Summary of Contents for Kramer 670T
- Page 1 K R A ME R E LE CT R O N IC S L TD . USER MANUAL MODEL: 670T HDMI Optical Transmitter 670R HDMI Optical Receiver P/N: 2900-000483 Rev 6...
-
Page 3: Table Of Contents
Introduction Getting Started Achieving the Best Performance Safety Instructions Recycling Kramer Products Overview Defining the 670T, 670R HDMI Optical Transmitter/Receiver Connecting the 670T, 670R Technical Specifications Figures Figure 1: 670T HDMI Optical Transmitter Figure 2: 670R HDMI Optical Receiver Figure 3: Connecting the 670T/670R Transmitter/Receiver System... -
Page 4: Introduction
Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront video, audio, presentation, and broadcasting professionals on a daily basis. In recent years, we have redesigned and upgraded most of our... -
Page 5: Getting Started
Avoid interference from neighboring electrical appliances that may adversely influence signal quality Position your Kramer 670T, 670R away from moisture, excessive sunlight and dust This equipment is to be used only inside a building. It may only be connected to other equipment that is installed inside a building. -
Page 6: Safety Instructions
Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at http://www.kramerelectronics.com/support/recycling/. -
Page 7: Overview
Overview The 670T converts the HDMI signal to an optical signal, and the 670R converts the optical signal back into an HDMI signal. Together, the 670T and 670R form an HDMI transmitter/receiver over multimode fiber system. The 670T and 670R pair features: ... -
Page 8: Figure 1: 670T Hdmi Optical Transmitter
3.1.1 Your 670T HDMI Optical Transmitter Figure 1 defines the 670T HDMI Optical Transmitter: Figure 1: 670T HDMI Optical Transmitter Feature Function HDMI IN Connector Connects to the HDMI source CONNECTED FIBER Illuminates when the fiber optic cable is connected... -
Page 9: Figure 2: 670R Hdmi Optical Receiver
VIDEO DETECT LED Indicates a valid video signal on the transmitter side ON LED Illuminates when receiving power Connect to the optical connector on the 670T OPTIC CABLE Connector (remove dust cap prior to use) 5V DC +5V DC connector for powering the unit... -
Page 10: Connecting The 670T, 670R
LCD display). 3. Remove the dust caps and connect the OPTIC CABLE connector of the 670T to the OPTIC CABLE connector of the 670R, via optic OM3 cabling with SC connectors (maximum range of 1700 meters (over 5570ft)). 4. Connect the 5V DC power adapter to the power socket on each unit and...
