define Array Definition Menu ]
Total Drv
2
[ Drive Assignments ]
Drive Model
MAXTOR87000A8
MAXTOR87000A8
MAXTOR87000A8
[ Keys Available ]
[ESC] Exit
Capacity(MB)
13044
Capacity (MB)
6522
6522
6522
[Space] Select [Ctrl-Y] Save
Status
Functional
Assignment
Y
N
Y
4-6
