Icom AT-130 Service Manual page 13

[TUNER UNIT]
REF ORDER
NO. NO.
J15 6510003100 CONNECTOR
J16 6510003100 CONNECTOR
P4 6910003120 CONNECTOR
P5 6910003120 CONNECTOR
P6 6910003120 CONNECTOR
DS1 5040002860 LED
DS2 5040002860 LED
DS3 5040002860 LED
DS4 5040002860 LED
DS5 5040002860 LED
DS6 5040002860 LED
DS7 5040002860 LED
DS8 5040002860 LED
DS9 5040002860 LED
DS10 5040002860 LED
DS11 5040002860 LED
DS12 5040002860 LED
DS13 5040002860 LED
DS14 5040002860 LED
DS15 5040002860 LED
DS16 5040002860 LED
DS17 5040002860 LED
DS18 5040002860 LED
DS19 5040002860 LED
DS20 5040002860 LED
DS21 5040002860 LED
DS22 5040002860 LED
DS23 5040002860 LED
DS24 5040002860 LED
S1 2260000200 SWITCH
S2 2260000580 SWITCH
S3 2260000830 SWITCH
S4 2260000610 SWITCH
S5 2260000830 SWITCH
W1 7120000010 JUMPER
W2 6910001030 JUMPER
W3 6910001030 JUMPER
W4 6910001030 JUMPER
W5 6910001020 JUMPER
W6 6910001030 JUMPER
W7 6910001030 JUMPER
W8 6910001020 JUMPER
W9 6910001020 JUMPER
W10 6910001020 JUMPER
W11 6910001020 JUMPER
W12 6910001030 JUMPER
W13 6910001030 JUMPER
W16 6910001020 JUMPER
W17 9040401015 WIRE
W19 9045201001 WIRE
W20 9045201001 WIRE
W36 6910001030 JUMPER
W37 9040401015 WIRE
W38 9040401015 WIRE
W39 9040401015 WIRE
W40 9040401015 WIRE
W42 6910001030 JUMPER
W49 6910001030 JUMPER
W50 6910001030 JUMPER
W51 6910001030 JUMPER
W52 6910001030 JUMPER
W53 6910001030 JUMPER
W54 6910001030 JUMPER
W55 6910001030 JUMPER
W56 6910001030 JUMPER
W57 6910001030 JUMPER
W58 6910001030 JUMPER
W59 6910001030 JUMPER
W60 6910001030 JUMPER
W70 6910001030 JUMPER
W71 6910001030 JUMPER
W72 6910001020 JUMPER
W73 6910001030 JUMPER
W74 6910001030 JUMPER
W75 6910001030 JUMPER
W76 6910001020 JUMPER
W77 7120000010 JUMPER
W78 6910001030 JUMPER
W79 6910001020 JUMPER
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
DESCRIPTION M.
RT01T-1.3B
RT01T-1.3B [AT-130/E] only
IMSA-9206H-T
IMSA-9206H-T
IMSA-9206H-T
EL-204HD
EL-204HD
EL-204HD
EL-204HD
EL-204HD
EL-204HD
EL-204HD
EL-204HD
EL-204HD
EL-204HD
EL-204HD
EL-204HD
EL-204HD
EL-204HD
EL-204HD
EL-204HD
EL-204HD
EL-204HD
EL-204HD
EL-204HD
EL-204HD
EL-204HD
EL-204HD
EL-204HD
MS621C
SKHLAD035A
SSGM18049A
SSGM17012A
SSGM18049A
JPW 02A
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-2
IPS-1041-4
IPS-1041-4
IPS-1041-2
IPS-1041-2
IPS-1041-2
IPS-1041-2
IPS-1041-4
IPS-1041-4
IPS-1041-2
74/98/045/X98/X98
74/98/040/X98/X98 [AT-130/E] only
74/98/040/X98/X98
[AT-130/140] only
IPS-1041-4
74/98/045/X98/X98
74/98/045/X98/X98
74/98/045/X98/X98
74/98/045/X98/X98
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-2
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-2
JPW 02A
IPS-1041-4
IPS-1041-2
[TUNER UNIT]
REF ORDER
NO. NO.
T W80 6910001030 JUMPER
T W81 6910001030 JUMPER
W82 6910001020 JUMPER
W83 6910001020 JUMPER
T W84 6910001020 JUMPER
T W85 6910001030 JUMPER
T W87 6910001030 JUMPER
W88 6910001030 JUMPER
W89 6910001030 JUMPER
T W90 6910001020 JUMPER
T W91 6910001030 JUMPER
T W92 6910001020 JUMPER
T W93 6910001030 JUMPER
T W94 6910001030 JUMPER
T W95 6910001030 JUMPER
T W96 7120000010 JUMPER
T W97 7120000010 JUMPER
T W98 6910001030 JUMPER
T W99 6910001020 JUMPER
T W100 6910001020 JUMPER
T W102 6910001030 JUMPER
T W104 6910001020 JUMPER
T W105 6910001020 JUMPER
T W106 6910001020 JUMPER
T W107 6910001020 JUMPER
T W108 6910001030 JUMPER
T W109 6910001020 JUMPER
T W110 6910001030 JUMPER
T W111 6910001020 JUMPER
T W112 6910001030 JUMPER
T W113 6910001030 JUMPER
T W114 6910001020 JUMPER
T W115 6910001030 JUMPER
W116 6910001020 JUMPER
W117 6910001020 JUMPER
T W120 6910001030 JUMPER
T W121 7120000010 JUMPER
T W122 6910001030 JUMPER
T W123 6910001030 JUMPER
T W124 6910001020 JUMPER
W125 6910001030 JUMPER
W126 6910001030 JUMPER
T W127 6910001030 JUMPER
T W128 6910001030 JUMPER
T W129 6910001030 JUMPER
T W130 6910001030 JUMPER
T W131 6910001020 JUMPER
T W132 6910001030 JUMPER
T W133 6910001030 JUMPER
T W134 6910001030 JUMPER
T W135 6910001030 JUMPER
T W136 6910001030 JUMPER
T W137 6910001020 JUMPER
T W138 6910001020 JUMPER
T W139 6910001020 JUMPER
T W140 6910001020 JUMPER
T W141 6910001020 JUMPER
T W142 6910001030 JUMPER
W144 6910001020 JUMPER
T W145 6910001030 JUMPER
T W146 6910001030 JUMPER
T W147 6910001020 JUMPER
T W148 6910001020 JUMPER
T W149 6910001030 JUMPER
T W150 6910001030 JUMPER
T W151 6910001030 JUMPER
T W152 7120000010 JUMPER
T W153 7120000010 JUMPER
T W157 6910001030 JUMPER
T W158 7120000010 JUMPER
T W159 9045201001 WIRE
T W160 6910001020 JUMPER
T W161 6910001030 JUMPER
T W162 6910001020 JUMPER
T W163 6910001020 JUMPER
T W164 6910001030 JUMPER
T W165 6910001020 JUMPER
T W168 6910001020 JUMPER
T W169 9040401015 WIRE
T W170 9040401015 WIRE
T W171 6910001020 JUMPER
T W172 6910001020 JUMPER
T W174 6910001020 JUMPER
T W176 6910001020 JUMPER
T
T
T
T
5 - 4
DESCRIPTION M.
IPS-1041-4
IPS-1041-4
IPS-1041-2
IPS-1041-2
IPS-1041-2
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-2
IPS-1041-4
IPS-1041-2
IPS-1041-4
IPS-1041-4
IPS-1041-4
JPW 02A
JPW 02A
IPS-1041-4
IPS-1041-2
IPS-1041-2
IPS-1041-4
IPS-1041-2
IPS-1041-2
IPS-1041-2
IPS-1041-2
IPS-1041-4
IPS-1041-2
IPS-1041-4
IPS-1041-2
IPS-1041-4
IPS-1041-4
IPS-1041-2
IPS-1041-4
IPS-1041-2
IPS-1041-2
IPS-1041-4
JPW 02A
IPS-1041-4
IPS-1041-4
IPS-1041-2
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-2
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-4
IPS-1041-2
IPS-1041-2
IPS-1041-2
IPS-1041-2
IPS-1041-2
IPS-1041-4
IPS-1041-2
IPS-1041-4
IPS-1041-4
IPS-1041-2
IPS-1041-2
IPS-1041-4
IPS-1041-4
IPS-1041-4
JPW 02A
JPW 02A [AT-140] only
IPS-1041-4
JPW 02A
74/98/040/X98/X98
IPS-1041-2
IPS-1041-4
IPS-1041-2
IPS-1041-2
IPS-1041-4
IPS-1041-2
IPS-1041-2
74/98/045/X98/X98 [AT-140] only
74/98/045/X98/X98 [AT-140] only
IPS-1041-2 [AT-140] only
IPS-1041-2 [AT-140] only
IPS-1041-2 [AT-140] only
IPS-1041-2 [AT-140] only
S.=Surface mount
