- Page 1 K R A ME R E LE CT R O N IC S L TD . USER MANUAL MODEL: 673T HD-SDI Optical Transmitter 673R HD-SDI Optical Receiver P/N: 2900-000485 Rev 4...
-
Page 3: Table Of Contents
Overview Defining the 673T, 673R HD-SDI Optical Transmitter/Receiver Connecting the 673T, 673R Technical Specifications Figures Figure 1: 673T HD-SDI Optical Transmitter Figure 2: 673R HD-SDI Optical Receiver Figure 3: Connecting the 673T, 673R HD-SDI Optical Transmitter/Receiver 673T, 673R – Contents... -
Page 4: Introduction
Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront video, audio, presentation, and broadcasting professionals on a daily basis. In recent years, we have redesigned and upgraded most of our... -
Page 5: Getting Started
Avoid interference from neighboring electrical appliances that may adversely influence signal quality Position your Kramer 673T, 673R away from moisture, excessive sunlight and dust This equipment is to be used only inside a building. It may only be connected to other equipment that is installed inside a building. -
Page 6: Safety Instructions
Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at http://www.kramerelectronics.com/support/recycling/. -
Page 7: Overview
BNC connectors to light pulses that are transmitted over a single multimode fiber optic cable to a 673R receiver that converts them back to serial digital signals. The 673T and 673R pair has a transmission range of 1000 meters (more than 3,200ft). -
Page 8: Defining The 673T, 673R Hd-Sdi Optical Transmitter/Receiver
Defining the 673T, 673R HD-SDI Optical Transmitter/Receiver This section describes the: 673T HD-SDI Optical Transmitter, see Section 3.1.1 671R HD-SDI Optical Receiver, see Section 3.1.2 3.1.1 Your 673T HD-SDI Optical Transmitter Figure 1 defines the 673T HD-SDI Optical Transmitter:... -
Page 9: Figure 2: 673R Hd-Sdi Optical Receiver
ON LED Illuminates when receiving power SDI OUT BNC Connector Connects to the SDI acceptor (from 1 to 4) Connects to the optical connector on the 673T via OPTIC CABLE Connector multimode fiber cable 5V DC +5V DC connector for powering the unit... -
Page 10: Connecting The 673T, 673R
HD-SDI displays). 3. Remove the dust caps and connect the OPTIC CABLE connector of the 673T to the OPTIC CABLE connector of the 673R, via OM3 cabling with SC connectors (maximum range of 900 meters (2950ft)). 4. Connect the 5V DC power adapter to the power socket on each unit and... -
Page 11: Figure 3: Connecting The 673T, 673R Hd-Sdi Optical Transmitter/Receiver
Figure 3: Connecting the 673T, 673R HD-SDI Optical Transmitter/Receiver 673T, 673R - Connecting the 673T, 673R... -
Page 12: Technical Specifications
12cm x 7.95cm x 2.76cm (4.7" x 3.1" x 1.08", W, D, H) WEIGHT: 0.3kg (0.67lbs) approx. each ACCESSORIES: 2 power supplies, bracket installation kit OPTIONS: RK-3T 19" rack mount Specifications are subject to change without notice at http://www.kramerelectronics.com 673T, 673R - Technical Specifications... - Page 14 For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback. Web site: www.kramerelectronics.com E-mail: info@kramerel.com SAFETY WARNING...
