SECTION 1
' ' GENERAL
• Number of memory channels
• Frequency range
• Maximum input power
• Input impedance
• Minimum operating input power
• Automatic tuning time
(General)
(Returning to a memorized frequency)
• Tuning accuracy (VSWR)
• Antenna required
• Power supply required
• Current drain
• Usable temperature range
• Dimensions
(projections not included)
• Case construction
• Weight
(AT-130/AT-140)
(AT-130E)
• Control cable
All stated specifications are subject to change without notice or obligation.

SPECIFICATIONS

: 45
: 1.6 MHz to 30 MHz with a 7 m (23 ft) or longer antenna element
: 150 W PEP
100 W continuous
: 50
: 5 to 15 W
:
Approx. 2 to 3 sec. (max. 15 sec.)
Approx. 1 sec.
: Less than 2.0 : 1
(after tuning; except for multiples of
: Marconi-type with suitable RF ground
(More than 7 m (23 ft) is suggested)
: DC 13.6 V ± 15 % (supplied from HF transceiver)
: Less than 2 A
: –30˚C to +60˚C; –22˚F to +140˚F
: 230(W) 80(H)
9 3 ⁄ (W)
32
: Weatherproof
:
Approx. 2.5 kg; 5 lb 8 oz
Approx. 2.7 kg; 6 lb
: OPC-420
OPC-566
OPC-1147
OPC-1186
1
340(D) mm
3 3 ⁄ (H) 13 13 ⁄ (D) in
32 32
(For [IC-77/78])
(For [IC-M700PRO], [IC-M710/RT])
(For [IC-M802])
(For [IC-F7000])
1 - 1
⁄ )
