Chapter 3 — Developing and Installing Applications

Upgrading the CN4 Using a miniSD Card

82
5 Double-click the .exe file on your PC. An InstallShield application
starts and walks you through the process of extracting the
upgrade files to the default location.
Note: Do not change the default location where InstallShield
extract the files. The SmartSystems console requires the files to be
in this location.
6 From the SmartSystems console, locate the device upgrade to
install.
7 Drag the file to each CN4 you want to upgrade or to a group of
CN4s in a folder. The SmartSystems console installs the upgrade
on your computers.
After the download is complete, your CN4 replaces the operating
system and automatically performs a cold boot.
Note: The SmartSystems console displays a red stop sign symbol,
indicating that the CN4 is offline, until the CN4 reboots and
reconnects to the system.
To use a miniSD card to upgrade the computer, you need an SD card
reader and a miniSD adapter card formatted as FAT16.
To upgrade the operating system using a miniSD card
1 Copy all required OS upgrade files to the miniSD card.
2 Insert the miniSD card into the CN4. For help, see
miniSD or SIM Card" on page 35.
3 Place the CN4 in a dock connected to external power and use a
stylus to press the Reset button located in the battery cavity on the
back of the CN4. For help, see
page 96.
4 Remove the miniSD card when the Installation Complete menu
appears.
5 Remove the CN4 from the dock and replace the battery.
To upgrade the SSPB using a miniSD card
1 Copy all required SSPB upgrade files to the miniSD card.
"Cold Booting the CN4" on
CN4 Mobile Computer User's Manual
"Installing a
