Summary of Contents for Kramer DigiTOOLS 672T
-
Page 1: User Manual
Kramer Electronics, Ltd. Preliminary USER MANUAL Models: 672T , UXGA Audio Optical Transmitter 672R , UXGA Audio Optical Receiver... -
Page 2: Table Of Contents
Figure 2: 672R UXGA and Audio Optical Receiver Figure 3: Connecting the 672T/672R Transmitter/Receiver System Tables Table 1: 672T UXGA and Audio Optical Transmitter Features Table 2: 672R UXGA and Audio Optical Receiver Features Table 3: 672T, 672R Technical Specifications... -
Page 3: Introduction
GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products 2 Not supplied with the machine 3 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com 4 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com... -
Page 4: Quick Start
Getting Started Quick Start This quick start chart summarizes the basic setup and operation steps. KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 5: Overview
Overview Overview The 672T and 672R are an optical fiber transmitter and receiver for computer graphics signals up to UXGA and stereo audio signals. The 672T converts the computer graphics and stereo audio signals to an optical signal, and the 672R converts the optical signal back to computer graphics and stereo audio signals. -
Page 6: Your Uxga And Audio Optical Transmitter And Receiver
Table 1 define the 672T UXGA and Audio Optical Transmitter: Figure 1: 672T UXGA and Audio Optical Transmitter Table 1: 672T UXGA and Audio Optical Transmitter Features Feature Function UXGA IN 15-pin HD Connector Connects to the computer graphics source AUDIO IN 3.5mm Mini Jack Connector... -
Page 7: Your 672R Uxga And Audio Optical Receiver
Illuminates when receiving power Connecting the 672T and 672R Transmitter/Receiver System To connect the 672T and 672R, do the following: 1. Connect a computer graphics source (for example, a computer graphics card on a PC) to the UXGA IN 15-pin HD connector. -
Page 8: Figure 3: Connecting The 672T/672R Transmitter/Receiver System
Connecting the 672T and 672R Transmitter/Receiver System 5. On the 672R, set the SOURCE switch to VGA. (If a Kramer 670T or 671T transmitter is connected to the 672R, set the SOURCE switch to HDMI). 6. Remove the dust caps and connect the OPTIC CABLE connector of the 672T to the OPTIC CABLE connector of the 672R, via OM3 cabling (maximum range of 1700 meters (over 1 mile)). -
Page 9: Technical Specifications
Technical Specifications Technical Specifications The 672T, 672R technical specifications are shown in Table Table 3: 672T, 672R Technical Specifications 672T 672R INPUTS: 1 VGA on a 15-pin HD connector, 1 fiber optic on an SC connector for multimode (OM3) fiber cable 1 unbalanced stereo audio on a 3.5mm connector... - Page 10 EXCLUSION OF DAMAGES The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall not be liable for: 1. Damage to other property caused by defects in this product, damages based upon inconvenience, loss of use of the product, loss of time, commercial loss;...
- Page 11 For the latest information on our products and a list of Kramer distributors, visit our Web site: www.kramerelectronics.com, where updates to this user manual may be found. We welcome your questions, comments and feedback. Safety Warning: Disconnect the unit from the power supply before opening/servicing.
