Digicast Media Router S2 Receiver CMR-5975 (MR-S2)
Installation & Initial Configuration
•
Comtech EF Data Customer Support if the shipment is:
Contact
Incomplete
Physically damaged
Inoperable
2.3 Installation
The MR-S2 is designed for ease of installation and configuration. Once the unit has been
removed from the packing container, please follow these instructions:
Step
1
2
3
4
5
6
7
Procedure
Place the MR-S2 on a flat surface with free-air flow where the LEDs can be clearly
observed with unrestricted access to the rear panel of the unit.
It is suggested that the coaxial connection to the Low Noise Block (LNB) NOT be
connected to the unit until the unit has been fully configured. If the unit will not be
powering the LNB, it is recommend that an F-Type DC Block be installed on the input
to the MR-S2's L-Band input
Connect the DC power connection to the connection labeled PWR on the back of the
unit and tighten the restraining nut to ensure secure operation.
Connect an RJ-45 Ethernet cable (patch cord) to the port labeled ETHERNET. This
cable should be connected to an Ethernet concentrator (hub) or switch.
Connect a terminal cable (supplied) to the port labeled TERM. This cable should be
connected to a PC's serial port (DB-9) to initially configure the MR-S2.
Connect the AC power cord between a standard wall outlet and the power supply.
The Blue LED will illuminate.
Upon startup, the following LEDs will illuminate on the MS-R2 front panel:
Function
LED
Label
Blue PWR
Green RED
Red ALARM
Green LOCK
Green E-SPD
Green E-COL
Green E-RX
Green E-TX
Green E-LINK
LED illuminates if power is properly applied
Redundancy indicator
LED may illuminate since the unit is not yet
configured
LED illuminates if the tuner is locked
Ethernet speed
Ethernet collision indicator
LED flashes if there is Ethernet traffic/activity
LED illuminates if the Ethernet connection to the
Hub/Switch is operational
2-2
Revision 3
MN-CMR5975-IOM
