Feature
Image setting
Color
OSD
Language
Recall
Miscellaneous
Exit
OSD and Power Button Control
The OSD menu and power button are enabled by default.
To enable or disable the OSD function:
15. Simultaneously press Menu/Exit and the Left (<-) key for two seconds. A
window appears displaying OSD ENABLE or OSD DISABLE.
16. When the OSD is disabled, the OSD menu is not visible.
To enable or disable the power button (PWR) lock function:
17. Simultaneously press Menu/Exit and the Right (->) key for two seconds. A
window appears displaying PWR ENABLE or PWR DISABLE.
18. When the power button lock feature is activated, the power button is disabled.
Description
Adjusts H position, V position, clock, and phase.
•
H position: Moves the screen horizontally right and left (1 pixel
pitch increment).
•
V position: Moves the screen vertically up and down (1 line
increment).
•
Clock: Adjusts the ratio of dividing frequency of the dot clock.
•
Phase: Adjusts the phase of the dot clock.
Sets color temperature (9300K, 7500K, 6500K, 5500K, or User
Preset).
Adjusts H position, V position, and OSD timeout.
•
H position: Adjusts the OSD menu screen position left or right.
•
V position: Adjusts the OSD menu screen position up or down.
•
Timeout: Adjusts the amount of time that the OSD menu is
displayed.
Changes language to English, French, Italian, German, Spanish,
Japanese, Simplified Chinese, or Traditional Chinese.
Sets color recall and recall defaults. Restores original factory settings.
Adjusts sharpness, enables/disables DDC/CI function.
Exits the OSD.
