Icom AT-130 Service Manual page 12

[TUNER UNIT]
REF ORDER
NO. NO.
C7 4610000740 TRIMMER
C8 4010000360 CERAMIC
C9 4510005110 ELECTROLYTIC
C10 4010000520 CERAMIC
C11 4020000990 CYLINDER
C12 4010000410 CERAMIC
C13 4010000410 CERAMIC
C14 4020000990 CYLINDER
C15 4020001000 CERAMIC
C16 4010000520 CERAMIC
C17 4020000980 CYLINDER
C18 4020000990 CYLINDER
C19 4020000420 CYLINDER
C20 4010000210 CERAMIC
C21 4010000410 CERAMIC
C22 4010000520 CERAMIC
C23 4020000990 CYLINDER
C24 4320000661 DIP MICA
C25 4320000661 DIP MICA
C26 4320000661 DIP MICA
C28 4010004740 CERAMIC
C29 4010004750 CERAMIC
C30 4010004280 CERAMIC
C31 4010004280 CERAMIC
C32 4010004280 CERAMIC
C34 4010000520 CERAMIC
C35 4010004280 CERAMIC
C36 4010004280 CERAMIC
C37 4010004790 CERAMIC
C38 4010004260 CERAMIC
C39 4010004770 CERAMIC
C40 4010004770 CERAMIC
C41 4010005040 CERAMIC
C42 4010005040 CERAMIC
C43 4010000520 CERAMIC
C44 4010004810 CERAMIC
C45 4010004810 CERAMIC
C46 4010004810 CERAMIC
C47 4010004810 CERAMIC
C48 4010000520 CERAMIC
C50 4020000980 CYLINDER
C52 4010000520 CERAMIC
C53 4510003900 ELECTROLYTIC
C54 4010000520 CERAMIC
C55 4010000520 CERAMIC
C56 4510005120 ELECTROLYTIC
C57 4010000520 CERAMIC
C58 4010000520 CERAMIC
C59 4020000990 CYLINDER
C60 4510004590 ELECTROLYTIC
C61 4010000520 CERAMIC
C62 4010000520 CERAMIC
C64 4010000520 CERAMIC
C65 4010000520 CERAMIC
C66 4010000520 CERAMIC
C68 4020001000 CERAMIC
C69 4010000500 CERAMIC
C70 4010000520 CERAMIC
C71 4010000520 CERAMIC
C72 4020001000 CERAMIC
C73 4020001000 CERAMIC
C74 4010000520 CERAMIC
C75 4310000520 MYLAR
C76 4010000520 CERAMIC
C77 4010000520 CERAMIC
C78 4010000430 CERAMIC
C79 4010000460 CERAMIC
C81 4020001000 CERAMIC
C82 4550000340 TANTALUM
C83 4510005460 ELECTROLYTIC
C84 4310000520 MYLAR
C85 4310000520 MYLAR
C86 4010000500 CERAMIC
C87 4010000810 CERAMIC
C88 4010000810 CERAMIC
C89 4020001000 CERAMIC
C90 4530000250 ARRAY
C91 4010000520 CERAMIC
C92 4020001000 CERAMIC
C93 4530000250 ARRAY
C94 4010000520 CERAMIC
C95 4010000520 CERAMIC
C96 4530000250 ARRAY
C98 4010000520 CERAMIC
C100 4010000520 CERAMIC
C102 4010000520 CERAMIC
C104 4010000520 CERAMIC
C106 4010000520 CERAMIC
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
DESCRIPTION M.
ECV-1ZW 10X53T
DD106 SL 181J 50V
16 MV 33 HC
DD107-601 B 472K 50V
UP050 B 473K-NA-CZ
DD107 SL 331J 50V
DD107 SL 331J 50V
UP050 B 473K-NA-CZ
RPER11H472K2P1A01B
DD107-601 B 472K 50V
UP050 B 104K-NA-CZ
UP050 B 473K-NA-CZ
UP050 SL 100J
DD104 SL 300J 50V
DD107 SL 331J 50V
DD107-601 B 472K 50V
UP050 B 473K-NA-CZ
KD20C 122J5A
KD20C 122J5A
KD20C 122J5A
DE1207 SL 271J 2KV
DE1510 SL 331J 2KV
DE1207 SL 151J 3KV
DE1207 SL 151J 3KV
DE1207 SL 151J 3KV
DD107-601 B 472K 50V
DE1207 SL 151J 3KV
DE1207 SL 151J 3KV
DEC1X3J680JC4B (DE1210SL680J)
DE0907 SL 820J 3KV
DEC1X3J390JC4B (DE0910SL390J)
DEC1X3J390JC4B (DE0910SL390J)
DE0707 SL 180J 3KV
DE0707 SL 180J 3KV
DD107-601 B 472K 50V
DEC1X3J101JC4B (DE1310SL101J)
DEC1X3J101JC4B (DE1310SL101J)
DEC1X3J101JC4B (DE1310SL101J)
DEC1X3J101JC4B (DE1310SL101J)
DD107-601 B 472K 50V
UP050 B 104K-NA-CZ
DD107-601 B 472K 50V
16 MV 22 HW
DD107-601 B 472K 50V
DD107-601 B 472K 50V
16 MV 47 HC
DD107-601 B 472K 50V
DD107-601 B 472K 50V
UP050 B 473K-NA-CZ
16 MV 470 HC
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
RPER11H472K2P1A01B
DD104 B 102K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
RPER11H472K2P1A01B
RPER11H472K2P1A01B
DD107-601 B 472K 50V
50 F2D 224J
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD108-601 SL 471J 50V
DD104 B 471K 50V
RPER11H472K2P1A01B
DN 1C 100M
FYDOH 474Z
50 F2D 224J
50 F2D 224J
DD104 B 102K 50V
DD104 CH 300J 50V
DD104 CH 300J 50V
RPER11H472K2P1A01B
B8XC0112-33N
DD107-601 B 472K 50V
RPER11H472K2P1A01B
B8XC0112-33N
DD107-601 B 472K 50V
DD107-601 B 472K 50V
B8XC0112-33N
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
[TUNER UNIT]
REF ORDER
NO. NO.
T C108 4010000520 CERAMIC
T C110 4010000520 CERAMIC
T C112 4010000520 CERAMIC
T C114 4010000520 CERAMIC
T C116 4010000520 CERAMIC
T C118 4010000520 CERAMIC
T C120 4010000520 CERAMIC
T C122 4010000520 CERAMIC
T C124 4010000520 CERAMIC
T C126 4010000520 CERAMIC
T C128 4010000520 CERAMIC
T C130 4010000520 CERAMIC
T C132 4010000520 CERAMIC
T C134 4010000520 CERAMIC
T C136 4010000520 CERAMIC
T C137 4530000250 ARRAY
T C138 4530000250 ARRAY
T C139 4530000250 ARRAY
T C140 4530000250 ARRAY
T C141 4530000250 ARRAY
T C142 4530000250 ARRAY
T C144 4530000050 ARRAY
T C147 4010000520 CERAMIC
T C148 4020001000 CERAMIC
T C150 4010000520 CERAMIC
T C152 4010000520 CERAMIC
T C153 4010000520 CERAMIC
T C155 4010000520 CERAMIC
T C156 4020001000 CERAMIC
T C162 4010005610 CERAMIC
T 4010005660 CERAMIC
T C163 4020001000 CERAMIC
T C164 4010000520 CERAMIC
T C165 4010000520 CERAMIC
T C166 4530000250 ARRAY
T C167 4530000250 ARRAY
T C168 4530000250 ARRAY
T C169 4010000520 CERAMIC
T C170 4020001000 CERAMIC
T C171 4010000520 CERAMIC
T C172 4010000520 CERAMIC
T C173 4010000520 CERAMIC
T C174 4020000990 CYLINDER
T C175 4020001000 CERAMIC
T C176 4010000520 CERAMIC
T C177 4020001000 CERAMIC
T C178 4010000520 CERAMIC
T C179 4010000520 CERAMIC
T C181 4020001000 CERAMIC
T C182 4010003930 CERAMIC
T
T
T RL1 6330001070 RELAY
T RL2 6330001070 RELAY
T RL3 6330001060 RELAY
T RL4 6330000570 RELAY
T RL5 6330001060 RELAY
T RL6 6330001060 RELAY
T RL7 6330001060 RELAY
T RL8 6330001060 RELAY
T RL9 6330001060 RELAY
T RL10 6330001060 RELAY
T RL11 6330001060 RELAY
T RL12 6330001060 RELAY
T RL13 6330001060 RELAY
T RL14 6330001060 RELAY
T RL15 6330001060 RELAY
T RL16 6330001060 RELAY
T RL17 6330001060 RELAY
T RL18 6330001060 RELAY
T RL19 6330001060 RELAY
T RL20 6330001060 RELAY
T RL21 6330001060 RELAY
T RL22 6330001060 RELAY
T RL23 6330001060 RELAY
T RL24 6330001060 RELAY
T RL25 6330000570 RELAY
T RL26 6330000570 RELAY
T RL27 6330000570 RELAY
T
T
T J1 6510000130 CONNECTOR
T J4 6910003140 CONNECTOR
T J5 6910003140 CONNECTOR
T J6 6910003140 CONNECTOR
T J8 6510024500 CONNECTOR
T J9 6510015150 CONNECTOR
T J13 6910003140 CONNECTOR
5 - 3
DESCRIPTION M.
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
B8XC0112-33N
B8XC0112-33N
B8XC0112-33N
B8XC0112-33N
B8XC0112-33N
B8XC0112-33N
B5RC0126-33N
DD107-601 B 472K 50V
RPER11H472K2P1A01B
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
RPER11H472K2P1A01B
HM60SJ SL 100D 500 V [AT-130E]
HM60SJ SL 220J 500V [OTHER]
RPER11H472K2P1A01B
DD107-601 B 472K 50V
DD107-601 B 472K 50V
B8XC0112-33N
B8XC0112-33N
B8XC0112-33N
DD107-601 B 472K 50V
RPER11H472K2P1A01B
DD107-601 B 472K 50V
DD107-601 B 472K 50V
DD107-601 B 472K 50V
UP050 B 473K-NA-CZ
RPER11H472K2P1A01B
DD107-601 B 472K 50V
RPER11H472K2P1A01B
DD107-601 B 472K 50V
DD107-601 B 472K 50V
RPER11H472K2P1A01B
DD06 SL 270K 500V
AJQ1341 B01
AJQ1341 B01
APQ 3311
AR-39251
APQ 3311
APQ 3311
APQ 3311
APQ 3311
APQ 3311
APQ 3311
APQ 3311
APQ 3311
APQ 3311
APQ 3311
APQ 3311
APQ 3311
APQ 3311
APQ 3311
APQ 3311
APQ 3311
APQ 3311
APQ 3311
APQ 3311
APQ 3311
AR-39251
AR-39251
AR-39251
FM MDR MI [AT-130/E] only
IMSA-9202B-1-02T
IMSA-9202B-1-02T
IMSA-9202B-1-02T
B06B-XH-A
ML-800S1V-6P [AT-130/E] only
IMSA-9202B-1-02T
S.=Surface mount
