Configuring and Controlling the Digicast CMR‑ 5975 Media Router with SNMP
E.4.1

MIB II OIDs on the Digicast Media Router (Model CMR-5975)

The following describes how MIB-II elements (OIDs) can be used to obtain (GET) information
from a Digicast CMR-5975 product:
The MIB-II elements are broken down into sections as follows:
MIB-11
Type
Number

mib-II

1 system
mib-II 2 interfaces
mib-II 3 at
mib-II 4 ip
mib-II 5 icmp
mib-II 6 tcp
mib-II 7 udp
mib-II 8 egp
mib-II 9 (no longer used)
mib-II 10 transmission - currently not used
mib-II 11 snmp
Supported MIB-II OIDs on the Digicast CMR-5975 Media Router product are as follows:
MIB-II
Type Sub Type
Number
mib-II 1 system
sysDescr
sysObjectID
sysUpTime
sysContact
sysName
sysLocation
sysServices
mib-II 2 interfaces
ifNumber
ifTable
mib-II 3 at
atTable
mib-II 4 ip
Description
General information about device for administration purposes
Keeps track of each interface on device
Address translation (only for backward compatibility)
Tracks IP (Internet Protocol) aspects
Tracks ICMP (Internet Control Message Protocol) aspects
Tracks TCP (Transmission Control Protocol) aspects
Tracks UDP (User Diagram Protocol) aspects
Tracks EGP (Exterior Gateway Protocol) aspects
Tracks SNMP aspects
OID
1.3.6.1.2.1.1
1.3.6.1.2.1.1.1
1.3.6.1.2.1.1.2
1.3.6.1.2.1.1.3
1.3.6.1.2.1.1.4
1.3.6.1.2.1.1.5
1.3.6.1.2.1.1.6
1.3.6.1.2.1.1.7
1.3.6.1.2.1.2
1.3.6.1.2.1.2.1
1.3.6.1.2.1.2.2
1.3.6.1.2.1.3
1.3.6.1.2.1.3.1
1.3.6.1.2.1.4
E–5
Description
General information about device
for administration purposes
System Description
System Object ID
System Up Time
System Contact
System Name
System Location
System Services
Keeps track of each interface on
device
Interface Number
Interface Table
Address translation (only for
backward compatibility)
Address Translation
Tracks IP (Internet Protocol)
Revision 3
MN-CMR5975-IOM
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
