Digicast Media Router S2 Receiver CMR-5975 (MR-S2)
Introduction
1.3

Performance

The MR-S2 provides the following performance characteristics:
Item
Maximum Bits Per Second
(Maximum Packet Size 1,518 Bytes)
Latency
Minimum Symbol Rate
Maximum Symbol Rate
Minimum Input Level
Minimum Input Level
1.4

Configurations

The MR-S2, shown in Figure 1-2, is a Satellite-to-Ethernet IP router.
Web Server
Streaming Media
Server
File Server
10/100 Base T
Ethernet
MENCAP 50
ATSC/DVB Encapsulator

Figure 1-3. Digicast Media Router S2 Receiver

Value
83 Mbps
Less than 10 ms
DVB-S (2 Msps)
DVB-S2 (2 Msps)
DVB-S (45 Msps)
DVB-S2 (32 Msps)
-50 dBm
-25 dBm
LBand
CMR-5975
Media Router MR-S2
1–3
Revision 3
MN-CMR5975-IOM
Ethernet
`
Desktop PC
or LAN
