- Page 1 K R A ME R E LE CT R O N IC S L TD . USER MANUAL MODELS: 640T HDMI–Coax Transmitter 640R Coax–HDMI Receiver P/N: 2900-000354 Rev 9...
-
Page 3: Table Of Contents
640R Coax-HDMI Receiver Your 640T/640R HDMI/Coax Transmitter/Receiver Your 640T HDMI-Coax Transmitter Your 640R Coax-HDMI Receiver Connecting the 640T/640R Technical Specifications Figures Figure 1: 640T/640R HDMI/Coax Transmitter/Receiver Figure 2: 640R Coax-HDMI Receiver Figure 3: HDMI-to-Coax Transmitter and Receiver System 640T/640R – Contents... -
Page 4: Introduction
Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront the video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we have redesigned and upgraded... -
Page 5: Getting Started
Achieving the Best Performance To achieve the best performance: Use only good quality connection cables (we recommend Kramer high- performance, high-resolution cables) to avoid interference, deterioration in signal quality due to poor matching, and elevated noise levels (often associated with low quality cables) ... -
Page 6: Safety Instructions
Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at http://www.kramerelectronics.com/support/recycling/. -
Page 7: Overview
640R receiver. Compatible with a Kramer transmitter and via a Kramer external remote IR receiver: C-A35M/IRR or C-A35M/IRE or C-A35M/2IRE. -
Page 8: 640R Coax-Hdmi Receiver
640T. It decodes the R-G-B, clock and data components and converts them to an HDMI output. Compatible with a Kramer transmitter and via a Kramer external remote IR receiver: C-A35M/IRR or C-A35M/IRE or C-A35M/2IRE. -
Page 9: Your 640T/640R Hdmi/Coax Transmitter/Receiver
Your 640T/640R HDMI/Coax Transmitter/Receiver This section defines the 640T HDMI-Coax Transmitter (see Section 4.1) and 640R Coax-HDMI Receiver (see Section 4.2). Your 640T HDMI-Coax Transmitter Figure 1 defines the 640T: Figure 1: 640T/640R HDMI/Coax Transmitter/Receiver Feature Function IR Connector Connects to an IR sensor or transmitter... -
Page 10: Your 640R Coax-Hdmi Receiver
BLUE Input BNC Connector Receives the clock signal from the 640T CLK Input BNC Connector PWR Input BNC Connector Receives power and the IR signal from the 640T 12V DC +12V DC connector for powering the unit 640T/640R - Your 640T/640R HDMI/Coax Transmitter/Receiver... -
Page 11: Connecting The 640T/640R
Connect the 640T red, green, blue, clock, and power BNC connectors to the 640R red, green, blue, clock, and power BNC connectors Connect one 12V DC power supply to either the 640T or the 640R (not shown in Figure 3). -
Page 12: Figure 3: Hdmi-To-Coax Transmitter And Receiver System
Figure 3: HDMI-to-Coax Transmitter and Receiver System 640T/640R - Connecting the 640T/640R... -
Page 13: Technical Specifications
12.1cm x 7.2cm x 2.4cm (4.7" x 2.8" x 1.0"), W, D, H WEIGHT: 0.3kg (0.7lbs) approx. ACCESSORIES: Power supply OPTIONS: Kramer external remote IR receiver C-A35M/IRR or C-A35M/IRE or C-A35M/2IRE Specifications are subject to change without notice at http://www.kramerelectronics.com 640T/640R Range Chart Cable Type... - Page 15 For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback. Web site: www.kramerelectronics.com E-mail: info@kramerel.com SAFETY WARNING...
