UNIT DESCRIPTION AND SPECIFICATIONS

Unit description

■
Ground terminal
Antenna terminal
Mounting plate

Specifications

■
• Frequency coverage:
• Power supply requirement:
• Current drain:
• Operating temperature range:
• Weight (approximately):
• Antenna connector:
• Maximum Input power:
• Automatic tuning time:
• Automatic tuning accuracy:
• Usable pole diameter:
All stated specifications are subject to change without notice or obligation.
Antenna connector
91.5 mm; 3.6 inches
1.6–30 MHz (with 7 m; 23.0 feet) or longer antenna element)
13.6 V DC (supplied from the HF transceiver)
Maximum 2 A
°C to +60°C (–22°F to +140°F)
–30
2.5 kg; 5.5 lb
Ω)
SO-239 (50
150 W (PEP)
Approximately 2 to 3 seconds (general condition)
Maximum 15 seconds
Approximately 1 second (re-tuning for a memorized frequency)
SWR 2.0:1 (after tuning, except for multiples of
32 to 60 mm; 1.3 to 2.4 inches
80 mm; 3.1 inches
Mounting plate
Control cable connector
100 W (continuous)
5
λ)
1 ⁄
2
10 10
