User's Manual
EZ-DT-2 / EZ-DT-4
P/N. 920-012511-03
Rev. A, 08.2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EZ-DT-2 and is the answer not in the manual?

Questions and answers

Related Manuals for Godex EZ-DT-2

Summary of Contents for Godex EZ-DT-2

  • Page 1 User’s Manual EZ-DT-2 / EZ-DT-4 P/N. 920-012511-03 Rev. A, 08.2009...

  • Page 2: Safety Instructions

    Personen durchgeführt werden. Bei Wartungs- und Reparaturarbeiten müssen die Sicherheitsvorschriften der zuständigen Berufsverbände und Behörden unbedingt eingehalten werden. Bei Verletzungen unbedingt den Arzt aufsuchen und die gegebenenfalls die zuständigen Stellen benachrichtigen. Unterlassung kann zum Verlust der Versicherungsleistungen führen. EZ-DT-2/EZ-DT-4 User’s Manual...
  • Page 3 Always obtain first aid or medical attention immediately after an injury. Never neglect an injury, no matter how slight it seems. CAUTION Danger of explosion if battery is incorrectly replaced Replace only with the equivalent type recommended by the manufacture. Dispose of used batteries according to the manufacturer’s instructions. EZ-DT-2/EZ-DT-4 User’s Manual...

  • Page 4: Table Of Contents

    3. ACCESSORY ................15 3-1. Stripper Module Installation ..................15 3-2. Cutter Module Installation ..................... 18 3-3. EZ-DT-2 Ethernet Module Installation ................20 3-4. EZ-DT-4 Ethernet Module Installation ................23 4. PRINTER SETTING ..............25 4-1. FEED Key ........................25 4-2.

  • Page 5: Barcode Printer

    Label roll diameter: Max. 5” (127 mm) Core diameter: 1”, 1.5” (25.4 mm, 38.1 Core diameter: 1”, 1.5” (25.4 mm, 38.1 Printer Language EZPL, GEPL (Godex Eltron® Printer Language) Label design software: QLabel-IV (for EZPL only) Software Driver & DLL: Windows 2000, XP and Vista Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A &...
  • Page 6 External label roll holder for 10” (250 mm) O.D. label rolls mm) O.D. label rolls External label rewinder External label rewinder Specifications are subject to change without notice. All company and/or product names are trademarks and/or registered trademarks of their respective owners. EZ-DT-2/EZ-DT-4 User’s Manual...

  • Page 7: Communication Interface

    +5V,max 500mA PRINTER 【 】 Note The total current output from serial port can not exceed 500mA. USB Interface Connector Type : Type B PIN NO. FUNCTION VBUS Internal Interface UART1 wafer Ethernet module E_MD E_MD E_RST E_RST EZ-DT-2/EZ-DT-4 User’s Manual...

  • Page 8: Printer Parts

    1-4. Printer Parts LED Light FEED Key Top Cover Power Switch Cover Open Button Print Head Lift Label Roll Holder Print Mechanism Label Roll Core Label Guide Front Cover Piece EZ-DT-2/EZ-DT-4 User’s Manual...
  • Page 9 Platen Cover Label Sensor Platen Roller Power Socket USB Port Fan-Fold Label Insert Serial Port (RS-232) Bottom Case Cover Hang Holes EZ-DT-2/EZ-DT-4 User’s Manual...

  • Page 10: Printer Installation

    Roll Core upward. Place a new label roll onto the Label Roll Core. Flip the Label Roll Core downward and pull back the Label Roll Holder. Pull and lock the Label Roll Core to the original position. EZ-DT-2/EZ-DT-4 User’s Manual...
  • Page 11 Put the label under the Label Guide and stretch it frontward. Pull the Label Guide inward and make it fit the edge of label. Close the Top Cover to complete the label installation. EZ-DT-2/EZ-DT-4 User’s Manual...

  • Page 12: Label Roll Core Switch

    When the lock hole of Label Roll Core is on lower side, it applies to 1.5” core. 【 】 Note You can also distinguish it by the index on the Label Roll Core as shown in figure. 1.5” Core EZ-DT-2/EZ-DT-4 User’s Manual...

  • Page 13: Pc Connection

    Take the power cable, plug the cable switch to the power socket, and then connect the other end of the cable to the printer power socket. Connect the cable to the USB/ Serial port on the printer and on the PC. Power on the printer and the LED light will shine. EZ-DT-2/EZ-DT-4 User’s Manual...

  • Page 14: Driver Installation

    Select the icon of driver file and click it to start the installation. Follow the instruction on screen to keep the installation going. Then the Driver Wizard utility should run automatically. Select "Install printer drivers". Select printer model. EZ-DT-2/EZ-DT-4 User’s Manual...
  • Page 15 Finish to start copying driver files. 10. Wait for file copying finished and complete the installation. 11. After the driver installation is complete, there should be a new printer model on Windows "Printer and Faxes" setting. EZ-DT-2/EZ-DT-4 User’s Manual...

  • Page 16: Accessory

    You can also use coin or screwdriver to open the Front Cover Piece. Push the Stripper connector into printer through the cable hole as shown in figure. Place the Stripper on the fillister. Align the Stripper with 2 notches on the fillister. EZ-DT-2/EZ-DT-4 User’s Manual...
  • Page 17 Before plugging the connector into socket, please check the pin first. Lock the Bottom Case Cover. (For EZ-DT-2, please tighten the screw of Bottom Case Cover) Turn the printer back to proceed to the label installation.
  • Page 18 13. Follow the direction as shown in figure to feed the liner across the stripper. 14. Flip the stripper upward to close it. 15. Press the FEED key to adjust the position of label and complete the installation. EZ-DT-2/EZ-DT-4 User’s Manual...

  • Page 19: Cutter Module Installation

    Place the printer on a horizontal surface and open the Top Cover. Remove the Front Cover Piece. Push the Cutter connector into printer through the cable hole as shown in figure. Place the Stripper on the fillister. EZ-DT-2/EZ-DT-4 User’s Manual...
  • Page 20 】 Note Before plugging the connector into socket, please check the pin first. Lock the Bottom Case Cover. ( For EZ-DT-2, please tighten the screw of Bottom Case Cover) Turn the printer back to proceed to the label installation. Follow the instruction on Chapter 2-1 to install the label.

  • Page 21: Ez-Dt-2 Ethernet Module Installation

    Unplug the power connector on the mainboard. Remove the middle compartment and the top cover together with the mainboard. Turn over the middle c ompartment and the top cover to the left side of m ainboard. EZ-DT-2/EZ-DT-4 User’s Manual...
  • Page 22 Please arrange the Module Connection Wire to keep it away from the hole which is marked with circle in figure. 15. Tighten the Ethernet Module screw and Ground wire screw to secure the Ethernet Module on the mainboard. EZ-DT-2/EZ-DT-4 User’s Manual...
  • Page 23 Note After the Ethernet module installation is completed, please send the "^XSET,USBETHERNET,1" printer command to printer for activating the Ethernet connection function. Please mind that USB port will be deactivated once the Ethernet connection function is activated. EZ-DT-2/EZ-DT-4 User’s Manual...

  • Page 24: Ez-Dt-4 Ethernet Module Installation

    Remove the Front Cover Plate. Lift the middle compartment and the top cover up. Loosen hexagonal screws on both sides of RS-232 port. Push the mainboard slightly to the direction that i ndicated in figure. Remove standard Back Panel from printer. EZ-DT-2/EZ-DT-4 User’s Manual...
  • Page 25 After the Ethernet module installation is com leted, please send the "^ ET,USBE THERNET,1" printer command to rinter for activating the Ethernet connection function. Please mind that USB port will be deactivated once the Ethernet connection function is activated. EZ-DT-2/EZ-DT-4 User’s Manual...

  • Page 26: Printer Setting

    LED light turn to flash red and then release the FEED key. Printer will automatically detect the label and record it. A Self-Test page will be printed out a fter Auto Sensing is completed and the printer goes back to standby mode. EZ-DT-2/EZ-DT-4 User’s Manual...

  • Page 27: Self-Test

    Option : ^D0 ^O0 Sensor Setting See-through Sensor AD: 411 841 985 (22) Code Pag Code age: 850 【 】 Note For more information about advance settings, such as "Sen sor switch" or "Dump Mode", please refer to Programmer's manual. EZ-DT-2/EZ-DT-4 User’s Manual...

  • Page 28: Error Messages

    2 beeps twice out “Filename can not be found.” the file exist and the names are correct. File name is repeated; printer will Change the file name and 2 beeps twice print out “Filename is repeated.” download again. EZ-DT-2/EZ-DT-4 User’s Manual...

  • Page 29: Maintenance And Adjustment

    Flip the Print Head Lift downward to release it. The Print Head t can be flipped downward after Print Head Lift is released. Remove the Print Head Connector. EZ-DT-2/EZ-DT-4 User’s Manual...
  • Page 30 After new print head is installed, tighten the Print Head Screws, plug the Print Head Connector, resto the Print Head Bracket and lock the Print Head Li ft to complete the installation. EZ-DT-2/EZ-DT-4 User’s Manual...

  • Page 31: Thermal Print Head Cleaning

    Use screwdriver to turn the Cutter Adjustment Screw counter-clockwise for releasing the paper-knife of the cutter and then remove the jammed-label out. After the jammed-label is removed, turn the Cutter Adjustment Screw clockwise to restore the paper-knife. EZ-DT-2/EZ-DT-4 User’s Manual...

  • Page 32: Black Mark Paper

    Black Mark paper which p aper width is equal to the maximum width of rinter's acceptability (60mm for EZ-DT-2; 1 18mm for EZ-DT-4), the error may occur since the lack mark on reverse side of label cannot b e detected by sensor sometimes.

  • Page 33: Troubleshooting

    Check if stripper sensor is covered with dust working correctly. Check if label is installed properly 【 】 Note Your dealer is knowledgeable about printers, printing software, and your unique system. Please contact your local dealer for further technical support. EZ-DT-2/EZ-DT-4 User’s Manual...

  • Page 34: Appendix

    Appendix 1. EZ-DT-2 Certifications EZ-DT-2/EZ-DT-4 User’s Manual...
  • Page 35 EZ-DT-2/EZ-DT-4 User’s Manual...
  • Page 36 EZ-DT-2/EZ-DT-4 User’s Manual...
  • Page 37 EZ-DT-2/EZ-DT-4 User’s Manual...
  • Page 38 EZ-DT-2/EZ-DT-4 User’s Manual...

  • Page 39: Ez-Dt-4 Certifications

    2. EZ-DT-4 Certifications EZ-DT-2/EZ-DT-4 User’s Manual...
  • Page 40 EZ-DT-2/EZ-DT-4 User’s Manual...
  • Page 41 EZ-DT-2/EZ-DT-4 User’s Manual...
  • Page 42 EZ-DT-2/EZ-DT-4 User’s Manual...
  • Page 43 EZ-DT-2/EZ-DT-4 User’s Manual...
  • Page 44 EZ-DT-2/EZ-DT-4 User’s Manual...
