Overview

The 672T and 672R are an optical fiber transmitter and receiver for
computer graphics signals up to UXGA and stereo audio signals. The 672T
converts the computer graphics and stereo audio signals to an optical signal,
and the 672R converts the optical signal back to computer graphics and
stereo audio signals.
Together, the 672T and 672R form a UXGA/audio transmitter/receiver over
multimode fiber system.
The 672T and 672R pair features:
•
A transmission range exceeding 1700 meters (more than 1 mile) over
multimode optical cable
•
Up to 1.65Gbps bandwidth per graphic channel
•
Regulation in accordance with Class 3R Laser Eye Safety in
compliance with ANSI Z136 and IEC 60825-1:2007
•
Full compatibility with the Kramer 670T/670R and 671T/671R
HDMI/DVI transmitters and receivers for non-HDCP content
•
5V DC power adapters
•
Housing in Kramer DigiTOOLS
3.1

Recommendations for Achieving the Best Performance

To achieve the best performance:
•
Use only good quality connection cables
deterioration in signal quality due to poor matching, and elevated noise
levels (often associated with low quality cables).
•
Avoid interference from neighboring electrical appliances that may
adversely influence signal quality and position your Kramer 672T,
672R away from moisture, excessive sunlight and dust
1 Suitable for resolutions up to UXGA at 60Hz, and for all HD resolutions
2 Available from Kramer Electronics on our Web site at
Overview
®
enclosures
2
to avoid interference,
http://www.kramerelectronics.com
